Page 1: Gas Oven
COOKER with DOUBLE GAS OVEN PR 60 FSDOG Instructions for use Installation advice Before operating this cooker, please read these instructions carefully KEEP IN A SAFE PLACE... - Page 2 Dear Customer, Thank you for purchasing a Prestige Gas Cooker with Double Gas Oven. The safety precautions and recommendations in these instructions are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
- Page 3 IMPORTANT SAFEGUARDS Fire risk! Do not store flammable material in the oven. AND RECOMMENDATIONS Make sure that electrical cords con- necting other appliances in the prox- After unpacking the appliance, check to imity of the cooker cannot come into ensure that it is not damaged and that contact with the hob or become the oven door closes correctly.
-
Page 4: Cooking Hob
COOKING HOB Fig. 1.1 COOKING HOB 1. Auxiliary burner (A) 1,00 kW 2. Semi-rapid burner (SR) 1,75 kW 3. Triple-ring burner (TR) 3,50 kW Note: The electric ignition is incorporated in the knobs. -
Page 5: Control Panel
CONTROL PANEL Fig. 2.1 CONTROL PANEL - Controls description 1. Front right burner control knob 2. Rear right burner control knob 3. Rear left burner control knob 4. Front left burner control knob 5. Ovens light control knob 6. Top oven - Gas oven / gas grill control knob 7. -
Page 6: Use Of Cooking Hob
USE OF COOKING HOB LIGHTING THE BURNERS GAS BURNERS To ignite the burner: Each burner is controlled by a gas tap assuring the opening and the closing of 1) Lightly press and turn the knob anti- the gas supply. clockwise and position the knob sym- Make the symbols printed on the knob to the indicator printed on the match the indicator on the control panel... -
Page 7: Choice Of The Burner
CORRECT USE OF TRIPLE-RING CHOICE OF THE BURNER BURNER (Fig. 3.4a - 3.4b) On the control panel, near every knob, there is a diagram that indicates which Flat-bottomed pans should be placed burner is controlled by that knob. directly onto the pan-support. The suitable burner must be chosen according to the diameter and the When using a WOK always place the... - Page 8 TOP GAS OVEN OVEN THERMOSTAT Attention: the oven door becomes The numbers 1 to 10 printed on the very hot during operation. knob (fig. 4.1) indicate the increasing Keep children away. oven temperature value (see table below - THERMOSTAT GRADE TABLE To regulate the temperature, set the chosen number onto the control panel GENERAL FEATURES...
-
Page 9: Oven Cooking
IGNITION OF THE OVEN BURNER If the flame extinguishes for any reason, the safety valve will automatically shut off the gas supply to the burner. IMPORTANT: the oven door must be To re-light the burner, first turn the oven open during this operation. control knob to position , wait for at least 1 minute and then repeat the... - Page 10 IGNITION OF THE GRILL BURNER IMPORTANT: the oven door must be open during this operation. 1 – Open the oven door to the full extent. WARNING: Risk of explosion! The oven door must be open during this operation. 2 – Lightly press and turn the thermostat knob clockwise to the posi- tion (fig.
-
Page 11: Oven Light
USE OF THE GRILL OVEN LIGHT Very important: the grill must always The cooker is equipped with a light that be used with the oven door slightly illuminates the oven to enable visually open and with shield "A” mounted controlling the food that is cooking. (Fig. - Page 12 BOTTOM MAIN GAS OVEN THERMOSTAT Attention: the oven door becomes The numbers 1 to 10 printed on the very hot during operation. knob (fig. 5.1) indicate the increasing Keep children away. oven temperature value (see table 5.2). To regulate the temperature, set the chosen number onto the control panel GENERAL FEATURES indicator.
- Page 13 IGNITION OF THE OVEN BURNER If the flame extinguishes for any reason, the safety valve will automatically shut off the gas supply to the burner. IMPORTANT: the oven door must be To re-light the burner, first turn the oven open during this operation. control knob to position , wait for at least 1 minute and then repeat the...
- Page 14 OVEN LIGHT The cooker is equipped with a light that illuminates the oven to enable visually controlling the food that is cooking. This light is controlled by a switch knob (Fig. 5.5 - position). Fig. 5.5...
-
Page 15: Cooking Guide
COOKING GUIDE Temperature and times given are approximate, as they will vary depending on the quality and amount of food being cooked. Remember to use ovenproof dishes and to adjust the oven temperature during cooking if necessary. COOKING CHART Temperature Food Cooking Time (approx) °C... -
Page 16: Electronic Clock/Alarm
ELECTRONIC CLOCK/ALARM ELECTRONIC ALARM The electronic alarm is a device which groups the functions of 24 hours clock The alarm program consists only of a with illuminated display and 99 minutes buzzer which may be set for a maximum alarm. period of 99 minutes. -
Page 17: Enamelled Parts
CLEANING MAINTENANCE ENAMELLED PARTS Important: All the enamelled parts must be cleaned Before cleaning or carrying out with a sponge and soapy water or other any maintenance disconnect the non-abrasive products. appliance from the electrical sup- Dry preferably with a soft cloth. ply and wait for it to cool down. - Page 18 BURNERS CORRECT REPLACEMENT OF THE BURNERS They can be removed and washed with soapy water only. It is very important to check that the They will remain always perfect if burner flame distributor F and the cap C cleaned with products used for silver- has been correctly positioned (see figs.
