- Page 1 ZP-320 HD Multimedia Player User’s Manual...
-
Page 2: Table Of Contents
Index Introduction ................................3 Package Contents..............................3 Product Overview..............................4 Panel Front side .............................. 4 Panel Back side............................... 4 Remote Control .............................. 5 Connect................................... 6 Setup ..................................6 Initial setup ..............................6 Setup Menu..............................7 Multimedia Jukebox ............................. 10 Playback the media files ..........................10 Movie.............................. -
Page 3: Introduction
Introduction ZP-320 is the first media player which truly decodes, playback and outputs High Definition 1080i in the market. Through the USB 2.0 port and the HDMI interface, ZP-320 playbacks the HD MPEG2/MPEG4-ASP Xvid / DivX movie or transport stream from the USB flash drive or hard disk drive to HDTV screen. -
Page 4: Product Overview
5. One stand 6. One YPbPr cable 7. One RCA cable 8. One quick installation guide Product Overview 2. 3. Panel Front side LED/button/connector: (1) POWER STANDBY: Press it to power on the device or put it into standby mode. (2) POWER indicator: It lights on when the power is plugged in. -
Page 5: Remote Control
DC IN: It connects the DC input of the Power Adapter. The power requirement is 12Vdc, 1.5 A. Remote Control MUTE: Mute POWER: Power on/Suspend MUSIC: Hotkey to view the music file PHOTO: Hotkey to view the photo file MOVIE: Hotkey to view the movie file RED / GREEN / YELLOW / BLUE: Special function Function Video... -
Page 6: Connect
Connect There are three ways shown below to connect this player to your TV set. Please choose one to apply. Basic connection: Power Cord: Connect the DC input in the device. Audio cable output: Connect the cables to TV set. CVBS video output (480i or 576i): Connect to TV set Advanced connection: Power Cord: Connect the DC input in the device. -
Page 7: Setup Menu
The second item is to setup the aspect ratio for your TV set. If your TV set is 4:3 then you can choose Pan Scan 4:3 or Letter Box 4:3. If you have wide-screen TV then you can choose 16:9. Use ▲▼ button to select one and press “ENTER”... - Page 8 The menu structure and options are listed below. 1. System Select this option to open the detail setting for the system. Menu Language: Select the OSD language among English, Chinese Traditional, Español, Franҫais, Deutsch, Italiano, Dutch and Chinese Simplified. Subtitle Encoding: Select the encoding for subtitle file, file name and folder name display from Unicode (UTF8), Chinese Simplified (GBK), and Chinese Traditional (BIG5).
- Page 9 System Info: It displays the firmware version. 2. Video Select this option to open the detail setting for video display. Aspect Ratio: Select one among these options “Pan Scan 4:3, Letter Box 4:3, 16:9”. Pan Scan 4:3: Select for a full-height picture with both sides cut. Letter Box 4:3: Select for the “wide screen”...
-
Page 10: Multimedia Jukebox
automatically, you have to select “HDMI RAW” format for 5.1 channel audio playback and “HDMI LPCM” for the stereo audio playback. Multimedia Jukebox Playback the media files You can playback the movies, music and photos in the connected USB storage via this device. Plug in the USB storage, and then press the three buttons “MUSIC, PHOTO, MOVIE”... - Page 11 Press the file title and it starts to playback the video. When the movie begins to play, the four key “Red, Green, Yellow, Blue” will be showed in the top of the TV screen. Red, Green, Yellow, Blue: When playing the video files supporting DVD menu such as ISO/IFO file, you can press red key for “Menu”, green key for “Audio”, yellow key for “Subtitle”...
- Page 12 the language of the subtitle. When playing the other formats of video file, you can press it to change the subtitle code among “OFF” for turning off the subtitle, “BIG5” for the traditional Chinese, and “GBK” for the simplified Chinese. When finishing the current video file, it will continue to play the next file in the directory to the last file.
-
Page 13: Music
Music Press the “MUSIC” button to enter the interface. Navigate to highlight the file and press enter to playback the file. When the file is highlighted, the right panel shows the detail information about the file including artist, title, album, genre and track. It will continue to play next file till the last file. -
Page 14: Photo
Photo Press the “PHOTO” button to enter the interface. Navigate to highlight the file and press “ENTER” to playback the file. When the file is highlighted, the right panel shows the detail information about the file. It will continue to play next file till the last file. You can also use the playback control while viewing photo. -
Page 15: Zoom In And Pan The Focus
Zoom in and pan the focus When viewing the photos, press “+” to zoom in and then “-” to change back. You can switch the rate between 2X, 4X, 8X and 16X. When zoom-in to the photo, press ▲▼◄► arrow keys to move the focus on the photo. -
Page 16: Edit The Media Files
information about the file. It will continue to play next file which is in the same kind of media till the last file. You can also use the playback control while playing the media files. Please refer to the section of video, music and photo playback. Edit the media files In the browser window, press the “EDIT”... -
Page 17: Delete
Delete Choose the “Delete” and the confirm window will pop up. Select “OK” to delete the file or “Return” to cancel. -
Page 18: Maintenance
Maintenance Reset the device You can press “MENU” to open the setup menu. To Reset the device, navigate to Setup menu and select “Restore Default” and press “ENTER”. Please refer to setup section for the details. Power on/Standby time The device needs sometime to power on. The time costs are listed below. Plug in the power ->... -
Page 19: Video/Audio Codec Support
Video/Audio codec support Codec Feature Others File container MPEG-1 MPEG-1 MPEG MPEG-2 MP@HL / MP@ML 480i/480p/576i/576p/720p/1080i MPEG Video DivX 3.11 DivX 4.12 Divx 3/4/5/6 DivX 5 480i/480p/576i/576p/720p/1080i Xvid DivX 6 Xvid: GMC not supported DivX HD Xvid 640x480, 30fps, Average Real Video 9 Real Video 450Kbps, Maximum 900Kbps,... -
Page 20: Specification
RPR option, the alert message will pop for notify the unsupported format. Specification Specification Model name ZP-320 Disc format FAT16/FAT32/NTFS (Read only)/UDF/EXT3 Subtitle Chinese Traditional/Chinese Simplified/UTF8 Aspect ratio Pan Scan 4:3 / Letterbox 4:3 /16:9 Interface Video 1x CVBS composite RCA Video 480i...
