ZIN-5005HD
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZIN-5005HD and is the answer not in the manual?

Questions and answers

Related Manuals for Zinwell ZIN-5005HD

Summary of Contents for Zinwell ZIN-5005HD

  • Page 1 ZIN-5005HD User’s Manual...
  • Page 2 Safety Instructions This product has been engineered and manufactured to assure your personal safety. However, improper use can result in potential electric shock or fire hazards. In order not to defeat the safe-guards incorporated in this instrument and its accessories, please adhere to the following instructions when installing, operating and servicing.
  • Page 3 Usage Warning ◆ To reduce the risk of electric shock, do not remove the cover or attempt to disassemble this product. There are no user-serviceable parts inside. Please refer all servicing to qualified service personnel. ◆ Protect this product from foreign objects. Never push object of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.

  • Page 4: Table Of Contents

    Ⅰ INTRODUCTION Package Content 5 Specifications 6 Front View 7 Back View 7 Remote Control 8 Ⅱ SETTING UP FOR ZIN-5005HD Connections 11 Connect to the Internet 11 Connect to USB Devices 13 Power On 13 Turn On ZIN-5005HD 13 Select the Video Output/Resource 13 Ⅲ...

  • Page 5: Package Content

    You can plug in your USB devices to the ZIN-5005HD to play music, movies and pictures on TV by following the on-screen display (OSD) menu. The ZIN-5005HD can also access the shared folders on the remote PCs through the intranet (local area network) and play the digital media files there on your TV.

  • Page 6: Specifications

    Specification Interfaces Video Output: HDMI、YPbPr、Composite Video Audio Output: Audio L/R、S/P DIF (Optical) Data Transfer: USB x 2、Ethernet Port General Specifications: Support Media Format: Video: MPEG1 (AVI/MKV/TS/DAT/MPG/MPEG/VOB) MPEG2 (MKV/DAT/MPG/MPEG/VOB/ISO/IFO/TS/TP) /M2TS MPEG4 (AVI/MP4/MKV/MOV/WMV/ASF) DivX 3/4/5/6、Xvid (AVI/MKV/MP4/MOV) H.264/AVC (TS/AVI/MP4/MKV/MOV/FLV)/M2TS VC-1 (TS/AVI/ASF/WMV)/M2TS WMV9 (ASF/WMV) Real Video 8/9/10 (RM/RMVB) Audio: MP3、MPEG Audio、Dolby Digital、DTS 、...

  • Page 7: Front View

    HDMI OUT: Connects to the HDMI jack on the display; a single cable transmits both audio and video data. S/PDIF: Connects the ZIN-5005HD to a display that has an optical digital audio port, using an optical digital audio (also called S/PDIF) cable.

  • Page 8: Remote Control

    REMOTE CONTROL...

  • Page 9: Remote Control

    REMOTE CONTROL Press to turn on the ZIN-5005HD; press POWER again to switch to stand-by mode. Press to mute the sound. MUTE 0-9 number keys for selecting desired Number options. Video/movie chapter selection. GOTO Display the information of media files while INFO in play mode.
  • Page 10 instructions in the screen. Play/pause selected file. PALY/ PAUSE Return to previous file. PREV Go to next file. NEXT Stop playback and return to the previous STOP screen. Play films in slow mode. SLOW MOTION Enable/disable Left/Right speaker. Switch audio outputs. AUDIO Zoom video or image display on screen.

  • Page 11: Ⅱ Setting Up For Zin-5005Hd

    For composite video (yellow) and stereo audio (white and red) RCA Cable Y/Pb/Pr (RGB) For component video output For audio output S/PDIF Step2: Connect the ZIN-5005HD to the home network through wired LAN (Option A) or wireless LAN (Wi-Fi 802.11 b/g/n) (Option B)
  • Page 12 A. Plug the Ethernet cable to the “LAN” jack on the rear panel of ZIN-5005HD, for wired Internet connection. ZIN-5005HD will detect the network automatically. B. If you have the optional wireless USB dongle we approved, it is possible to connect ZIN-5005HD to the network wirelessly using Wi-Fi 802.11 b/g/n.

  • Page 13: Connect To Usb Devices

    Step3: Connect USB devices Step4: Power cord connection Plug one end of the power cord into the back of the ZIN-5005HD and the other end into a power outlet. ZIN-5005HD will start automatically without pressing any other button once the power is connected.
  • Page 14 Media” features. If your wired network equipment such as the IP Sharing router or AP (Access Point), uses DHCP to assign IP address, by default the ZIN-5005HD will automatically request the IP and other related information to set up ZIN-5005HD...

  • Page 15: Ⅲ Network Connections Wired

    Step 1: To access “Setup” on the main menu. Select “Network”. Step 2: Select “Wired” on the Network menu. Select “DHCP”. Step 3: Select Yes to implement DHCP network setting. ZIN-5005HD will automatically receive its IP address from a DHCP sever that is built into the...

  • Page 16: Wireless

    access point or IP sharing router. > Static IP Step 1: Select “Wired” on the Network menu. Select “Static IP”. Step 2: Input the value IP Address, Subnet mask, Gateway, and DNS text box respectively. PS Please acquire information of these setting values from your ISP（Internet Service Provider）first.
  • Page 17 _ Please use I-BT approved WI-FI dongle for wireless connection. > Infrastructure (AP) ZIN-5005HD performs a list of current wireless network connections- “SSIDs”. Along with its security protocols (WEP/WPA/WPA 2 key) and signal strength. Step 1: Select your preferred wireless network connection.
  • Page 18 > Ad-Hoc Setup Rename SSID Rename your wireless network connection. Wireless Security Set your wireless network as an open system or have it protected by WEP key first, in order to connect the ZIN-5005HD to the network.

