Summary of Contents for Oklahoma Sound AW-95
- Page 1 Wireless/Rechargeable PERSONAL PA With Built in Tape Player/Recorder INSTRUCTION MANUAL VOICE Amplification SYSTEM MODEL #PAW-95...
-
Page 2: Important Safety Information
INTRODUCTION Congratulations! You are now the owner of a new and exciting product in the presentation world of today. This updated version also features a permanent rechargeable battery, built in cassette player/recorder & 20 watt multime- dia sound system the latest in the popular OSC lectern and presentation equipment product line. - Page 3 TABLE OF CONTENTS Introduction ....... .2 Safety Information......2 Manufacturer’s Warranty.
- Page 4 OPERATING INSTRUCTIONS PLEASE READ CAREFULLY BEFORE USE! Getting Acquainted A) RECEIVER: This the main unit which includes the speaker, tape deck, volume, tone and echo controls (karaoke). B) TRANSMITTER: Is the small unit which the Tie-Clip Mic attaches to it weighs less than a pound and fits in a pock- et or clips neatly on belt.
- Page 5 Receiver (continued) 4) When the receiver is used with the transmitter the RF light will turn on and the AF light will flash while speaking which indicates that the unit is working as it should. 5) If you want to record using a separate device other than the built-in tape deck connect the device to the “AUX OUT”...
-
Page 6: Troubleshooting
TROUBLESHOOTING If Feedback Occurs • Be sure the mic isn't directly in front of built-in speaker • Be sure the mic is not closer than 5 ft. from the receiver • Reduce volume gradually until feedback diminishes • Reduce the tone gradually by turning knob to the left until feedback diminishes Interference may occur in the following circumstances—... - Page 7 FEATURES • PAW-95 was produced using the latest SMT machine, high stability • PAW-95 is provided with a permanently installed recharge- able battery, which can be used continuously for 8 hours • PAW-95 can be used with the recharger cable if the bat- tery runs out •...
- Page 8 TECHNICAL SPECIFICATIONS TRANSMITTER Frequency range ....VHF170-250MHz Modulation ......FM+/- 30KHz max Power Output ....20mW min Frequency Stability .... +/- 10PPM (at 20°C) Power Source ....DC 9V Current Consumption ..DC 3V AF Response ...... +/-dB (at 100MHz -10KHz) Distortion ......5% max (at DEV =/- 9-KHZ) RECEIVER Sensitivity ......
