AOC L32W431 Service Manual
AOC L32W431 Service Manual

AOC L32W431 Service Manual

32" lcd tv

Advertisement

32" LCD TV
Service
Service
Service
Description
Table Of Contents.....................................................1
Revision List.......................................................2
Important Safety Notice...................................................3
1. General Specification...............................................4
2. Operating Instructions.........................................5
2.1. The Use Of Remote Control.................................5
2.2. Front Panel Control Knobs.................................6
2.3. To Use The Menu...............................................7
2.4. How To Connect..............................................13
3. Input/Output Specification.......................................15
4. Mechanical Instructions.........................................17
5. Repair Flow Chart ..............................................20
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
.scf
显示桌面

TABLE OF CONTENTS

Page
Description
7.PCB Layout ..............................................30
7.1 Main Board...........................................30
7.2 Power Board...........................................33
7.3 Tuner Board.......................................35
8. Block Diagram.........................................37
9. Schematic Diagram.......................................38
9.1 Main Board.................................................38
9.2 Power Board...............................................49
9.3 Tuner Board................................................51
10.Exploded View.............................................55
11.BOM List...............................................56
12.Different Parts List....................................107
SAFETY NOTICE
1
AOC L32W431
Horizontal Frequency
31. 5 kHz to 49 kHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L32W431 and is the answer not in the manual?

Questions and answers

Summary of Contents for AOC L32W431

  • Page 1: Table Of Contents

    32″ LCD TV AOC L32W431 Service Service Service .scf 显示桌面 Horizontal Frequency 31. 5 kHz to 49 kHz TABLE OF CONTENTS Description Page Description Page Table Of Contents..……......…..1 7.PCB Layout …………..………………..…..30 Revision List……………………………………………..2 7.1 Main Board…………..………….………..30 Important Safety Notice........……..3 7.2 Power Board…………..………….………..33 1.
  • Page 2: Revision List

    32″ LCD TV AOC L32W431 Revision List Version Release Date Revision History TPV Model Apr.-02-2007 Initial Release E326MTNSD1A3NP May-29-2007 Second Release E326MTNCW1GLN Jan-07-2008 Add SKD model for Brazil E327MTNSW1AC6N...
  • Page 3: Important Safety Notice

    AOC L32W431 Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.
  • Page 4: General Specification

    32″ LCD TV AOC L32W431 1. General Specification Items Specification Screen Size 32”(81cm)TFT-LCD Panel Panel type TV 32" B1-L04 CMO Aspect Ratio 16:9 Resolution (Native) 1366 x 768 WXGA Active Area 714.96 (H) x 404.6 (V) mm Pixel Pitch 0.1730 (H) x 0.5190 (V) mm...
  • Page 5: Operating Instructions

    32″ LCD TV AOC L32W431 2. Operations Instructions 2.1 The Use of Remote Control...
  • Page 6: Front Panel Control Knobs

    32″ LCD TV AOC L32W431 2.2 Front Panel Control Knobs : Press to turn the TV on or off. MENU Key: Press to show the OSD menu and exit OSD menu at the TV. Down / Up Key: Press to select OSD function or change channel.
  • Page 7: To Use The Menu

    32″ LCD TV AOC L32W431 2.3 OSD Operations To use the menus: 1. Press the MENU button to display each menu. 2. Use the cursor up/down to select a menu item. 3. Use the cursor left/right to enter a submenu or enable/disable the function.
  • Page 8 32″ LCD TV AOC L32W431 When adjust any item sub-OSD will show up like this. 4. SATURATION: Adjust color saturation, range is from 0 to 100. 5. SHARPNESS: Adjustment picture sharpness, range is from 0 to 100. 6. NR: When the signal is poor, you can turn on the noise reduction function.
  • Page 9 32″ LCD TV AOC L32W431 Note: To check the remaining time, press the SLEEP button. To cancel the sleep timing, press the SLEEP button repeatedly until 0 appears. If you turn off the TV after you set the sleep timing, the setting will be cleared. You will need to set it again.
  • Page 10 32″ LCD TV AOC L32W431 Press the MENU button to enter into the OSD Main Menu. Adjustable items include: VIDEO SETTING, SOUND SETTING, OPTIONS SETTING, VGA SETTING VIDEO SETTING: 1. CONTRAST: Adjust black and white level, suitable contrast can make picture more lightly. Adjustment range is from 0 to 100.
  • Page 11 32″ LCD TV AOC L32W431 2.EFFECT:You can choice your prefer mode of CUSTOM, STEREO, NEWS, MOVIE, MUSIC, BBE VIVA. 3.120Hz, 500Hz, 1500Hz, 5 KHz, 10KHZ. Choice the prefer frequency to increase or decrease. OPTIONS SETTING: 1. MENU LANGUAGE: This indicates the different languages available for the OSD menu, including Simplified English, Spanish and Portuguese.
  • Page 12 32″ LCD TV AOC L32W431 3. Clock: (The function only in VGA mode) 4. Focus: Adjust A/D focus. (The function only in VGA mode) 5. Auto tune: Auto tune to a best status on screen.(The function only in VGA mode) 6.
  • Page 13: How To Connect

