Aparton SPD-3.4 User Manual

The alarms are designed to detect smoky fires and issue both sound and light alarm notifications.
The alarm operates as a standalone unit powered from batteries DURACELL MN1604 (6LR61) or equal
one. It can be used in residential and industrial premises.
The alarms can be interconnected with the help of two-wire line that allows to protect maximum number
of enclosed premises and to hear alarm sound in remote premises. The arrangement of collective fire
protection of a few flats is possible.
Complies with EN 14604:2005
Features:
• Indication of standby mode (LED flashing every 35-45 sec);
• Indication of a low battery status (short sound and light signals every 35-45 sec);
• Indication of a fault or contamination of the alarm (short sound signals every 35-45 sec);
• Indication of alarm mode (loud intermittent sound signal, LED frequent flashing).
• Battery presence control.
1.1 Power voltage, V... ........................................................ 7,5-10,0
1.2 Alarm sound level at 3 m, dB........................................................... 85
1.3 Interlink, pcs..................................................................... 10
1.4 Dimensions, mm.................... .........................................Ø100 48
1.5 Weight (including battery), g................................................... 200
1.6 Operating temperature range, °
1.7 Average lifespan, years....................................................
SPD-3.4 smoke alarm
Manual
Package

3. PREPARING FOR OPERATION, PLACEMENT AND INSTALLATION

3.1 Determine where the alarm will be sited taking into account the following requirements:
- Alarms are ceiling-mounted (not nearer than 10 cm from a wall);
wall-mounted at the distance 10-30 cm from a ceiling.
- It is prohibited to place alarms in bathrooms, shower rooms, W.C., laundries, saunas.
3.2 Unpack the alarm and check the package's content.
3.3 Detach the alarm from a base, turning it anti-clockwise and slightly pressing the rear side.
USER'S
MANUAL
SPD-3.4
BATTERY-OPERATED

SMOKE ALARM

1. TECHNICAL SPECIFICATIONS

......................................... from –10 t 55

2. ITEMS SUPPLIED WITH THE ALARM

Name Quantity Note
1 The base including
1 Per 25 pcs
1 Per 25 pcs
10
