ULTRA-MAX™ GAS GRIDDLE MODELS
GRILS A GAZ ULTRA-MAX MODELES
824M
836M
848M
860M
872M
WARNING:
Improper installation,
adjustment, alteration, service or
maintenance can cause property
damage, injury or death.
installation, operating and maintenance
instructions thoroughly before installing
or servicing this equipment.
AVERTISSEMENT: L'installation inexacte, le réglage,
le changement, le service ou l'entretien peuvent
causer des dégats matériels, des dommages ou la
mort. Lisez les instructions d'installation, d'opération
et d'entretien complètement avant d'installer ou
entretenir ce matériel.
FOR YOUR SAFETY:
use gasoline or other flammable vapors or
liquids in the vicinity of this or any other
appliance.
POUR VOTRE SÛRETÉ: N'enregistrez pas ou
n'utilisez pas l'essence ou d'autres vapeurs ou
liquides inflammables à proximité de ceci ou d'aucun
autre appareil.
Star
Manufacturing
International Inc.
0 Sunnen Drive
St. Louis, MO 6343
Phone: (800) 264-7827
Fax: (34) 78-274
824T
836T
848T
860T
872T
Read the
Do not store or
824TS
836TS
848TS
860TS
872TS
WARNING:
This appliance shall be
installed in accordance with current
regulations and used only in well-
ventilated space. Refer to instructions
before installing and using this
appliance.
AVERTISSEMENT: Cet appareil sera installé
selon des règlements actuels et utilisé
seulement dans l'espace bien-aéré. Référez-
vous aux instructions avant d'installer et utiliser
cet appareil.
In addition, there should be posted, in a
prominent location, detailed instructions
to be followed in the event the operator
smells gas. Obtain the instructions from
the local gas supplier.
En outre, là devrait être signalé, dans un
emplacement en avant, des instructions détaillées
d'être suivi en cas que l'opérateur sent le gaz.
Obtenez les instructions du fournisseur local de
gaz.
Installation and
Operating Instructions
Instructions d'installation
et d'opération
2M-Z4877 Rev. G 6/23/20
824TSCHS
836TSCHS
848TSCHS
860TSCHS
872TSCHS
Advertisement
Table of Contents
Related Manuals for Star Manufacturing 824M
Summary of Contents for Star Manufacturing 824M
- Page 1 Instructions d’installation 0 Sunnen Drive St. Louis, MO 6343 et d’opération Phone: (800) 264-7827 Fax: (34) 78-274 2M-Z4877 Rev. G 6/23/20 ULTRA-MAX™ GAS GRIDDLE MODELS GRILS A GAZ ULTRA-MAX MODELES 824M 824T 824TS 824TSCHS 836M 836T 836TS 836TSCHS 848M 848T...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: Specifications
IL2241 SPECIFICATIONS Dimensions Approx Weight Model Type Controls BTUH Griddle Area Width Depth Height Installed Shipping 214lbs 244lbs 824M Manual Valve (97kg) (110.6kg) 573 sq in 24" 220lbs 246lbs 824T/TM Throttling Control 60,000 (3697sq. cm) (61cm) (99.7kg) (111.5kg) 824TS Snap Action Control... -
Page 4: General Installation Data
GENERAL INSTALLATION DATA This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. CAUTION Before using your new equipment, read and understand all the instructions &... -
Page 5: Leveling Unit
LEVELING UNIT This griddle is supplied with 4 feet or floor stand legs which must be screwed into the body. After the griddle is in its final position, adjust the legs to create 1/8 inch slant from back to front. This will allow the grease to run into the grease gutter and provide the proper combustion air for the burners. - Page 6 GAS PIPING Gas piping shall be of such size and so installed as to provide a supply of gas sufficient to meet the full gas input of the appliance. If the appliance is to be connected to existing piping, it shall be checked to determine if it has adequate capacity.
-
Page 7: Pilot Flame Adjustment
PILOT FLAME ADJUSTMENT The griddles are equipped with standing pilots and should be lit immediately after the gas is turned on. MANUAL VALVE AND THROTTLING CONTROL MODELS Adjust the flame as low as possible while still providing immediate burner ignition when the control knob is turned to high. -
Page 8: Burner Air Shutter Adjustment
BURNER AIR SHUTTER ADJUSTMENT The burner air shutter has a locking screw on the bottom side of the venturi. Loosen this screw to make any adjustment and tighten the screw to lock the air shutter in place after adjustment is com- plete. -
Page 9: Griddle Care (Chrome Surfaces)
GRIDDLE CARE (NON-CHROME SURFACES) It takes very little time and effort to keep the griddle attractive and performing at top efficiency. If grease is permitted to accumulate, it will form a gummy cake and then carbonize into a hard substance which is extremely difficult to remove. - Page 10 years against manufacturing defects to the original owner from the date of installation. This limited warranty is void if it is determined by Star Manufacturing International Incor- porated or one of its authorized representatives that the chrome surface has been misused or abused or subjected to the following situations: Improperly installed.