    32″ LCD TV AOC L32W431 2.4 How to Connect VIDEO RECORDER 1. Connect the antenna or cable 1 to the RF IN port of your VCR. 2. Connect another RF cable 2 from the output RF of your VCR to the Antenna input of your TV. Better quality when playing from our VCR can be obtained if you also connect the Video, Audio LEFT AND right (only for stereo equipment) cables 3 to the VIDEO, AUDIO L and R inputs AV.
  • Page 14 32″ LCD TV AOC L32W431 2. Connect the audio cables 2 to the DVD player’s AUDIO L and R ports and to the L and R AUDIO AV ports on the HDMI: HDMI is the leading new standard for Digital video and audio interconnection.
  • Page 15: Input/Output Specification

    32″ LCD TV AOC L32W431 3. Input/Output Specification 3.1 Input Signal connector This procedure gives you instructions for installing and using the LCD TV display. Lay the display on the desired operation and plug the power cord into a convenient AC outlet. Three-wire power cord must be shielded and is provided as a safety precaution as it connects the chassis and cabinet to the electrical conduct ground.
  • Page 16 32″ LCD TV AOC L32W431 Apply power to the display by turning the power switch to the "ON" position and allow about ten seconds for Panel warm-up. The Power-On indicator lights "GREEN" when the display is on. With proper signals feed to the display, a pattern or data should appear on the screen, adjust the brightness and contrast to the most pleasing display, or press auto-adjust to get the best picture-quality.
  • Page 17: Mechanical Instructions

    32″ LCD TV AOC L32W431 4. Mechanical Instructions Step Figure Description Lay the LCD-TV on a flat, soft and clean Preparation surface. Disassemble the stand cover. Remove Remove the 8 screws the stand remove Remove the 14 screws the rear...
  • Page 18 32″ LCD TV AOC L32W431 Remove Remove the 8 screws the plate Remove Remove the screws the shield...
  • Page 19 32″ LCD TV AOC L32W431 Remove Remove the 9 screws the main & 6 connectors to board & remove the main board and power power board board Remove Remove the 16 screws the main to remove the main frame frame...
  • Page 20: Repair Flow Chart

    32″ LCD TV AOC L32W431 5. Repair Flow Chart 5.1 No Power (No LED indicator) Plug in power cord and interface Check power cord and board interface Replace F901 or BD901 or D910 or D902 Check F901, BD901, D901, D902...
  • Page 21 32″ LCD TV AOC L32W431 5.2 Can not start (LED indicator yellow) Check key board Repair the key board Return to “5.1” Check 5V_SB Check main board power supply and U402 Check PWR_ON signal Check I C communication Replace panel...
  • Page 22 32″ LCD TV AOC L32W431 5.3 No display (LED indicator green) Reset source Check the source Reset LVDS cable Check LVDS cable Return to “5.1” Check 12V and 5V power supply Check main board power supply Check U402,U401 Replace U402,U401...
  • Page 23 32″ LCD TV AOC L32W431 5.4 Abnormal display Reset source Check the source Check signal filter circuit Replace the filter or resistance RF signal Check TV system setup Check input Check LVDS cable Check Tuner Replace LVDS cable Check panel...
  • Page 24 32″ LCD TV AOC L32W431 5.5 No sound Reset source Check the source Check signal filter circuit Replace the filter circuit Check Earphone jack Replace the Earphone jack SIF signal Check TV system setup Replace Tuner Check Tuner AV, S-video, HDMI, PC signal...
  • Page 25 32″ LCD TV AOC L32W431 5.6 Key Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Pad Board Is Button Switch normally? Replace Button Switch Replace Key Pad Board Is Key Pad Board Normally?
  • Page 26: White-Balance, Luminance Adjustment

    32″ LCD TV AOC L32W431 6. White Balance, Luminance Adjustment Instrument List: Chroma 2225、VG848、Chroma 7120 Adjustment Process: ① Instrument Orientation Connect LCD-TV、Chroma 2225 and VG848, and set Timing137、Pattern1 on Chroma2225. Chroma7120’s lens must aim at the center of Pattern1 showed on the LCD-TV’s screen. The distance of Chroma7120’s lens and the center of screen is 20cm±1cm.
  • Page 27 32″ LCD TV AOC L32W431 Fig.3 ③ PC Mode White Balance Adjustment Begin to adjust the W/B (White Balance) you should select the Color Temp(Warm and Cold) and enter the son menu from father menu “Scaler” refer to Fig.2 and Fig.3.
  • Page 28 32″ LCD TV AOC L32W431 Fig.5 Fig.6 Fig.7 1.OFFSET(26%) W/B ADJUSTMENT(This is only for AV/TV):Change the input signal to 26% white level performance .Set the CHROMA7120 to 288 301 30 and MODE_RGB ,then adjust the TV’s RB、GB、BB to make CHROMA7120 display to 100.
  • Page 29 32″ LCD TV AOC L32W431 MODE_RGB and CH3, check whether the color temperature was in SPEC (color spec is x±15;y±15;Y±15). In this time, most of the TV is in SPEC, while the others should be adjusted twice or more to make its color temperature in SPEC.
  • Page 30: Pcb Layout

