Pure n Natural Systems PR20.0 User Manual

PR20.0 AIR CLEANER USERS MANUAL

Pure n Natural Systems, Inc. recommends that a licensed electrician or licensed contractor

WARNINGS:

1. Always unplug or disconnect the air cleaner from power supply before servicing.

2. To reduce the risk of electric shock or injury to persons, do not expose to water or rain,

do not use in a window.

3. Do not use this fan with any solid state speed control device.

Pre Filter

18 pound Carbon V-Bank Filter

H.E.P.A. Filter

Step 1. The Pre Filter is located behind the intake door (service door). The Pre Filter is a blue and

white polyester, pre-tack filter. The intake door is located closest to the HI/OFF/LO switch on the

face of the system. Unclip the two latches on the intake door and the door will swing down. The

Pre Filter is the first filter behind the intake door. Peel away dirty Pre Filter and discard. Install

the new Pre filter with the white side out. Close door.

DO NOT WASH PRE FILTERS.

Step 2. The carbon filter is located behind the Pre Filter. Follow Pre Filter changing instructions

from Step 1. Remove Carbon Filter, discard and replace with new Carbon Filter.

DO NOT WASH CARBON FILTERS.

Step. 3. Remove the adjustable louver door. Remove the H.E.P.A. Bar. The H.E.P.A. Filter is a

pleated media surface with a metal frame. Slip the H.E.P.A. Filter out of the system, discard and

replace with new H.E.P.A. Filter.

DO NOT WASH H.E.P.A. FILTER.

Filter maintenance may vary according to each situation.

For any questions, please contact our customer service department at 1-800-237-9199.

READ AND SAVE THESE INSTRUCTIONS

install units.

Replace every 3 to 4 weeks.

Replace at least every 8 to 12 months.

Replace at least every 12 months.

Table of Contents

Do you have a question about the PR20.0 and is the answer not in the manual?

Page 1 PR20.0 AIR CLEANER USERS MANUAL READ AND SAVE THESE INSTRUCTIONS Pure n Natural Systems, Inc. recommends that a licensed electrician or licensed contractor install units. WARNINGS: 1. Always unplug or disconnect the air cleaner from power supply before servicing. 2. To reduce the risk of electric shock or injury to persons, do not expose to water or rain, do not use in a window.
Page 2 INSTALLATION OF PR20.0 AIR CLEANER EQUIPMENT: 1. Each PR20.0 unit is equipped with two (2) eye bolts, two (2) eye lags and industrial hanging wire for easy installation. 2. The PR20.0 has a ten foot power cord and a three prong grounded plug. Electrical: 120 Volts, 9 Amps.
Page 3 bolt, loop the wire and twist tightly together. Thread the opposite end of the hanging wire through the opposite eye bolt. Pull the wire tight. The system should be only slightly resting on the grid work of the drop ceiling. After you have adjusted the weight of the system on the grid work, then loop the wire and twist tightly.
Page 4 The PR20.0 flushmount Air Cleaner is designed to drop into a suspended ceiling. It replaces either 1 - 2' x 4' tile or 2 - 2' x 2' tiles from the suspended ceiling. In order to install the PR20.0 flushmount easily, the clearance above the suspended ceiling needs to be at least 18"...