-
Page 11: Entretien Et Réparations
Dû aux modifi cations périodiques de dessins, méthodes, procédures, règles et régulations, les spécifi cations contenues dans ce manuel sont susceptibles de changer sans préavis. Quoique STAR Manufacturing exerce la bonne foi de fournir le renseignement correct, STAR n’est pas responsable pour les erreurs ou les omissions dans le renseignement pourvu ou les conclusions tirées à... - Page 12 DONNÉES GÉNÉRALES D’INSTALLATION NOTIFICATION ATTENTION Quand cet appareil est installé avec des roulettes, il doit être installé avec les roulettes fournies, un connecteur étant conforme à la norme ANSI Ce matériel est conçu et vendu pour l’usage Z21.69 ou au CAN/CGA-6.16 et à un dispositif commercial seulement par le personnel qualifié...
- Page 13 RASANT DE L'UNITÉ ATTENTION Cette plaque en fonte est fournie 4 pieds ou jambes d'éventaire d'étage qui doivent être vissées N’INSTALLEZ PAS SANS ATTACHER ES dans le corps. Après que la plaque en fonte est PIEDS OU DES JAMBES ET L'ETAGERE dans sa position finale, régler les jambes pour FOURNIES DE STAND.
- Page 14 TUYAUTERIE À GAZ GAZ PROPANE - CONVERSION La taille de la tuyauterie à gaz et la façon dont elle Cette gauffreuse est équipée des capots fixes est installée doivent être telles qu’elle fournisse d’orifice et est expédiée de l’usine pour l’usage avec une alimentation suffisante de gaz pour répondre le gaz naturel.
- Page 15 ALLUMER DES INSTRUCTIONS MODÈLES EXTÉRIEURS INSTANTANÉS Quand la gauffreuse est d’abord allumée, il fum- DE THERMOSTAT ET DE CHROME era jusqu’à ce que les huiles et les impuretés de D’CAction Ajustez le pilote tellement ap- préservatif soient consommation. Les gauffreuses proximativement 3/8 “...
- Page 16 CONNEXION ÉLECTRIQUE POUR L’CAction CUISINE INSTANTANÉE ET LES MODÈLES EXTÉRIEURS Placez la molette de cadran à la configuration désirée. DE CHROME SEULEMENT Après une période de préchauffage de 30 minutes Des grils extérieurs instantanés d’action et de (minimum), le gril mettra à jour automatiquement chrome sont équipés d’une trois-fourche fondant la température choisie.
- Page 17 Cette 3. Suivez les étapes 2 et 3 du soin de gril (non garantie limitée est vide si elle est déterminée par Star Manufacturing International Incorporated ou surfaces de chrome). un de ses représentants autorisés que la surface de chrome a été...
- Page 18 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation company who delivered the item to you and initiate your claim with same.
- Page 20 NAMEPLATE REFER TO THE PARTS LIST SPECIFIC TO YOUR MODEL FOR MORE DETAIL INFORMATION. Model: 800 SERIES STAR MANUFACTURING INTERNATIONAL, INC. SK1878 REV B 3-30-09...
-
Page 21: Parts List
PARTS LIST June 23, 20, Rev G Ultra-Max Gas Griddle Models: 824M, 824T, 824TS, 824TM, 824TSCHS Fig. No Part No. Description Application G5-Z4812 FLUE 824M/T/TS/TSCHS G5-824004 824M G5-824005 824T/TS GRIDDLE PLATE ASSY COMPLETE G5-824006 824TSCHS G5-Z4793 BULB CLAMP 824T/TS/TSCHS G5-Z4794... - Page 22 PARTS LIST June 23, 20, Rev G Ultra-Max Gas Griddle Models: 836M, 836T, T36TS, 836TSCHS Fig. No Part No. Description Application G5-Z4813 FLUE 836M/T/TS/TSCHS G5-Z4817 FLUE DIVIDER 836M/T/TS/TSCHS G5-836004 836M G5-836005 GRIDDLE PLATE ASSY COMPLETE 836T/TS G5-836006 836TSCHS G5-Z4793 BULB CLAMP 836T/TS/TSCHS G5-Z4794 BULB COVER...