    32″ LCD TV AOC L32W431 7. PCB Layout 7.1 Main Board...
  • Page 31 32″ LCD TV AOC L32W431...
  • Page 32 32″ LCD TV AOC L32W431...
  • Page 33: Power Board

    32″ LCD TV AOC L32W431 7.2 Power Board...
  • Page 34 32″ LCD TV AOC L32W431...
  • Page 35: Tuner Board

    32’’ LCD TV AOC L32W431 DC-DC Board 7.3 Tuner Board...
  • Page 36 32’’ LCD TV AOC L32W431...
  • Page 37: Block Diagram

    32″ LCD TV AOC L32W431 8. Block Diagram...
  • Page 38: Schematic Diagram

    DVI_RXC+ R241 CLK+ DVI_RXC+ DVI_RXC- RClamp0504F DVI_RXC- CLK- 56T662-2 A_RED A_GREEN 715V1768-C A_BLUE A_HSYNC A_GND1 U207 A_GND2 DVI_RX0- DVI_RXC- AOC (Top Victory) Electronics Co., Ltd. 5V_SB JACK DVI_RXC+ DVI_RX0+ Title RClamp0504F Size Document Number Date: Monday, July 24, 2006 Sheet...
  • Page 39   1/16W Q204 PC_R PMBS3904 L206 150 OHM C224 Q205 To mcu R230 0.001uF VGAHS PMBS3906   1/16W AOC (Top Victory) Electronics Co., Ltd. C225 R231 P201 C226 R232 D206 0.047uF 100K  0.47uF/50V PC_AUDIO 1/16W BAT54S   Title C200 0.001uF...
  • Page 40 MPUCS0N 100   100   CAS# MPUGPIO4 DQS[0..3] RAS# MPU has CS0# MPU has separated MA[0..11] MCLK0# Data/Address AOC (Top Victory) Electronics Co., Ltd. Address/Data MCLK0 multiplex I2C Address: Title I2C Address: SVP-EX256_1 7C/7D VD3_3 7E/7F MCU_A[0..7] Size Document Number...
  • Page 41 VD3_3 C366 0.1uF C367 FB306 VDDH 10uF/16V VD3_3 AVSS3_BG_ASS P_38 150 OHM P_33 C368 0.1uF C369 P_24 AOC (Top Victory) Electronics Co., Ltd. C375 10uF/16V C370 C371 C372 C373 C374 VSSH VSSH C376 C377 Power saving ? 0.1uF 0.1uF 0.1uF 0.1uF...
  • Page 42 MEMORY DECOUPLING SCHEME 600 OHM 600 OHM C304 C305 C306 C307 C308 C309 C310 C311 C312 C313 C314 C315 AOC (Top Victory) Electronics Co., Ltd. 0.1uF 0.1uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.0047uF 0.0047uF 0.1uF 0.1uF 0.01uF Title SVP-EX_DDR Size...
  • Page 43 1/16W 4.7K   1/16W R489 R490 Top View 4.7K  R491 CPU_RST 4.7K  RST# RST_H Q404 RESET Reset MCU AOC (Top Victory) Electronics Co., Ltd. 2,3,9 PMBS3904 C415 U404 2,3,9 RST_HDMI ASM810SEUR-T Title R492 2K  C416 CN400 10uF/16V CONN Size Document Number...
  • Page 44 300 OHM FILT+ C498 C497 0.1uF 10uF/16V P1_+5V R4026 C499 C4000 C4001 10uF/16V Q405   1/16W 10uF/16V 0.1uF AOC (Top Victory) Electronics Co., Ltd. BSN20 R4027 3V3S   1/16W Title SIL_9021 Size Document Number Date: Monday, April 10, 2006 Sheet...
  • Page 45 RESO Option AMCLK CLKEXT Logic 0 for 24.576MHz R522 VDD1.8 Logic 1 for 32.11MHz VDD3.3 4.7K 1/16W   AOC (Top Victory) Electronics Co., Ltd. R523 C538 C539 C541 C540 680pF 270pF 0.0027uF 0.1uF Title SAA7117A Logic 0 for slave address 42h/43h and 4Ah/4Bh...
  • Page 46 4.7uF/16V 0805 5V_A Earphone Jack R556 3.9K   1/16W C5002 CP500 R557 C5003 47uF/16V 470pF 10uF/16V 3.9K   1/16W R558 10K   1/16W AOC (Top Victory) Electronics Co., Ltd. Title Amplifier Size Document Number Custom Date: Monday, April 10, 2006 Sheet...
  • Page 47 10uF/16V 10uF/16V 0.1uF 0.1uF C718 0.1uF Q709 PMBS3904 AP1117E3.3A U702 3.3V_SB 5V_SB L707 600 OHM C720 C722 C719 AOC (Top Victory) Electronics Co., Ltd. C721 0.1uF 0.1uF 22uF/16V 22uF/16V Title POWER_1 Size Document Number Date: Monday, April 10, 2006 Sheet...
  • Page 48 300 OHM 22uF/16V 0.1uF VR1_8 U711 300 OHM L720 C756 C757 C758 10uF/16V 10uF/16V 0.1uF C759 C760 22uF/16V Sil9021 AOC (Top Victory) Electronics Co., Ltd. 0.1uF C761 1.8V 10uF/16V Title Power POWER_2 Size Document Number Date: Monday, April 10, 2006 Sheet...
  • Page 49: Power Board

