  • Page 1     PlugLink 500 Wireless “N”Adapter User’s Guide PL9571-WAP 66-0377-01Rev.001...
  • Page 2 Asoka USA Corporation. Asoka USA Corporation reserves the right to make changes to this user’s guide at any time without notice and assumes no responsibility for its use. Asoka USA products and services can only be ordered under the terms and conditions of Asoka USA Corporation's applicable agreements.
  • Page 3 You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Asoka equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: Turn the television or radio antenna until the interference stops.

  • Page 4: Contact Information

    Contact Information For more information about the PlugLink 500 Wireless “N” Adapter or any of Asoka’s other leading-edge solutions, please contact us using any of the following methods: • Voice calls: (408) 550-8167 - We welcome your calls Monday through Friday, from 9:00 am to 5:00 pm Pacific Time.

  • Page 5: Table Of Contents

    Table of Contents Chapter 1  .............................  3   Introduction ..........................  3   Chapter 2  .............................  4   Important Safety Instruction  ....................  4   Chapter 3  .............................  5   Learning about PL9571  ......................  5   Chapter 4  .............................  8   Preparing to Install ........................ ...

  • Page 6: Chapter 1

    Introduction Thank you for purchasing a PlugLink 500 Wireless “N” Adapter from Asoka. This adapter lets you extend an existing Powerline network allowing you to set up an instant wireless hotspot simply by plugging into a power outlet. With your PlugLink 500 Wireless “N” Adapter, you...

  • Page 7: Chapter 2

    Chapter 2   Important Safety Instruction The following precautions should be taken when using this product: • Read all instructions before installing and operating this product. • Do not open the cover or casing on this product and/or alter this product in any way.

  • Page 8: Chapter 3

    The Front Panel The front panel of the PL9571-WAP Adapter contains the status lights described below. Figure 3-1: PL9571-WAP Front Panel You can use the status lights to verify connections. Viewed from top to bottom, left to right, the table describes the lights on the front panel of the unit.

  • Page 9: The Bottom Panel

    The Bottom Panel The bottom panel of the PL9571-WAP two (RJ-45) ports shown in figure 3-2. Figure 3-2: PL9571-WAP Bottom Panel The Rear Panel The label on the rear panel of the PL9571-WAP Adapter contains the items listed below. Model number...
  • Page 10 SW2 (Front) Button / WPS Wireless and power- Key reuse, and the button at different times, said two functions. This button allows you to configure wireless security by simply pushing a button. This requires software and a network adapter that supports this feature.

  • Page 11: Chapter 4

    10/100BaseT Ethernet-capable device. To setup a PLC (PowerLine Communication) Network you will need: One (1) PL9571-WAP device One (1) PL9660-Q1 device (sold separately) Standard Cable/ DSL gateway (provided by your ISP) Figure 4-1: Connecting PL9571-WAP with PL9661-ETH diagram Page 8 of 38 ...

  • Page 12: Chapter 5

    Chapter 5 Installing PL9571 Do not connect the PlugLink 500 Wireless “N” Adapter to a power strip, extension cord, uninterruptible power supply (UPS), or surge protector. This may prevent the unit from working property or degrade the network performance. Plug the PlugLink 500 Wireless “N” Adapter into the wall outlet vertically (right side up).
  • Page 13 5. From your computer scan your Wireless Network Connections to look for your PlugLink 500 Wireless “N” Adapter’s network name (SSID). The default name (SSID) of the PlugLink 500 Wireless “N” Adapter is Asoka. You will be prompted for your “Encryption Key”. The default Encryption Key is the last 10 digits of the serial number.

  • Page 14: Chapter 6

    Figure 6-1: Login Address For security, the PL9571-WAP has its own user ID and password. When prompted, enter admin for the user ID, welcome for the password, both in lower case letters, and press Login. To change the login password, see “Setting or Changing the Administrative Login Information”...
  • Page 15 3. The first time the login screen opens, use the default user name admin and password welcome. Click Login (Note that user accounts are managed in User Account Management and can be changed after the first login.) The web interface opens to the basic devices information. Page 12 of 38 ...

