M2000 Quick Start Guide
Wireless Access Point & Client Bridge
M2000 is a long range outdoor wireless Access Point / Client
Bridge with mesh function that operates seamlessly in the 2.4GHz
frequency and provides high bandwidth up to 108Mbps with
Turbo G. It features high transmitted output power and high
receivable sensitivity. High output power and high sensitivity can
extend range and coverage to reduce the roaming between
Access Points to get a more stable wireless connection. Based on
mesh function, it can be used to establish mesh network, reduces
the expense of equipment and risk of disconnection.
It supports distance control by 1km to 30km and RSSI indicator
which enables the best transmission and receives signals for
traffic communication. This product comes with PoE injector for
building in outdoor environment easily.
To protect your wireless connectivity, it can encrypt all wireless
transmissions through 64/128‐bit WEP data encryption and also supports WPA/WPA2. The MAC address filter lets
you select exactly which stations should have access to your network. In addition, the User Isolation function can
protect the private network between client users. The attractive design, high performance, and array of features
make M2000 a suitable wireless solution for your residence or office.
IP Address Configuration
The default IP address of the device is
192.168.1.1. In order to log into this device, you
must first configure the TCP/IP settings of your
PC/Notebook.
1. In the control panel, double click Network
Connections and then double click on the
connection of your Network Interface Card
(NIC). You will then see the following
screen.
2. Select Internet Protocol (TCP/IP) and then
click on the Properties button. This will
allow you to configure the TCP/IP settings
of your PC/Notebook.
3. Select Use the following IP Address radio
button and then enter the IP address
(192.168.1.21)
(255.255.255.0). Ensure that the IP address
and subnet mask are on the same subnet as
the device.
4. Click on the OK button to close this window,
and once again to close LAN properties
window.
Logging In
Quick Start Guide v.1.0
Refer to User's Manual for complete instructions
and subnet mask
1. To configure the device through the
web‐browser, enter the IP address of the
Bridge (default: 192.168.1.1) into the
address bar of the web‐browser and
press Enter.
2. After connecting to the IP address, the
web‐browser will display the login page.
Specify admin as the default User Name
and Password, and then click on the Login
button.
Administration
1. Click on the Administration link under the
Management section. This option allows
you to create a new user name and
password for the device. For security it is
highly recommended for security reasons.