    32″ LCD TV AOC L32W431 9.2 Power Board C970 0.0022uF/250V D940 UF4003 C915 0.0022uF/250V C940 22UF/50V P1-1 D901 ML35 FOR BACKLIGHT 24V/5A P2-1 L951 CN951 L906 D902 NR901 NR902 BEAD T951 L952 RJ901 L953 PFC CHOKE FMX-G26S 5A/3   5A/3  ...
  • Page 50 32″ LCD TV AOC L32W431 Q801 L801 AO4411 22uH C802 R804 1uF/25V D801 1/4W C806 C807 C808   470uF/10V 470uF/10V SSM54 1000PF IC801 C810 LM3485 1000PF PGATE R801 C803 C801   1/16W 1000PF PWGND AGND CN801 220uF/25V ISENSE R802 C804...
  • Page 51: Tuner Board

    32″ LCD TV AOC L32W431 9.3 Tuner Board L111 5V_A JACK J101 COMP_L1 600 OHM R131   1/16W C131 470pF R133   1/16W AGND R134 L112 U105 PCA9554PW   1/16W R132 SVIDEO_C 0Ω 1/8W 120 OHM L113 R139 10K  ...
  • Page 52 32″ LCD TV AOC L32W431 10uF/16V C120 U104 AV_1 10uF/16V C121 CVBS_SEL_1 AV_2 VIN1 VOUT CVBS_SEL_1 VIN2 VIN3 C101 0.1uF CH_SEL3 CH_SEL4 U104 5V_A C123 CVBS_SEL_I C124 NJM-2244M-PF 0.1uF 10uF/16V AGND L107 600 OHM SUBWOOFER_OUT CN101 R160 0Ω 1/10W JACK...
  • Page 53 32″ LCD TV AOC L32W431 TU100 ANT IN 12V_T R103 10Ω 3W AGND R104 10Ω 3W R120 0Ω 1/10W R122 1KΩ 1/10W R121 0Ω 1/10W C129 C130 100pF 100pF AGND SIF_IN AGND C161 R119 47pF L128 TUNER_OUT U101 R115 75Ω 1/10W 75Ω...
  • Page 54 32″ LCD TV AOC L32W431 AZ1117H-ADJ-E1 L600 12V_T U600 600 OHM VOUT C601 100pF SIF_IN R602 C603 C604 C605 10uF/16V C602 0.1uF 1/16W 0.1uF   10uF C607 AGND R604 C609 C608 L601 1/8W   56pF L602 AGND C606 56pF 600 OHM...
  • Page 55: Exploded View

