Summary of Contents for Cables to Go 29350
- Page 1 UIDE 1.1 R ECEIVER ONGLE Model: 29350...
-
Page 2: Table Of Contents
ABLE OF ONTENTS Introduction..............................2 Features................................3 Package Contents............................4 Device Installation............................5 Technical Specifications..........................7 Cables To Go One Year Warranty........................8 Important Safety Information...........................9... -
Page 3: Introduction
The USB v1.1 Receiver Dongle is bus powered, so no external power source is needed. This unit is designed to work with Cables To Go part numbers: 29349, 29344, or 29348. We recommend that you read this manual thoroughly and retain for future reference. -
Page 4: Features
EATURES Extends the functional distance of a USB signal, allowing a USB device to function with a USB-enabled computer up to 150ft away Ideal for use with USB projectors, interactive whiteboards, cameras, printers, web cams, hubs, or any other USB device Bus-powered so no external power source is required Uses standard cat5/cat5E/cat6 patch cords (not included), allowing for easy use and flexibility Compliant with USB Specification 1.1... -
Page 5: Package Contents
ACKAGE ONTENTS USB v1.1 Receiver Dongle User Guide... -
Page 6: Device Installation
EVICE NSTALLATION Step 1 Install the USB transmitter (29349, 29344, or 29348) by means of wall plate, if using wall plate style transmitter, or connect the Dongle style transmitter to your computer. Step 3 Using a pre-terminated Cat5/Cat5e/Cat6 cable or terminate your own cable to connect the USB transmitter and USB Receiver Dongle. - Page 7 EVICE NSTALLATION Note: We recommend using a solid 24AWG Cat5/Cat6 patch cable when connecting this transmitter with a receiver unit. Example Application: (shown being used with Cables To Go USB SuperBooster Wall Plate Transmitter- #29344) # 29344 USB Cable Cat5/6 Patch Cable...
-
Page 8: Technical Specifications
ECHNICAL PECIFICATIONS Product No. 29350 Complies USB Rev. Ver. 1.1 USB Type A female/ Connectors RJ45 female Power Mode Cable Length 6in. Product Weight .05 lbs Product Color Black... -
Page 9: Cables To Go One Year Warranty
ARRANTY At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device. -
Page 10: Important Safety Information
MPORTANT AFETY NFORMATION ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc. can damage the product. - Page 12 . 1.0.4.3.09...
