- Page 1 Hardware Manual NPM200 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ audac.eu. NPM200 - Quick Start Manual...
-
Page 3: Table Of Contents
Quick start guide ................13 Technical specifications Notes NPM200 - Quick Start Manual... - Page 4 NPM200 - Quick Start Manual...
-
Page 5: Introduction
Featuring a user-friendly interface and intuitive controls on a 3.5” touchscreen, the NPM200 allows you to easily manage audio paging and messaging. You can create and transmit pre-recorded messages or use the console’s XLR input to make announcements in real time. -
Page 6: Precautions
This will make sure that it will be recycled in an environmentally friendly manner, and will help to protect the environment in which we all live. NPM200 - Quick Start Manual... - Page 7 NPM200 - Quick Start Manual...
-
Page 8: Connections And Connectors
Chapter 1 Connections CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment. For balanced microphone input connections PIN 1: Ground Signal + PIN 2: Signal - PIN 3:... -
Page 9: Network Settings
Network settings STANDARD NETWORK SETTINGS DHCP: ON IP Address: Depending on DHCP Subnet Mask: 255.255.255.0 (Depending on DHCP) Gateway: 192.168.0.253 (Depending on DHCP) DNS 1: 8.8.4.4 (Depending on DHCP) DNS 2: 8.8.8.8 (Depending on DHCP) NPM200 - Quick Start Manual... -
Page 10: Overview Front Panel
Chapter 2 Overview front panel The front panel of the NPM200 is finished with elegant front panel glass with die-cast metal body construction features a PTT button with visual LED feedback, a 3.5” fully flexible and configurable touchscreen, and an XLR input that allows the use of various microphones with provided 48V phantom power. -
Page 11: Overview Rear Panel
(Dante/AES67), as well as control signals and power (PoE), are distributed over the Ethernet network. This input shall be connected to your network infrastructure. Teardrop holes These teardrop holes makes it possible to mount the NPM200 to a surface or wall with the included brackets. Installation This chapter guides you through the setup process for a basic setup where an NPM200 paging console should be connected to a system with a wired network. -
Page 12: Quick Start Guide
Configuring the NPM200 1) Dante controller Once all connections are made, and the NPM200 paging console is operational, the routing for the Dante audio transfer can be made. For the configuration of the routing, the Audinate Dante Controller software shall be used. The use of this tool is extensively described in the Dante controller user guide which can be downloaded from both Audac (www.audac.eu) and Audinate (www.audinate.com) websites. - Page 13 2) NPM200 paging console settings Once the Dante routing settings are made through the Dante Controller, other settings of the NPM200 paging console itself can be configured using the Audac Touch platform, which can be freely downloaded and operated from various platforms. This is very intuitive to be operated and automatically discovers all available compatible products in your network.
-
Page 14: Technical Specifications
110 x 58 x 166 mm Weight 0.5 Kg (Approx.) Construction Die-cast metal Colours Black (RAL9005) Front finish Elegant front panel with glass Accessories Mounting bracket (included) for teardrop holes Compatible devices All Dante compatible devices CMX215 CMX230 NPM200 - Quick Start Manual... -
Page 15: Notes
Notes NPM200 - Quick Start Manual... - Page 16 Discover more on audac.eu...