    32″ LCD TV AOC L32W431 10. Exploded View...
  • Page 56: Bom List

    WIRE HARNESS 095T8014 3D551 WIRE HARNESS 095T8014 8D651 WIRE HARNESS 095T8018 3506 LVDS CABLE 098TRABD1NEACF REMOTE CONTROL FUHUA FQ FOR AOC 0M1T 330 4128 CR3 SCREW 0M1T 330 4128 CR3 SCREW 0M1T 330 6128 CR3 SCREW 0M1T 340 8 47 CR3...
  • Page 57 32″ LCD TV AOC L32W431 0Q1T 340 10128 CR3 SCREW 0Q1T 930 6128 CR3 SCREW 705TQJK0B34050 BACK COVER ASS'Y 705TQJK0F34042 BEZEL ASS'Y 705TQJK0M34026 A4 ASS'Y 705TQJK0P34034 STAND ASS'Y 750TVMN0B1411N PANEL TV 32" B1-L04 CMO ADPF24180A4P ADAPTER ASS`Y CBPF6T1SQ3 MAIN BOARD...
  • Page 58 32″ LCD TV AOC L32W431 037T 546 1 HINGE 0M1T 140 10120 SCREW M4X10 0M1T 330 4128 CR3 SCREW 0Q1T 140 8128 CR3 SCREW 0Q1T 140 10128 CR3 SCREW Q34T1665 GM 1A COVER HINGE W33T4854 RG L STAND MID W33T4855 RG L...
  • Page 59 32″ LCD TV AOC L32W431 C933 067T215L1024NL KY25VB1000M-L 10*25MM C934 067T215L221 4N LOW E.S.R 220UFM 25V C934 067T215L221 4R LOWE.S.R 220UFM 25V C931 067T215L221 6N KY35VB220M-L 8*15MM C955 067T215L471 6N KY35VB470M-L 10*20MM C955 067T215L471 6R LOW E.S.R 470UF +/-20% 35V...
  • Page 60 32″ LCD TV AOC L32W431 U401 056T1133 77ET2 EN29F040A-70JCP U401 056T1133 80ET2 A29040BL-70F PLCC-32 R718 061T152M100 64 10OHM 5% 2W R716 061T152M229 64 2.2 OHM 2W 5% MOF R719 061T152M479 64 4.7 OHM +-5% 2W R717 061T152M479 64 4.7 OHM +-5% 2W...
  • Page 61 32″ LCD TV AOC L32W431 D927 093T 60239 FME-210B T0-220 D927 093T 60245 SP10150 D928 093T 60247 DIODE FME-220A TO-220 SANKEN 0M1T1730 10128 CR3 SCREW 012T 372 2 SILICON Q901 057T 667 17 IRFP460APBF T0-247AC Q901 057T 667 18 STW20NM50...
  • Page 62 32″ LCD TV AOC L32W431 R953 061T0805563 RST CHIPR 56 KOHM +-5% 1/8W R952 061T0805682 RST CHIPR 6.8 KOHM +-5% 1/8W R903 061T0805683 RST CHIPR 68 KOHM +-5% 1/8W R925 061T0805689 RST CHIPR 6.8 OHM +-5% 1/8W R908 061T1206000 RST CHIPR 0 OHM +-5% 1/4W...
  • Page 63 32″ LCD TV AOC L32W431 D926 093T 6432P LL4148 BY PANJIT D929 093T 6432P LL4148 BY PANJIT D944 093T 6432P LL4148 BY PANJIT D945 093T 6432P LL4148 BY PANJIT D946 093T 6432P LL4148 BY PANJIT D947 093T 6432P LL4148 BY PANJIT...
  • Page 64 32″ LCD TV AOC L32W431 U300 056T 615105 AS 7C256A-10TIN TSOP-1 U504 056T 616 3 PT2308S SO-8 PTC U502 056T 628 4 NJW1147M-PF U206 056T 634 2 1 PI5V330SSQE PERICOMQSOP-16 U408 056T 638601 CS4344-CZZ U406 056T 662 4 RCLAMP0514M.TBT U410 056T 662 4 RCLAMP0514M.TBT...
  • Page 65 32″ LCD TV AOC L32W431 RN306 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R RN305 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R RN304 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R RN303 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R...
  • Page 66 32″ LCD TV AOC L32W431 R4020 061T0603101 CHIP 100OHM 1/16W R4021 061T0603101 CHIP 100OHM 1/16W R405 061T0603101 CHIP 100OHM 1/16W R408 061T0603101 CHIP 100OHM 1/16W R410 061T0603101 CHIP 100OHM 1/16W R421 061T0603101 CHIP 100OHM 1/16W R538 061T0603102 CHIP 1K OHM 1/16W...
  • Page 67 32″ LCD TV AOC L32W431 R492 061T0603202 RST CHIPR 2 KOHM +-5% 1/10W R425 061T0603220 CHIP 22OHM 1/16W R424 061T0603220 CHIP 22OHM 1/16W R245 061T0603220 CHIP 22OHM 1/16W R220 061T0603220 CHIP 22OHM 1/16W R216 061T0603220 CHIP 22OHM 1/16W R214 061T0603220...