- Page 19 TRIPLE RING BURNER The triple ring burner must be correctly positioned (see fig. 8.3); the burner rib must be enter in their lodgement as shown by the arrow. The burner correctly positioned must not rotate (fig. 8.4). Then position the cap A and the ring B (fig. 8.4 - 8.5). Fig.
- Page 20 TOP OVEN ASSEMBLY AND DISMANTLING OF THE SIDE RUNNER FRAMES – Fit the side runner frames into the holes on the side walls inside the oven (Fig. 8.6). – Slide the tray and rack into the run- ners (Fig. 8.7). Do not use the first level from the bottom.
-
Page 21: Bottom Main Oven
BOTTOM MAIN OVEN ASSEMBLY AND DISMANTLING OF THE SIDE RUNNER FRAMES – Fit the side runner frames into the holes on the side walls inside the oven (Fig. 8.8). – Slide the tray and rack into the run- ners (Fig. 8.9). The shelf must be fitted so that the safety catch, which stops it sliding out, faces the inside of the oven. -
Page 22: Removing The Oven Door
Type A REMOVING THE OVEN DOOR To facilitate oven cleaning, it is possible to remove the door. Please follow the instructions carefully: – Open the door completely. – Push down the lever “L” and, keeping it in this position, slowly close the door in order to block the hinge. - Page 23 Type B Fig. 8.14A REMOVING THE OVEN DOOR The oven door can easily be removed as follows: – Open the door to the full extent (fig. 8.14A). – Attach the retaining rings to the hooks on the left and right hinges (fig. 8.14B).
-
Page 24: Advice For The Installer
ADVICE INSTALLER FOR THE IMPORTANT – Cooker installation must only be carried out by QUALIFIED TECHNICIANS and in compliance with local safety standards. Failure to observe this rule will invalidate the warranty. The appliance must be installed in compliance with regulations in force in your country and in observation of the manufacturer's instructions. -
Page 25: Installation
INSTALLATION This cookers has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a gap of at least 200 mm must be left between the side of the cooker and the furniture. The furniture walls adjacent to the cooker must be made of material resistant to heat. -
Page 26: Stability Chain
STABILITY CHAIN To avoid the possibility of the cooker tipping forwards in the event of the user placing an excessive weight on the oven door when in the open position. A stability chain must be firmly fixed between the rear of the cooker and wall. PROVISION FOR VENTILATION The room containing the cooker should have an air supply in accordance with BS.5540: Part 2: 1989. -
Page 27: Gas Section
GAS SECTION GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the cooker to Natural Gas or LP Gas must be carried out by a This appliance is supplied for use on qualified gas engineer. Installers shall NATURAL GAS only and cannot be take due account of the provisions of the used on any other gas without modifica- relevant British Standards Code of... - Page 28 GAS CONNECTION The gas supply must be connected to the gas inlet which is located at the left or the right hand rear of the appliance (fig. 10.1). The pipe does not cross the cooker. When screwing the connecting tube operate with two spanners (fig.
-
Page 29: Conversion To Lpg
CONVERSION TO LPG 1 - INJECTORS REPLACEMENT OF HOB BURNERS The diameter is marked on the injector in cents of millimetre. Select the injectors to be replaced according to the “Table for the choice of the injectors” (page 31). To replace the injectors: –... - Page 30 2 - ADJUSTING OF THE MINIMUM The burners are conceived in such a way so as not to require the regula- OF THE HOB BURNERS tion of the primary air. In the minimum position the flame must have a length of about 4 mm and must remain lit even with a quick turn from the maximum position to that of minimum.
- Page 31 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar Nominal Reduced G 20 - 20 mbar G 31 - 37 mbar Power Power BURNERS Ø injectors ring opening Ø injectors ring opening [kW] [kW] [1/100 mm] [mm] [1/100 mm] [mm]...
- Page 32 GAS OVENS (top and bottom) OPERATIONS TO BE EXECUTED FOR THE REPLACEMENT OF THE INJECTORS OF THE OVEN AND GRILL BURNERS a) oven burner Fig. 10.6 – Lift and remove the lower panel inside the oven. – Remove the burner securing screw (fig.
- Page 33 PRIMARY AIR OF THE OVENS PRIMARY AIR OF THE GRILL BURNERS BURNER (top oven only) With a screwdriver untighten the screw (fig. 10.10) and move forward or back- With a screwdriver untighten the screw ward the air flow regulation collar to (fig.
-
Page 34: Lubrication Of The Gas Taps
ADJUSTMENT OF THE OVENS Flame Flame Flame BURNERS MINIMUM faulty in correct with excess primary air primary air This needs to be done only for the oven long, yellow clear short and sharp burner (the grill is a fixed capacity) by interior blue too blue interior acting on the thermostat in the following... -
Page 35: Electrical Section
ELECTRICAL SECTION For your safety please read the following information: This appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. This appliance has to be equipped with a 13 amp three pin mains plug with a 3 amp fuse fitted. - Page 36 Warning! Before effecting any intervention on the electrical parts the appliance must be dis- connected from the network. REPLACEMENT OF THE ELECTRICAL FEEDER CABLE – Remove the two screws securing the cover plate A behind the cooker. – Remove the screw C from the cable clamp. –...
- Page 37 Your Prestige from COMET Your new Prestige product comes with 12-month guarantee covering all parts and labour. If your appliance proves to be defective as a result of faulty materials or workmanship during the guarantee COMET will repair or replace it free of charge.
- Page 39 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs.
- Page 40 Prestige is a registered trademark of Meyer Intellectual ® Properties Limited and is sold pursuant to a license. code 1102465 ß9...