  • Page 16: Chapter 7

    Chapter 7 Basic Configuration Working mode Middleware-enabled platforms have two operation modes: To configure AP mode using the router (router build only): 1. Choose the NETWORK tab to open the Network Connection Settings: 2. Select Enable Access Point Mode. A confirmation box appears. Click OK. 3.
  • Page 17 A confirmation screen appear, the router will now work in Router Mode. To configure router mode using the Ap: unselect the check box Enable Access Point Mode. To add a PPPoE internet connection: See “To set the router IP address” on page 24 for how to configure the router to the Internet connection.
  • Page 18 4. Enter the user name and password provided by the ISP. Leave Name of Service blank if unsure. 5. Select the preferred dial-up style under Dial-up Method. 6. Click Save to commit the changes. To add a DHCP internet connection: 1.
  • Page 19 Wireless LAN (WLAN) Setup Set up a WLAN either manually or by using WiFi protected setup (WPS). WPS allows easy setup of client devices that support WPS. Choose the NETWORK tab, then choose the WLAN SETTINGS tab to open the Radio Settings screen. Note that WPS configures one client device at a time.
  • Page 20 Figrure7-2 WPS Setup Screen To user automatic automatic WPS configuration: 1. Under the Wireless Security Mode section of the WPS setup screen: In the WPS Configured drop-down menu, choose Yes. For a client device with a WPS button: click the WPS button on the client 　...
  • Page 21 2. Click Save to commit the changes. To use manual WLAN configuration: 1. Enable the radio under the radio settings section of WLAN settings: 2. Select the mode, channel, and transmission power levels. 3. Click Save to commit the changes. In radio settings, click >>Show Advanced Setting to show more radio settings: View the basic wireless settings on the wireless settings screen.
  • Page 22 View the wireless security mode settings on the WLAN settings screen:             Page 19 of 38 ...