  • Page 68 32″ LCD TV AOC L32W431 R412 061T0603472 CHIP 4.7KOHM 1/16W R404 061T0603472 CHIP 4.7KOHM 1/16W R455 061T0603472 CHIP 4.7KOHM 1/16W R454 061T0603472 CHIP 4.7KOHM 1/16W R453 061T0603472 CHIP 4.7KOHM 1/16W R451 061T0603472 CHIP 4.7KOHM 1/16W R450 061T0603472 CHIP 4.7KOHM 1/16W...
  • Page 69 32″ LCD TV AOC L32W431 R318 061T0603750 9F CHIP 75OHM 1/16W 1% R319 061T0603750 9F CHIP 75OHM 1/16W 1% R704 061T0603752 RST CHIPR 7.5 KOHM +-5% 1/10W R705 061T0603752 RST CHIPR 7.5 KOHM +-5% 1/10W R545 061T0603820 1F RST CHIPR 8.2 KOHM +-1% 1/10W...
  • Page 70 32″ LCD TV AOC L32W431 C462 065T0603103 32 CHIP 0.01UF 50V X7R C464 065T0603103 32 CHIP 0.01UF 50V X7R C465 065T0603103 32 CHIP 0.01UF 50V X7R C588 065T0603103 32 CHIP 0.01UF 50V X7R C582 065T0603103 32 CHIP 0.01UF 50V X7R...
  • Page 71 32″ LCD TV AOC L32W431 C385 065T0603104 32 CHIP 0.1UF 50V X7R C386 065T0603104 32 CHIP 0.1UF 50V X7R C387 065T0603104 32 CHIP 0.1UF 50V X7R C388 065T0603104 32 CHIP 0.1UF 50V X7R C389 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 72 32″ LCD TV AOC L32W431 C321 065T0603104 32 CHIP 0.1UF 50V X7R C322 065T0603104 32 CHIP 0.1UF 50V X7R C325 065T0603104 32 CHIP 0.1UF 50V X7R C329 065T0603104 32 CHIP 0.1UF 50V X7R C330 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 73 32″ LCD TV AOC L32W431 C481 065T0603150 31 CHIP 15PF 50V NPO C480 065T0603150 31 CHIP 15PF 50V NPO C300 065T0603272 32 CHIP 2700PF 50V X7R C337 065T0603272 32 CHIP 2700PF 50V X7R C3005 065T0603330 31 CHIP 33PF 50V NPO...
  • Page 74 32″ LCD TV AOC L32W431 C574 065T0805475 A5 CHIP 4.7UF 10V X5R C577 065T0805475 A5 CHIP 4.7UF 10V X5R C578 065T0805475 A5 CHIP 4.7UF 10V X5R CP500 065T600M471 8T CHIP ARRAY 470PF 8P C705 067T 312100 6 SMD EC 10UF 35V 85C...
  • Page 75 32″ LCD TV AOC L32W431 C345 067T 4121003XT EC 85℃ CHIP 10UF M 16V C347 067T 4121003XT EC 85℃ CHIP 10UF M 16V C350 067T 4121003XT EC 85℃ CHIP 10UF M 16V C355 067T 4121003XT EC 85℃ CHIP 10UF M 16V...
  • Page 76 32″ LCD TV AOC L32W431 L707 071T 56U601 MA 0805 600 OHM L507 071T 56Z601 CHIP BEAD 600 OHM L401 071T 56Z601 CHIP BEAD 600 OHM L303 071T 56Z601 CHIP BEAD 600 OHM L208 071T 56Z601 CHIP BEAD 600 OHM...
  • Page 77 32″ LCD TV AOC L32W431 R142 061T0603101 CHIP 100OHM 1/16W R140 061T0603101 CHIP 100OHM 1/16W R122 061T0603102 CHIP 1K OHM 1/16W R603 061T0603102 CHIP 1K OHM 1/16W R134 061T0603102 CHIP 1K OHM 1/16W R139 061T0603103 CHIP 10KOHM 1/16W R133 061T0603103...
  • Page 78 32″ LCD TV AOC L32W431 C626 065T0603331 31 CHIP 330PF 50V NPO C625 065T0603331 31 CHIP 330PF 50V NPO C624 065T0603331 31 CHIP 330PF 50V NPO C161 065T0603470 31 CHIP 47PF 50V NPO C636 065T0603471 32 CHIP 470PF 50V NPO...
  • Page 79 32″ LCD TV AOC L32W431 C610 067T 4121013XT EC 85℃ SMD CAP 100UF M 16V C643 067T 4124703XT EC 85℃ SMD CAP 47UF M 16V L128 071T 56U601 BEAD 600 OHM L111 071T 56Z601 CHIP BEAD 600 OHM L115 071T 56Z601...
  • Page 80 32″ LCD TV AOC L32W431 065T0603102 32 GP CHIP 1000PF 50V X7R 065T0603104 32 CHIP 0.1UF 50V X7R 065T0603104 32 CHIP 0.1UF 50V X7R 065T0603104 32 CHIP 0.1UF 50V X7R 065T0805475 A5 CHIP 4.7UF 10V X5R 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608...
