1
Manual for Remote View & Control-Router UPNP Supported
H.264 Network
Embedded DVR
INSTRUCTION MANUAL FOR REMOTE VIEW&CONTROL
---------------- Router UPNP Supported----------------
Visionari Limited Liability Company
Visionari Copyright(1.5)2010Version
http://www.mydepots.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the H.264 Network Embedded DVR and is the answer not in the manual?

Questions and answers

Related Manuals for MyDepots H.264 Network Embedded DVR

Summary of Contents for MyDepots H.264 Network Embedded DVR

  • Page 1 Manual for Remote View & Control-Router UPNP Supported H.264 Network Embedded DVR INSTRUCTION MANUAL FOR REMOTE VIEW&CONTROL ---------------- Router UPNP Supported---------------- Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 2 Step 6~6-1: Setting visiting password on remote view interface………………..P18 Attention here: all data below is cited from writer’s local network situation (system fault parameter is exception), please adjust according to your actual environment. Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 3 Step 1: Plug network cable line into LAN, assure the light is on, indicating network is normal. Figure (1) Figure 1  Step 2：Coming into DVR’s main menu, select 【ADVANCE】 ，Press【Enter】 Figure 2  Step 3：select 【NETWORK】, Press【Enter】 Figure 3 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 4 【TYPE】: Here’re 3 options, you need firstly check whether your router support “UPNP”, if yes, please select it and follow next steps(if not, please get reference from another manual under 【STATIC】mode) Figure 4-1 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 5 00080, it’s a must to change another), provided that it’s a 5-digit number and not used by any other device in your wireless environment, i. e, here assumed we set it as 【09001】. Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 6 Step 4-4: Writer selects DNS1 to fill, then finish inputting completely. But it’s always necessary to remember to click 【APPLY】, then 【EXIT】, at this time, DVR system will restart, if not, please restart manually. Figure 4-4 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 7 Step 4-7: Check UPNP’s status Equally, land your router’s managing interface, inspect setting list for UPNP, check whether DVR’s web port, media port, even mobile port are automatically added here or not. Figure 4-7 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 8 Maybe you would ask how to get my router’s WAN IP? Still you need get on your router’s below(Attention: it’s just writer’s router’s IP interface, please check yours managing interface like accordingly) Figure 4-8-1  Step 4-8-2: as you could see how writer operated address correctly. Figure 4-8-2 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 9 Step 4-9: Visiting DVR through DDNS: which means you could also visiting your DVR though Dynamic Domain Name Server. But similarly, you need finish corresponding setting. Go to this interface, and click 【DDNS SETTINGS】. Figure 4-9  Step 4-9-1: select 【DDNS】as 【ON】 Figure 4-9-1 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 10 Step 4-9-3： 【SERVICE】: here we recommend to select 【dyndns】 Figure 4-9-3  4-9-4： 【HOST NAME】&【USER NAME】 & 【PASSWORD】: you have to get them through registration on www.dyndns.com, The following steps present you how to catch clues for the three. Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 11 Manual for Remote View & Control-Router UPNP Supported  4-9-5：Visit website” www.dyndns.com”, and click【Account】 Figure 4-9-5  4-9-6：Click【Create Account】 Figure 4-9-6 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 12 4-9-7： Fill in application information, like username(“vvmedvr1023” assumed by writer here) Figure 4-9-7  4-9-8: Now you’ll find interface as below, which reminds you to get useful information from your email-box. Figure 4-9-8 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 13 4-9-9: In your email box, you’ll find an email with topic “Your DynDNS.com Account Information” from “DynDNS.com Support”, you need click the address. Figure 4-9-9  4-9-10: Now revisit ” www.dyndns.com”, input username “vvmedvr1023 “& password to login in. Figure 4-9-10 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 14 4-9-11: Click 【Add Host Services】to register “host name” Figure 4-9-11  4-9-12: Now fill in username you want to use, select correct suffix as”dyndns.org” , and click “Use auto detected IP…..”, finally, click 【Add To Cart】 Figure 4-9-12 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 15 4-9-13: be demanded for credit card information). Figure 4-9-13  Step 4-9-14: Click 【Activate Services】 Figure 4-9-14  Step 4-9-15: you’ll see interface as below, indicating your services is successfully activated Figure 4-9-15 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 16 【http://】+ 【DDNS’s HOSTNAME】+【:】+【web port】, Take writer’s case as example, the address will be http://vvmedvr123.dyndns.org:9001 Well, still when firstly visit on net, you have to install the ActiveX, please follow: Figure 4-9-17 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 17 Step 4-9-19：Till now you can see any channel view from DVR’s side like below:（channels you can see depend on q’ty of dvr’s channel）, here we just take 4-ch dvr as example. You also can click 【SETUP】to come into control interface. Figure 4-9-19 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
  • Page 18 >>6-2: Remember Only you do set password not only on viewing interface(Figure 6), but also correspondingly on DVR’s interface(see figure 6-1), the passwords truly work. Eventually, you finish whole process realize “ Remote View” , go to enjoy now!! Figure 6-1 Visionari Limited Liability Company Visionari Copyright(1.5)2010Version http://www.mydepots.com...
