Page 1: User Manual
Microphone M86/M87 AUDAC PROFESSIONAL AUDIO EQUIPMENT M86/M87 Dynamic Microphone User Manual © AUDAC http://www.audac.eu info@audac.eu... - Page 2 Due to the unidirectional (supercardioid) polar pattern, the feedback is reduced to a strict minimum. The M86 and M87 are both exactly the same microphones with the same spe- cifi cations, except the on/off switch which is only provided on the M87.
- Page 3 Specifi cations Microphone type Dynamic Polar pattern Super Cardioid Frequency response 50 Hz - 18 kHz Sensitivity -74 dB ± 3 dB Impedance 300 Ohm Magnet Neodymium Output connector 3-pin XLR Dimensions Ø 51 x 178mm Weight 360g Measured at 1000 Hz Figure 1: Polar pattern Figure 2: Frequency response...
- Page 4 Eligible to bear CE marking. Conforms to European EMC Directive 89/336/ EEC. Meets applicable tests and performance criteria in European standard EN 55103 (1996) parts 1 and 2, for residential (E1) and light industrial (E2) environments.