  • Page 81 32″ LCD TV AOC L32W431 L951 071T 55 23 BEAD CORE L921 071T 55 23 S FERRITE BEAD K-TYPE L951 071T 55 23 S FERRITE BEAD K-TYPE F901 084T 55 3 FUSE 5A 250V F901 084T 55 4 FUSE 382-5A 250V WICKMANN...
  • Page 82 32″ LCD TV AOC L32W431 E327MTNSW1AC6N Location Part No. Description 026T 800504 3 BARCODE LABEL 036T 600 18107 NONWOVEN FABRTC 040T 581 26646 S/N LABEL 044T3231 15 EVA WASHER 044T6000 4E CARTON 045T 77 3 PE PACKING 045T 77500 RIBBON...
  • Page 83 32″ LCD TV AOC L32W431 KEPF7QAC KEY BOARD 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 077T 600 1GCJ TACT SWITCH TSPB-2 -NP...
  • Page 84 32″ LCD TV AOC L32W431 705TQ734504 BEZEL ASS'Y 033T4977 RG 1L BUTTON FUNCTION 033T4978 1 C LENS_POWER 044T3121510506 SPONGE Q33T4979 ED C LENS REMOTE Q34T1833 KGBAL BEZEL TV37W06-A1 705TQ778001 SPEAKER ASS'Y 078T 451 2A K SPK 8OHM 15W KUAIDA Q12T7032 1...
  • Page 85 32″ LCD TV AOC L32W431 L952 073L 174 47LSG LINE FILTER L904 073L 174 49LSG LINE FILTER L905 073L 174 52LSG CHOKE COIL L902 073L 253156 LH CHOKE COIL L901 073L 253156 LH CHOKE COIL L903 073T 174 68 L...
  • Page 86 32″ LCD TV AOC L32W431 R802 061T0603620 2F RST CHIPR 62 KOHM +-1% 1/10W R804 061T1206220 RST CHIPR 22 OHM +-5% 1/4W C803 065T0603102 32 CHIP 1000PF 50V X7R C804 065T0603102 32 CHIP 1000PF 50V X7R C809 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 87 32″ LCD TV AOC L32W431 R923 061T1206100 4F RST CHIPR 1 MOHM +-1% 1/4W R924 061T1206100 4F RST CHIPR 1 MOHM +-1% 1/4W R968 061T1206101 RST CHIPR 100 OHM +-5% 1/4W R962 061T1206102 RST CHIPR 1 KOHM +-5% 1/4W R926...
  • Page 88 32″ LCD TV AOC L32W431 D947 093T 6432V LL4148-GSO8 SMD BY VISHA D949 093T 6432V LL4148-GSO8 SMD BY VISHA D950 093T 6432V LL4148-GSO8 SMD BY VISHA ZD921 093T 39S 10 T RLZ6.8B LLDS ZD944 093T 39S 15 T RLZ15B ZD943 093T 39S 24 T RLZ 5.6B LLDS...
  • Page 89 32″ LCD TV AOC L32W431 R716 061T152M229 64 2.2 OHM 2W 5% MOF R717 061T152M479 64 4.7 OHM +-5% 2W R719 061T152M479 64 4.7 OHM +-5% 2W R524 061T153M109 59 MOFR 1 OHM +-5% 3W R525 061T153M109 59 MOFR 1 OHM +-5% 3W...
  • Page 90 32″ LCD TV AOC L32W431 Q708 057T 417 4 CHIP PMBS3904 BY PHILIPS Q706 057T 417 4 CHIP PMBS3904 BY PHILIPS Q705 057T 417 4 CHIP PMBS3904 BY PHILIPS Q704 057T 417 4 CHIP PMBS3904 BY PHILIPS Q502 057T 417 4...
  • Page 91 32″ LCD TV AOC L32W431 R536 061T0603000 CHIP 0OHM 1/16W R423 061T0603000 CHIP 0OHM 1/16W R4004 061T0603000 CHIP 0OHM 1/16W R348 061T0603000 CHIP 0OHM 1/16W R347 061T0603000 CHIP 0OHM 1/16W R311 061T0603000 CHIP 0OHM 1/16W R300 061T0603000 CHIP 0OHM 1/16W...
  • Page 92 32″ LCD TV AOC L32W431 R340 061T0603102 CHIP 1K OHM 1/16W R309 061T0603102 CHIP 1K OHM 1/16W R308 061T0603102 CHIP 1K OHM 1/16W R307 061T0603102 CHIP 1K OHM 1/16W R223 061T0603102 CHIP 1K OHM 1/16W R332 061T0603103 CHIP 10KOHM 1/16W...
  • Page 93 32″ LCD TV AOC L32W431 R424 061T0603220 CHIP 22OHM 1/16W R425 061T0603220 CHIP 22OHM 1/16W R426 061T0603220 CHIP 22OHM 1/16W R428 061T0603220 CHIP 22OHM 1/16W R429 061T0603220 CHIP 22OHM 1/16W R434 061T0603220 CHIP 22OHM 1/16W R473 061T0603221 CHIP 220OHM 1/16W...
  • Page 94 32″ LCD TV AOC L32W431 R404 061T0603472 CHIP 4.7KOHM 1/16W R412 061T0603472 CHIP 4.7KOHM 1/16W R417 061T0603472 CHIP 4.7KOHM 1/16W R418 061T0603472 CHIP 4.7KOHM 1/16W R427 061T0603472 CHIP 4.7KOHM 1/16W R433 061T0603472 CHIP 4.7KOHM 1/16W R435 061T0603472 CHIP 4.7KOHM 1/16W...
