Oklahoma Sound 007HT Specifications

PAs #007hT / PAW-90x / PAW-95
w w w . o k l a h o m a s o u n d . c o m
#007hT
PA Sound System completely built into handsome black brief-case. Includes 2
practical mic systems: Tie/Lapel-Clip style mic and a gooseneck mic holder with
hand-held mic. Use as a lectern with 14" x 15" fold-out reading table; folds
away neatly allowing ample storage for your presentation materials. Removable
shoulder-strap lets you sling brief-case over your shoulder for hands-free
operation. Standard with AC power adapter; or use with batteries for complete
mobility.
Power Output ....20 Watts
Mic/007 ................ 2 Condenser type: Handheld with 9'
Speakers............... Two 4" High Efficiency
Inputs....................One Mic
Outputs ................ Line out 1 – Extension Speaker
MODEL 007HT
#PAW-90x
Free yourself of wire constraints and be heard from anywhere in the room! This
portable system includes receiving station, transmitter and lavalier microphone
— all in one compact travel case that weighs 4.5lbs. Ideal as a classroom tool,
conferences or for business meetings. Transmitter includes belt clip or fits into
your pocket. Includes Lead Acid rechargeable battery for complete mobility.
Maximum operating distance from receiver is 200 feet. Optional Handheld &
Headset micophones available.
TRANSMITTER Wireless Mic:
Frequency Response ............... 100 – 12000 Hz
RF Output Power ..................... 50mW (MAX)
Battery Life ................................. 8 Hours (average)
Battery Type ............................... 006p 9V
MODEL PAW-90x
#PAW-95
Be heard from anywhere in the room. Powerful 20 watt amplifier will broadcast
voice allowing user to be up to 200 feet away. Compact portable wireless voice
amplification system includes wireless receiver with built in amplifier speaker
and rechargeable battery. Clip on beltpak transmitter and lavalier mic for wire
free use. Includes built in cassette recorder to record speeches, play music etc.
Dimensions .....................18"L x 13"W x 5"H
RECOMMENDED ACCESSORIES
MODEL PAW-95
I
P e r s o n a l a n d P o r t a b l e
I
P A-In-Case Sound Attache
Cable; Tie-Clip/Lavalier with 10' Cable
Line out 2 – Tape Recorder
I
P ersonal PA
I
P ortable Wireless PA w/Cassette
(PAW-90x & PAW-95)
#PWM90-5 Wireless Mic
Handheld
#PWM90-6 Wireless Mic
Tie-Clip/Lavalier
#PWM90-7 Wireless Mic
Headset
PO R TA B LE P .A. SySTEMS
— —
21
Controls ............... One Volume, Two Tone, On/Off
Fuse .......................Internally Mounted
Power Supply .... AC — 110V; DC (8 'C' Cell Batteries
or 12V Lantern, not included)
Dimensions .........18"L x 13"W x 5"H
Weight ..................9 lbs.
RECEIVER with Amplifier:
Sensitivity .....................................10uV
AF Output Power .......................7W
Power Req.....................................AC/DC 12V
Frequency Range .......................160 – 240 MHz
(8 preset frequencies for multiple station use).
Weight .............................9 lbs.
#PWM95-5 Wireless Mic
Handheld
#PWM95-6 Wireless Mic
Tie-Clip/Lavalier
#PWM95-7 Wireless Mic
Headset