  • Page 19: File Sharing Configuration

    Home Network Setup in Windows XP. Please refer to the following instructions to allow the ZIN-5005HD to access the shared folders on the remote PC. Step 1: Right click on the folder to be shared and select Sharing and Security.
  • Page 20 Step 3: You may now specify a “Share Name”, which will be used for users on the network to access the shared folder. The icon of the shared folder will be changed to showing a hand holding the folder. If your operating system is Windows Vista, please refer to the following instructions: (1) Open the Control Panel and then open Network and Sharing Center.

  • Page 21: Media Center

    You may also refer to Setup menu on the OSD screen of ZIN-5005HD to select wired or wireless connection. 4 Media Center Description Remote Enter OSD Menu > Play Media Under Play Media, select the media source from USB Device/ PCs/ UPnP/ Playlist.
  • Page 22 USB device. > PC Media Connect ZIN-5005HD to your PC using a USB 2.0 cable. By connecting your PC to the Local Area Network, you can play the media files on the remote PCs. Before you do so, please confirm the network settings and file-sharing setup have been finished successfully.

  • Page 23: Video Playback

    Remote Description Add to Playlist Select/cancel the files which will be added. Edit Rename/delete file. Note: For the files added to the playlist, ZIN-5005HD will categorize the media files with video/music/photo tags. VIDEO PLAYBACK...
  • Page 24 Description Remote Enter Play Media > Video Playback . Navigate the media file you want to play. The preview window will show the highlighted Edit Rename/delete file. Add to Playlist Add selected file to Playlist. Back Return to previous display. Full screen mode.

  • Page 25: Music Playback

    MUSIC PLAYBACK Description Remote Enter Play Media > Music Playback Navigate the media file you want to play. The preview window will show the file details of highlighted file. Edit Rename/delete file. Add to Playlist Add selected file to Playlist. Back Back to previous display.

  • Page 26: Photo Playback

    Go to next file. Stop playback and return to the previous display Music will continue playing as the background music when you leave MUSIC PLAYBACK menu. Press to stop playing. PHOTO PLAYBACK Description Remote Enter Play Media > Photo Playback Navigate the media file you want to play.
  • Page 27 Back Back to previous display. Full screen mode. THUMBNAIL MODE Description Remote Full screen mode. Back Back to previous display. Previous file. Go to next file. Leave thumbnail mode.
  • Page 28 FULL SCREEN MODE Description Remote Previous picture Next picture Rotate the viewing picture counterclockwise Rotate the viewing picture clockwise. Leave full screen mode. PS You can choose the preferred slide show effects in Setup menu. If you’d like to turn off the function, please enter Setup >...

  • Page 29: Bonus Features

    ◆ The ZIN-5005HD is connected to the network; ◆ The network is properly set up. For more information on this part, please refer to “Step 2” in “Setting up ZIN-5005HD” section, and “Network” under “Setup Menu”. BitTorrent is the leading and the most common peer-to-peer file-sharing communications protocol.
  • Page 30 USB storage device. It may take up to several minutes, according to the size of your USB device. Step 3: A message will pop up to ask you to choose either the external hard drive or the remote PC as the media download destination. Press to select one for the .torrent seeds.

  • Page 31: Setup Menu

    6 SETUP MENU AUDIO Description Remote Enter “Audio” setup menu. Select the item for adjustment. Confirm the change. Return to previous display. Item Options On/Off Night Mode HDMI LPCM Digital Output HDMI RAW SPDIF LPCM SPDIF RAW Change Audio L/R...

  • Page 32: Video

    VIDEO Description Remote Enter “Audio” setup menu. Select the item for adjustment. Confirm the change. Return to previous display. Item Options Pan Scan 4:3 Aspect Ratio Letter Box 4:3 Wide Screen 16:9 Full Screen HDMI Auto Resolution NTSC 480P 576P 720P 50HZ 720P 60HZ 1080i 50HZ...

  • Page 33: System

    SYSTEM Description Remote Enter “Audio” setup menu. Select the item for adjustment. Confirm the change. Return to previous display. Item Options English Menu Language Traditional Chinese Español Français Simplified Chinese Unicode (UTF 8) Text Encoding 简体中文 (GBK) 繁體中文(BIG5) Subtitle Size Moderate Small Software Version/ BOX ID/...

  • Page 34: Miscellaneous

    MISCELLANEOUS Description Remote Enter “Audio” setup menu. Select the item for adjustment. Confirm the change. Return to previous display. Item Options Off/2,5,10,30 Seconds/1,2 Minutes Slide Show Timer Off/Cross Fade/Left to Right/Top to Transition Effect Bottom/Waterfall/Snake/Dissolve/Str ip Left Down/All Effect Shuffle Off/On Background Music Off/On...

  • Page 35: Troubleshooting

    Use an Ethernet LAN cable not displayed. to connect from the Network jack of the ZIN-5005HD o the network router or Access Point. Or check the setting between your external USB wireless dongle and IP sharing.
  • Page 36 speed BT is a peer - to-peer download technology. It ◆ requires more people or torrents to share the files at the same time.