- Page 23 PARTS LIST June 23, 20, Rev G Ultra-Max Gas Griddle Models: 848M, 848T, 848TS, 848TSCHS Fig. No Part No. Description Application G5-Z4814 FLUE 848M/T/TS/TSCHS G5-Z4817 FLUE DIVIDER 848M/T/TS/TSCHS G5-848004 848M G5-848005 GRIDDLE PLATE ASSY COMPLETE 848T/TS G5-848006 848TSCHS G5-Z4793 BULB CLAMP 848T/TS/TSCHS G5-Z4794 BULB COVER...
- Page 24 PARTS LIST June 23, 20, Rev G Ultra-Max Gas Griddle Models: 860M, 860T, 860TS, 860TSCHS Fig. No Part No. Description Application G5-Z4815 FLUE 860M/T/TS/TSCHS G5-Z4817 FLUE DIVIDER 860M/T/TS/TSCHS G5-860004 860M G5-860005 GRIDDLE PLATE ASSY COMPLETE 860T/TS G5-860006 860TSCHS G5-Z4793 BULB CLAMP 860T/TS/TSCHS G5-Z4794 BULB COVER...
- Page 25 PARTS LIST June 23, 20, Rev G Ultra-Max Gas Griddle Models: 872M, 872T, 872TS, 872TSCHS Fig. No Part No. Qty Description Application G5-Z4816 FLUE 872M/T/TS/TSCHS G5-Z4817 FLUE DIVIDER 872M/T/TS/TSCHS G5-872004 872M G5-872005 GRIDDLE PLATE ASSY COMPLETE 872T/TS G5-824006 872TSCHS G5-Z4793 BULB CLAMP 872T/TS/TSCHS G5-Z4794...
- Page 28 PARTS LIST June 23, 20, Rev G 800M and 800T Series MODEL Number Part Description Number Number Model Unit 2K-Z490 MANIFOLD 824M/T 2K-Z4902 MANIFOLD 836M/T 2K-Z4903 MANIFOLD 848M/T 2K-Z4904 MANIFOLD 860M/T 2K-Z490 MANIFOLD 872M/T 2K-Z492 BURNER FLEX TUBE 824M/T BURNER FLEX TUBE...
- Page 31 PARTS LIST June 23, 20, Rev G 824TS and 824TSCHS Series MODEL Number Part Description Model Number Number Unit 2K-Z4921 824TS/TSCHS BURNER FLEX TUBE 2K-2675 824TS/TSCHS FITTING 3/8 CC X 3/8 MPT 2P-1453 824TS/TSCHS PIPE PLUG 2K-Y5550 824TS/TSCHS NIPPLE 3/8 NPT X 1 1/2 2K-2665 824TS/TSCHS ELBOW 3/8 NPT...
- Page 33 PARTS LIST June 23, 20, Rev G 836TS and 836TSCHS Series MODEL Number Part Number Number Description Model Unit 2K-Z4921 836TS/TSCHS BURNER FLEX TUBE 2K-2675 836TS/TSCHS FITTING 3/8 CC X 3/8 MPT 2P-1453 836TS/TSCHS PIPE PLUG 2K-Y5550 836TS/TSCHS NIPPLE 3/8 NPT X 1 1/2 2K-2665 836TS/TSCHS ELBOW 3/8 NPT...
- Page 35 PARTS LIST June 23, 20, Rev G 848TS and 848TSCHS Series MODEL Number Part Description Model Number Number Unit 2K-Z4921 848TS/TSCHS BURNER FLEX TUBE 2K-2675 848TS/TSCHS FITTING 3/8 CC X 3/8 MPT 2P-1453 848TS/TSCHS PIPE PLUG 2K-Y5550 848TS/TSCHS NIPPLE 3/8 NPT X 1 1/2 2K-2665 848TS/TSCHS ELBOW 3/8 NPT...
- Page 37 PARTS LIST June 23, 20, Rev G 860TS and 860TSCHS Series MODEL Part Model Number Description Number Number Per Unit 2K-Z492 860TS/TSCHS BURNER FLEX TUBE 2K-267 860TS/TSCHS FITTING 3/8 CC X 3/8 MPT 2P-43 860TS/TSCHS PIPE PLUG 2K-Y0 860TS/TSCHS NIPPLE 3/8 NPT X /2 2K-266 860TS/TSCHS ELBOW 3/8 NPT...
- Page 39 PARTS LIST June 23, 20, Rev G 872TS and 872TSCHS Series MODEL Part Model Number Description Number Number Per Unit 2K-Z492 872TS/TSCHS BURNER FLEX TUBE 2K-267 872TS/TSCHS FITTING 3/8 CC X 3/8 MPT 2P-43 872TS/TSCHS PIPE PLUG 2K-Y0 872TS/TSCHS NIPPLE 3/8 NPT X /2 2K-266 872TS/TSCHS ELBOW 3/8 NPT...
- Page 40 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 781-2777 www.star-mfg.com...