  • Page 95 32″ LCD TV AOC L32W431 R705 061T0603752 RST CHIPR 7.5 KOHM +-5% 1/10W R704 061T0603752 RST CHIPR 7.5 KOHM +-5% 1/10W R545 061T0603820 1F RST CHIPR 8.2 KOHM +-1% 1/10W R478 061T0603822 RST CHIPR 8.2 KOHM +-5% 1/10W R526 061T0805000...
  • Page 96 32″ LCD TV AOC L32W431 C489 065T0603103 32 CHIP 0.01UF 50V X7R C490 065T0603103 32 CHIP 0.01UF 50V X7R C449 065T0603103 32 CHIP 0.01UF 50V X7R C454 065T0603103 32 CHIP 0.01UF 50V X7R C455 065T0603103 32 CHIP 0.01UF 50V X7R...
  • Page 97 32″ LCD TV AOC L32W431 C4001 065T0603104 32 CHIP 0.1UF 50V X7R C362 065T0603104 32 CHIP 0.1UF 50V X7R C363 065T0603104 32 CHIP 0.1UF 50V X7R C364 065T0603104 32 CHIP 0.1UF 50V X7R C365 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 98 32″ LCD TV AOC L32W431 C479 065T0603104 32 CHIP 0.1UF 50V X7R C478 065T0603104 32 CHIP 0.1UF 50V X7R C732 065T0603104 32 CHIP 0.1UF 50V X7R C734 065T0603104 32 CHIP 0.1UF 50V X7R C736 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 99 32″ LCD TV AOC L32W431 C317 065T0603104 32 CHIP 0.1UF 50V X7R C314 065T0603104 32 CHIP 0.1UF 50V X7R C313 065T0603104 32 CHIP 0.1UF 50V X7R C305 065T0603104 32 CHIP 0.1UF 50V X7R C304 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 100 32″ LCD TV AOC L32W431 C709 065T0805105 12 1UF +-10% 16V X7R C559 065T0805105 22 CHIP 1UF 25V X7R 0805 C563 065T0805225 12 CHIP 2.2UF 16V X7R 0805 C3004 065T0805475 A5 CHIP 4.7UF 10V X5R C5004 065T0805475 A5 CHIP 4.7UF 10V X5R...
  • Page 101 32″ LCD TV AOC L32W431 C761 067T 4121003XT EC 85℃ CHIP 10UF M 16V C757 067T 4121003XT EC 85℃ CHIP 10UF M 16V C756 067T 4121003XT EC 85℃ CHIP 10UF M 16V C750 067T 4121003XT EC 85℃ CHIP 10UF M 16V...
  • Page 102 32″ LCD TV AOC L32W431 L502 071T 56G301 EA CHIP BEAD 300 OHM 0805 L503 071T 56G301 EA CHIP BEAD 300 OHM 0805 L720 071T 56G301 EA CHIP BEAD 300 OHM 0805 L719 071T 56G301 EA CHIP BEAD 300 OHM 0805...
  • Page 103 32″ LCD TV AOC L32W431 SMTIRPF6QA9P IR BOARD FOR SMT 057T 417 6 PMBS3906/PHILIPS-SMT 061T0603101 CHIP 100OHM 1/16W 061T0603103 CHIP 10KOHM 1/16W 061T1206301 RST CHIPR 300 OHM +-5% 1/4W 061T1206331 RST CHIPR 330 OHM +-5% 1/4W 065T0603102 32 GP CHIP 1000PF 50V X7R 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 104 32″ LCD TV AOC L32W431 RN103 061T 125473 8 RST CHIP AR 8P4R 47 KOHM +-5% 1/16W RN102 061T 125473 8 RST CHIP AR 8P4R 47 KOHM +-5% 1/16W RN101 061T 125473 8 RST CHIP AR 8P4R 47 KOHM +-5% 1/16W...
  • Page 105 32″ LCD TV AOC L32W431 C159 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C156 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C157 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C628 065T0603104 32 CHIP 0.1UF 50V X7R C612 065T0603104 32 CHIP 0.1UF 50V X7R...
  • Page 106 32″ LCD TV AOC L32W431 C162 067T 4121003XT EC 85℃ CHIP 10UF M 16V C602 067T 4121003XT EC 85℃ CHIP 10UF M 16V C603 067T 4121003XT EC 85℃ CHIP 10UF M 16V C613 067T 4121003XT EC 85℃ CHIP 10UF M 16V...
  • Page 107: Different Parts List

    32″ LCD TV AOC L32W431 ZD101 093T 39S 34 T UDZSNP5.6B ROHM ZD100 093T 39S 34 T UDZSNP5.6B ROHM 715T2275 3 TUNER BOARD PCB 001T6017 2 SCREW Q41T320167323A MANUAL Q41T7800615A92 WARRANTY CARD Q45T 76 28CK2 PE BAG 040T 581 26646...
