- Page 1 C H A R C O A L OWNER’S MANUAL 4001609 OW N ER ’ S M AN UAL A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS 50-2815...
-
Page 2: Safety Precautions
Safety Precautions lease read this entire manual before assembly and use of this charcoal burning grill ailure to follow these instructions could result in ProPerty damage bodily injury or even death Contact local building or fire officials about restrictions and installation inspection requirements in your area. - Page 3 After first use, inspect all fasteners for tightness The metal band on the Black Olive is designed to keep the top of your grill secure. Due to temperature changes causing expansion and contraction, checking the tightness of these fittings after the first few uses is highly recommended.
-
Page 4: Table Of Contents
Assembly ....................9 Installation Instructions ................12 Clearances ..................... 12 Lighting Instructions ................14 Operating Instructions ................15 Maintenance and Service ................. 16 Black Olive Accessories ................17 Parts Diagram ..................18 Parts List ....................20 Troubleshooting ..................22 Technical Specifications ................23 Warranty ....................24... -
Page 5: Specifications
SPECIFICATIONS Grilling Area 19 3/4” ( 306 sq in ) Maximum BTU 60,000 * Ignition Time 3 minutes * Grill Temp 150°F - 650°F+* Electrical Requirements 120 Volts 3.55 Amps Unit Dimensions H 49” W 49.5” D 28” Fuel Lump Charcoal ePending on charcoal tyPe 49.5”... -
Page 6: Contents
For your safety two people are required to lift and assemble the Black Olive Grill. Your crated Black Olive Grill come partially assembled with the remainder of the parts in a separate box. Reference the Bill of Materials below to insure you have all the correct components and fasteners. -
Page 7: Uncrating
UNCRATING Step 1: To remove the crating you will need a 5/16” socket or flat screwdriver. Start by removing the screws in the circled areas shown (see Figure 2) on both sides of the crate. Both side cross members can now be removed from the crate (See Figure 3). - Page 8 UNCRATING Step 3: Remove the two circled screws shown (Figure 4) from the rear packaging brace using a 5/16” socket. The crate can now be removed from the pallet and shell assembly. Note: The shell assembly is now unsupported, be careful not to knock it over.
-
Page 9: Assembly
ASSEMBLY Step 6: Install the wheels and axle shaft into the base assembly by resting the base assembly on its side as shown in Figure 7. Use a rubber mallet or hammer to install the supplied push nut onto the free end of the axle shaft. After installing the wheels, right the base assembly and adjust the leveling legs until it is level. - Page 10 ASSEMBLY Step 9: Open the shell assembly and remove the ceramic fire basket, ceramic ring, grill support, and any packaging material from inside the shell. Step 10: place the 10” round ceramic blanket in the bottom of the shell. Now take the stainless steel shell secure plate with ignitor cover tube attached, slide the ignitor cover tube over the ignitor.
- Page 11 ASSEMBLY Step 9: You will now need to adjust the ignitor and lock it in place. Remove the access panel at the back of the barbeque, there are four T-20 screws holding it on. Now loosen the lock down screw shown in the detail view A. Once the screw is loose push up on the bracket holding the ignitor until the square ignitor base is touching the cover tube.
-
Page 12: Installation Instructions
The grill is heavy and is not designed to roll over uneven terrain such as gravel or soft terrain. ALWAYS place and use your Black Olive Grill in a SAFE and LEVEL spot. DO NOT place the grill on slopes, uneven surfaces, or under any unprotected combustible materials. - Page 13 CLEARANCES 12” from back of hinge 15” 15” 15: s igure ide and baCk ClearanCe 36” from caP 16: t igure OP ClearanCe...
-
Page 14: Lighting Instructions
LIGHTING INSTRUCTIONS ALWAYS REMOVE THE GRILL COVER BEFORE LIGHTING THE GRILL Fuel Type: Use only hardwood lump charcoal. Note: No lighter fluid or fire starter cubes are required to start this grill. To Start Grill: Scrape ash from previous burn through the cast grate, make sure holes aren’t plugged. -
Page 15: Operating Instructions
Smoking (1-2) 150°F - 250°F Grilling (3-4) 250°F - 500°F Searing (5-6) 500°F - 700°F DO NOT attempt to move your Black Olive Grill when it is hot or while cooking. USE CAUTION when touching exterior surfaces of grill, exterior surfaces are HOT when in use. -
Page 16: Maintenance And Service
Do not wash interior of shell as it will absorb water. • Mold - If the Black Olive Grill is subjected to the elements for an extended length of time moisture can get trapped inside the grill and cause mold to appear on the grill’s internal ceramics or grill. -
Page 17: Black Olive Accessories
These is perfect for breakfast multipurpose shelves or brunch on the grill. It simply sit on top of the gives your Black Olive existing shelves and even more versatility and can be used as cutting allows you to cook bacon, boards or prep stations. -
Page 18: Parts Diagram
PARTS DIAGRAM... - Page 19 PARTS DIAGRAM...
-
Page 20: Parts List
Fully Assembled Base 50-2802 Base Frame w/ Decal 50-2803 Leveling Legs 50-2714 Power Switch 50-2804 Black Olive Wheel End Caps (set of 2) 50-2727 Axel w/ Wheel Retainers 50-2757 Black Olive Wheels 8" Diameter 50-2756 SS Air Control Lever 50-2805... - Page 21 50-2809 Charcoal Base Tray 50-2810 Charcoal Ash Pan 50-2811 Electrical Cord Strain Relief EC-044 120V Electrical Power Cord 8 ft EC-042 Black Olive Grill Cover 50-2596 Cleanout Cover Assembly 50-2812 Charcoal Scraper Tool 50-2813 Grill Gripper 50-2814 Cast Cooking Grill...
-
Page 22: Troubleshooting
TROUBLESHOOTING roblem ossible ause olution Make sure outlet is working and plug grill in. rill is not Plugged in Red light on switch will light up when ignitor and ower switch is off pump are turned on. Replace wet charcoal with fresh dry charcoal. harcoal is wet When the grill is switched on you should hear the pump running, check the base of the grill for a vibration. -
Page 23: Technical Specifications
Center the lid and make sure gasket is sealing. Retighten the acorn nuts then replace the springs. roken hinge or loose Contact your local Black Olive Dealer for replacement id is eavy to hinge or springs. -
Page 24: Warranty
Black Olive Charcoal Grill Warranty Sherwood Industries Ltd prides itself in producing the highest level of quality and customer service. The Black Olive Grill is built using only the finest material to create a durable ceramic grill/smoker. Our commitment is backed by our Exclusive Limited Lifetime Warranty to the original purchaser. - Page 25 23. Optional accessories for the Black Olive Grill are covered against defect for a period of one (1) year from purchase. 24. Fading of the BBQ cover is a natural result of exposure to the elements and is not covered by warranty.
- Page 26 Notes...
- Page 27 Notes...
- Page 28 SHERWOOD INDUSTRIES LTD 6782 OLDFIELD ROAD, VICTORIA, BRITISH COLUMBIA, V8M 2A3 blackolivegrill March 21, 2013 C-14063...
