Pure n Natural Systems FM-2000 User Manual

FM-2000 AIR CLEANER USERS MANUAL

READ AND SAVE THESE INSTRUCTIONS

Pure n Natural Systems, Inc. recommends that a licensed electrician or licensed

WARNINGS:

1. Always unplug or disconnect the air cleaner from power supply before servicing.

2. To reduce the risk of electric shock or injury to persons, do not expose to water or

rain, do not use in a window.

3. Do not use this fan with any solid state speed control device.

1. Pre Filter

2. Carbon Panel Filter

3. H.E.P.A. Filter

Step 1. The Pre Filter is located behind the intake door (service door). The Pre Filter is a

blue and white polyester, pre-tack filter. The intake door is located closest to the

HI/OFF/LO switch on the face of the system. Unclip the two latches on the intake door

and the door will swing down. The Pre Filter is the first filter behind the intake door. Peel

away dirty Pre Filter and discard. Install the new Pre filter with the white side out. Close

door. DO NOT WASH PRE FILTERS.

Step 2. The carbon filter is located behind the Pre Filter. Follow Pre Filter changing

instructions from Step 1. Remove Carbon Filter, discard and replace with new Carbon

Filter. DO NOT WASH CARBON FILTERS.

Step. 3. Remove the adjustable louver door. Remove the H.E.P.A. Bar. The H.E.P.A.

Filter is a pleated media surface with a metal frame. Slip the H.E.P.A. Filter out of the

system, discard and replace with new H.E.P.A. Filter. DO NOT WASH H.E.P.A.

FILTER.

Filter maintenance may vary according to each situation.

For any questions, please contact our customer service department at 1-800-237-9199.

contractor install units.

Replace every 3 to 4 weeks.

Replace at least every 2 months.

Replace at least every 12 months.

Table of Contents

Do you have a question about the FM-2000 and is the answer not in the manual?

Page 1 FM-2000 AIR CLEANER USERS MANUAL READ AND SAVE THESE INSTRUCTIONS Pure n Natural Systems, Inc. recommends that a licensed electrician or licensed contractor install units. WARNINGS: 1. Always unplug or disconnect the air cleaner from power supply before servicing. 2. To reduce the risk of electric shock or injury to persons, do not expose to water or rain, do not use in a window.
Page 2 INSTALLATION OF FM-2000 AIR CLEANER EQUIPMENT: 1. Each FM-2000 unit is equipped with two (2) eye bolts, two (2) eye lags and industrial hanging wire for easy installation. 2. The FM-2000 has a ten foot power cord and a three prong grounded plug.
Page 3 Step 6. Locate a stud in the solid ceiling that is directly above the tile where the system will be installed. Fasten the eye lag into the stud making sure to line up the eye lag with the eye bolts on the system so the hanging wire will hang vertically. Thread the hanging wire through the eye lag so that either side is evenly dispersed.
Page 4 FM-2000 FLUSH MOUNT AIR CLEANER APPLICATION The FM-2000 flushmount Air Cleaner is designed to drop into a suspended ceiling. It replaces either 1 - 2' x 4' tile or 2 - 2' x 2' tiles from the suspended ceiling. In order to install the FM-2000 flushmount easily, the clearance above the suspended ceiling needs to be at least 18"...