  • Page 23: Chapter 8

    Chapter 8 Advanced Configuration  3.2.1 Local Area Network (LAN) Settings Choose the NETWORK tab to open the Network Connection Settings, LAN SETTINGS to open the LAN Settings screen: To set the router IP address 1. Under LAN settings, enter the router IP address and subnet mask. 2.
  • Page 24 1. Under Reserved IP Address List, click New Reserved IP: 2. Fill in the MAC address and IP address. 3. Click Save to commit the changes. To delete a reserved IP: 1. Under Reserved IP Address List, click Delete Reserved IP:. 2.
  • Page 25 firewall feature,then set the firewall level as appropriate 2. Click Save to commit the changes. To edit the DOS attack protection settings: 1. Under DOS Attack Protection Settings, select Enable or Disable to enable or disable the DOS attack protection feature. 2.
  • Page 26 security (IPSEC), session initiation protocol (SIP). To enable an ALG: 1. Check a specific ALG to enable it. 2. Click Save to commit the changes. To enable a DMZ host: Under NAT - DMZ Host, click Enable DMZ host and enter the DMZ host address. 3.2.15 UPnP (Router Build Only) Click the APPLICATION tab and click UPNP CONFIGURATION to access the UPnP Settings...
  • Page 27 1. IGMP snooping requires an existing Internet connection. Check Enable IGMP. 2. Click Save to commit the changes. Status Information 1 Device Information Click the STATUS tab to show the basic device information, including the Device Model/ID and the hardware/software version. 2 Network Status Click the STATUS tab and choose NETWORK INFORMATION to show the network- related information.
  • Page 28 3 Wireless/Ethernet/USB Information Click the STATUS tab and choose USER INFORMATION to show the LAN-side, Ethernet, and USB information. Page 25 of 38 ...
  • Page 29 4 Hybrid Network Setting (APH126 Only) Hybrid networking involves effective use of both wired and wireless technologies to provide seamless connectivity solutions that offer end-users a flexibility and performance within the home. For carriers and retailers, hybrid solutions deliver more reliability and fewer customer service calls.
  • Page 30 2. Under Hybrid Path Transmition Method drop-down menu, select “None” for default mode, select “SEAMLESS” for seamless path switching. 3. Select the hybrid interfaces WiFi interface setting. Note that for the WIFI interface, only one SSID can be set for each radio. 　...
  • Page 31 Service Pack 3, Windows 2000 with Service Pack 4, and Windows Vista include the client software that supports WPA/WPA2. Nevertheless, the wireless adapter hardware and driver must also support WPA/WPA2. The PL9571-WAP provides the following levels of security: Open, WEP, WPA- Personal, WPA-Enterprise, WPA2-Personal and WPA2-Enterprise. Page 28 of 38 ...
  • Page 32 No wireless security enabled. WEP offers the following options: • Open System With Open Network Authentication and 64- or 128- bit WEP data encryption, the PL9571-WAP does perform 64- or 128-bit data encryption but does not perform any authentication • Shared Key Shared Key authentication encrypts the SSID and data.
  • Page 33 Configuring Wireless Security By default, the PL9571-WPA security options are enabled. The default security type is set to WPA2-Personal AES; and its security key is the last 10 digits of the PL9571’s serial number shown on the label. The security options should be configured by advanced users only.
  • Page 34 How the NID and WPS-Push Button can be used Following is an example of how the NID button can be used: Select a PlugLink 9571 device in your network. Press and hold the NID button for 10 seconds. After about 10 seconds, the lights on your device will blink off briefly and come back on immediately.
  • Page 35 b) If the c urrent wir eless netw work was c created b by WPS: The PL957 71 will use the curren nt SSID/wi ireless pas ssword an retain the current c clients’ con nnections s in the wire eless netw work.

  • Page 36: Chapter 9

    Chapter 9 Technical Support PLEASE REFER TO THE WARRANTY AND SUPPORT INFORMATION CARD THAT WAS SHIPPED WITH YOUR PRODUCT. By registering your product at www.asokatech.com/register, we can provide you with faster expert technical support and timely notices of product and software upgrades. Support Information Phone: 1-408-550-8167 Email: support@asokatech.com...

  • Page 37: Chapter 10

    Chapter 10 Technical Specifications Forward Error Correction (FEC) Standards Compliance Automatic Channel HomePlug® AV Adaptation IEEE 1901, IEEE 802.3, IEEE 802.11b/g/n Power Supply US Version: 100-120VAC System Requirements UK/EU Version: 220-240VAC Windows® 98, 2000, XP , Vista and Windows 7 Power Rating US Version: 100-120VAC 0.25A, Network Protocol...

  • Page 38: Chapter 11

    Chapter 11 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 39: Chapter 12

    This warranty extends only to you, the original purchaser and is not transferable to any subsequent purchasers. This warranty does not apply if, in the judgment of Asoka, the product fails due to damage from shipment, handling, storage, accident, abuse,...
  • Page 40 WHILE ASOKA HAS MADE EVERY EFFORT TO PROVIDE CLEAR AND ACCURATE TECHNICAL INFORMATION ABOUT ITS PRODUCTS, ASOKA ASSUMES NO LIABILITY FOR ANY EVENTS ARISING OUT OF THE USE OF THE TECHNICAL INFORMATION OR THE PRODUCT. EXCEPT AS SPECIFICALLY PROVIDED IN THIS...
  • Page 41 Asoka USA Corporation 2620 Augustine Drive Suite 230 230 Santa Clara, California 95054 USA Phone: (408) 550–8167 Fax: (408) 884–2390   www.asokatech.com             66-0377-01Rev.001 Page 38 of 38...
