S t a r M a n u f a c t u r i n g I n t e r n a t i o n a l , I n c .
STAR-MAX
THERMOSTATIC CONTROLS
Models 615TD, 624TD, 636TD & 648TD

Features/Benefits:

Throttling thermostat adjusts from 150° to 450°F providing
quick response to surface temperature change.
Available in 15", 24", 36" and 48" widths to meet your space
and volume requirements.
Highly polished 3/4" thick polished steel plate for superior heat
distribution, fast recovery and energy efficient operation.
Custom designed 20,000 BTU aluminized U-shaped steel
burner every 12" of cooking surface provide even heat
distribution.
Heavy-duty all-welded body construction with stainless steel
front, bull nose and 4-1/2" high tapered splash guard.
Spatula wide 3-1/4" front grease trough and grease chute for
easy cleaning.
Large 4-1/2 quart stainless steel grease drawer.
Gas convertible in the field conversion kit supplied. Units are
shipped Natural Gas.
Heavy-duty 4" adjustable legs to fit your countertop line-up
requirements.
A p p l i c a t i o n s :
Star-Max thermostatically controlled griddles provide maximum
cooking performance and reliability. Breakfast, lunch or dinner,
Star has a griddle to fit your menu needs.

Quality Construction:

Star-Max griddles feature 3/4" thick polished steel griddle plate
with 4-1/2" high wrap-around stainless steel splash guard and 3-
1/4" wide front access grease trough with 4-1/2 quart grease draw-
er capacity. Includes a 20,000 BTU aluminized burner every 12"
of width controlled by a throttling thermostatic, 3/4" N.P.T. male
gas connection with convertible pressure regulator, and 4"
adjustable legs. These units are approved for installation within 6"
of non-combustible surfaces. Griddles operate on Natural or
Propane gas.
Wa r r a n t y :
Star-Max gas griddles are covered by Star's one year parts and
labor warranty.
Star Manufacturing International Inc. - 10 Sunnen Drive - P.O. Box 430129 - St. Louis, MO 63143-3800
GAS GRIDDLES WITH
®
Phone: (800) 264-7827 - FAX: (800) 264-6666 - www.star-mfg.com
Model 648TD
Model 648TD
with Optional Equipment Stand
S202/0106
