O
S
C
KLAHOMA
OUND
ORPORATION
TECHNICAL SPECIFICATIONS
TRANSMITTER
Frequency range ..............VHF170-174MHz
Wireless/Rechargeable
Modulation ........................FM+/- 15KHz max
PERSONAL PA
Power Output .................... 5mW min
Frequency Stability ............ +/- 10PPM(at 25°C)
INSTRUCTION MANUAL
Power Source ....................DC AA (2)
Current Consumption ......DC20 mA max
VOICE
Amplification
RECEIVER
SYSTEM
Sensitivity ............................ 2.5uV min (under squelch control)
Max Power Output ............5W min (at 4 ohms speaker load)
Distortion ............................5% max ( At 2W output)
Frequency Stability ............ +/- 10PPM (at 25°C)
Hum and Noise ..................60db min.
Power Source ....................AC 120V/DC12V
(Including rechargeable battery)
Current Consumption ...... 800mA max
Dimensions ........................7"W x 9
3
⁄
"H x 4"D
4
Weight ................................4 lbs.
OKLAHOMA SOUND CORP.
149 Entin Road, Clifton, NJ 07014
Tel 973-594-9000 • Fax 973-594-9339
www.oklahomasound.com • e-mail: info@oklahomasound.com
MODEL #PAW-90x
Advertisement
Related Manuals for Oklahoma Sound PAW-90X
Summary of Contents for Oklahoma Sound PAW-90X
- Page 1 Power Source ...AC 120V/DC12V (Including rechargeable battery) Current Consumption ... 800mA max Dimensions ...7"W x 9 ⁄ "H x 4"D Weight ...4 lbs. OKLAHOMA SOUND CORP. 149 Entin Road, Clifton, NJ 07014 Tel 973-594-9000 • Fax 973-594-9339 www.oklahomasound.com • e-mail: info@oklahomasound.com MODEL #PAW-90x...
- Page 2 Our Wireless PA Rechargeable System undergoes the most rigid and exacting tests for superior quality and performance before leaving the factory. Oklahoma Sound Corporation warrants this product to be free from defec- tive material and workmanship for two years from the date of resale by an authorized Oklahoma Sound distributor.
- Page 3 As with any electronic device this unit should not be used by children without the proper supervision. PERSONAL PA: Model PAW-90x TABLE OF CONTENTS Introduction ....... .2 Safety Information..
- Page 4 4) Attach mic to clip and affix to tie, lapel etc. — the closer the 5) If the transmitter will not be used for an extended period of time PERSONAL PA: Model PAW-90x where mic will be used) green which indicates full battery; when LB light turns red indi- cates low battery.
