Biodrier Business
High speed Hand Dryer
Operating Instructions and Parts Manual (automatic)
Surface Mount
Technical Specifications
Model BB70
Operating Voltage
Air Speed
Motor Type
Display
Rated Power
Drying Time
Circuit Operation
Timing Protection
Drip Proof
Isolation
Net Weight
Shipping Weight
Unit Size
Finish
Decibel Rating
Approvals
Cover Type/ Cover Finish
Operating Instructions and Parts Manual
Performance Data
220 - 240V 50Hz 86 m/s
(150M /h)ICP
Brushless Motor
LCD Instruction + Countdown
850 Watts
Under 10 Seconds
Infrared Automatic, Self Adjusting
30 Seconds Auto Shut Off
IP X 1
Class Il
11KG
13KG
650 x 292 x 250 mm
White/Silver (ABS)
79 dba @ 1mtr
CE, GS, WEEE
BB70W ABS - White
BB70S ABS - Silver
)
1
Advertisement
Table of Contents
Related Manuals for Biodrier BB70
Summary of Contents for Biodrier BB70
-
Page 1: Performance Data
Biodrier Business High speed Hand Dryer Operating Instructions and Parts Manual (automatic) Surface Mount Technical Specifications Model BB70 Performance Data Operating Voltage 220 - 240V 50Hz 86 m/s Air Speed (150M /h)ICP Motor Type Brushless Motor Display LCD Instruction + Countdown... - Page 2 Biodrier Business High speed Hand Dryer General Safety Information: WARNING This product is intended for WARNING Disconnect power at the service installation by a qualified service person. breaker before installing or servicing. Use AWG No. 16 solid conductor for wiring.
- Page 3 Biodrier Business High speed Hand Dryer 4. Connect supply wires to terminal block where indicated and connect ground wire to base plate with ground screw Connections: A. Connect the live wire (coloured red and black) to the terminal black marked ‘’L’’.
- Page 4 Biodrier Business High speed Hand Dryer Cleaning and Maintenance Periodic cleaning of the unit is recommended to ensure optimum performance. Disconnect the electrical supply. Remove the two cover-mounting screws. Remove the cover. Remove air intake filter (situated adjacent to drip tray) and rinse with hot soapy water, dry and replace.
- Page 5 Biodrier Business High speed Hand Dryer Repair parts list Description Description Water tank Block Spring Cover Side board Circuitry box Air inlet Circuitry B Motor cover Fix loop Operating Instructions and Parts Manual...
- Page 6 Biodrier Business High speed Hand Dryer Front cover Air connector Motor and air home Sound insulation cover Switch Fixer Switch button Circuitry A Connection cover Motor cover Front air out cover Circuitry C Bracket Connector Front air shell Front airproof...
- Page 7 Biodrier Business High speed Hand Dryer Hose Outlet rubber Celotex A Operating Instructions and Parts Manual...
