EnGenius M36 Datasheet

Package Contents
- 1* High power multi-function
AP (M36)
- 1* 12V/1A Power Adapter
- 1* CAT5 UTP Cable
- 1*QIG
- 1*CD (User's Manual)
- 1* Wall mount screw set
Features
Mesh Networking
Super G solution up to 108Mbps
High Output Power up to 28 dBm
IEEE 802.11b/g Compliant
Embedded Antenna
Point-to-point,
Point-to-multipoint Wireless
Connectivity
2.4GHz Super G 108Mbps
The M36 is a smoke detector looking Wireless Access Point / Universal
Repeater / WDS that operates seamlessly in the 2.4 GHz frequency
spectrum supporting the 802.11b (2.4GHz, 11Mbps) and Super high
speed of 802.11g (2.4GHz, 108Mbps) wireless standards. It's the best
way to add wireless capability to your existing wired network, or to add
bandwidth to your wireless installation.
M36 features high transmitted output power and high receivable
sensitivity along with antenna diversity. High output power and high
sensitivity can extend range and coverage to reduce the roaming
between Access Points to get a more stable wireless connection. It also
reduces the expense of equipment in the same environment.
To protect your wireless connectivity, it can encrypt all wireless
transmissions through 64/128-bit WEP data encryption and also
supports WPA/WPA2. The MAC address filter lets you select exactly
which stations should have access to your network. In addition, the User
Isolation function can protect the private network between client users.
The attractive design, high performance, and array of features make
M36 a suitable wireless solution for your residence or office.
Features
Convenient Wireless Connection build up. In this mode for better
performance, recommended 1 Gateway with 4 Relay in linear and
radiative deployment scenario.
Capable of handling heavy data payloads such as MPEG, video
streaming, large file transfer and VoIP
Extended excellent Range and Coverage (fewer APs)
Fully Interoperable with IEEE 802.11b/IEEE802.11g compliant devices
Users won't see antenna in your building environment
Let users transfer data between two buildings or multiple buildings
Wireless High power AP
Access Point/ WDS/Universal Repeater
Benefits
M36
