Summary of Contents for Aparton SPD-3.2
- Page 1 ISO 9001:2008 OPTICAL SMOKE DETECTOR SPD-3.2 Model: USER’S MANUAL 1438 Private enterprise "ARTON" 6 Nezalezhnosti ave. Chernivtsi 58029 Ukraine EC-certificate of conformity No: 1438/CPD/0077 EN 54-7 For further information please contact us: +38 0372 584373 www.arton.com.ua...
- Page 2 1. FUNCTIONS 1.1 The SPD-3.2 optical smoke detector is designed to detect smoky fires indoors and to transmit alarm signal to fire alarm control panels. 1.2 The SPD-3.2 detector is counted on the continuous 24-hours operating in connection with fire alarm control panels in 4-wire 12 V fire alarm loops.
- Page 3 5. PLACEMENT AND INSTALLATION 5.1 You should site detectors in places with the following conditions: -minimal vibrations of constructions; -minimal illumination intensity; -maximum distance from sources of electrical-magnetic interferences (electric wiring etc.), infra-red radiation (heat devices); -elimination of water ingress on the case and penetration out of the base; -absence of gas, steam, aerosol emission that can cause corrosion.
- Page 4 2. Screw contact «2» 6. Screw contact «6» 3. Screw contact «3» 4. Screw contact «4» Figure 2 WIRING DIAGRAM FOR SPD-3.2 DETECTORS TO CONTROL PANEL and R are specified by the control panel manufacturer. term QUALITY AND PACKING CERTIFICATE Optical smoke detector, model SPD-3.1M, serial numbers:...
