CL
DIALOGUE CL-40
Amplified Cordless Telephone

Operating Instructions

Please read these Instructions carefully before use. Keep for future reference.
AMERIPHONE Inc., 12082 Western Ave., Garden Grove, CA 92841
(800) 874-3005, (714) 897-0808
M03900 CL-40
© AMERIPHONE CL-40 5270-0101
4/02
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dialogue CL-40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriphone Dialogue CL-40

Summary of Contents for Ameriphone Dialogue CL-40

  • Page 1: Operating Instructions

    ® DIALOGUE CL-40 Amplified Cordless Telephone Operating Instructions Please read these Instructions carefully before use. Keep for future reference. AMERIPHONE Inc., 12082 Western Ave., Garden Grove, CA 92841 (800) 874-3005, (714) 897-0808 M03900 CL-40 © AMERIPHONE CL-40 5270-0101 4/02...

  • Page 2: Table Of Contents

    Contents Safety Instructions...2 HANDSET Controls-Location and Function..5 BASE UNIT Controls-Location and Function... 7 Getting Started...9 Desk Mounting...11 Wall Mounting... 12 Basic Operation...13 Receiving Calls... 13 Placing Calls... 14 Using the Headset Feature... 14 Storing Numbers...16 Recalling Stored Numbers... 16 Security System...

  • Page 3: Important Safety Instructions

    Safety Instructions IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock and/or injury, always follow these basic safety precautions when using your cordless telephone equipment. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the telephone. 3.
  • Page 4 Safety Instructions 13. Do not use the telephone to report a gas leak in the vicinity of the leak. 14. Never install telephone wiring during a lightning storm. 15. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

  • Page 5: Battery Cautionary Instructions

    Safety Instructions SAVE THESE INSTRUCTIONS Battery Cautionary Instructions CAUTION: To reduce the risk of fire or personal injury, read and follow these instructions: 1. Use only the following type and size of battery pack: Cordless Telephone Battery Pack 3.6V, 600mAh Ni-Cd Battery Pack 2.

  • Page 6: Handset Controls

    HANDSET Controls MANUAL(430-0102-)V3.p65 02-10-23, 11:30...
  • Page 7 HANDSET Controls 1. Handset Antenna 2. IN USE/BATT LOW LED Indicator: Lights up when the HANDSET is in TALK mode. Blinks when battery power is low. 3. TALK Button: Press to answer an incoming call, to place a call or to end a call. 4.

  • Page 8: Base Unit Controls

    BASE UNIT Controls CHG/IN USE POWER C O R D L E S S A M P L I F I E D P H O N E MANUAL(430-0102-)V3.p65 02-10-23, 11:30...
  • Page 9 BASE UNIT Controls 1. TELEPHONE LINE CONNECTION Jack: For connecting the other end of your telephone line cord from the telephone line outlet. 2. POWER-IN CONNECTION Jack: For connecting the AC Adaptor to the base unit. 3. RINGER HI/MED/LOW: Set the base unit ringer to HI, MED, LOW. 4.

  • Page 10: Connecting Your Phone

    Getting Started Connecting Your Phone This section is a reference guide to the basic functions and operations of your cordless telephone. For more detailed descriptions of the operations and features of this telephone, refer to the Contents on page 1. 1.
  • Page 11 Getting Started (continued) 6. Raise or reposition the antenna on the base unit for the best reception. 7. We recommend not placing this unit next to appliances. Doing so may cause interference. 8. TONE/PULSE Select Switch: A. If your home is equipped with a Tone dialing system, set the TONE/PULSE select switch to the TONE position.

  • Page 12: Desk Mounting

    Desk Mounting Desk Mounting One of the special features of your equipment is the unique design of the MOUNTING BRACKET which can hold your phone at an angle of 15 There are two positions to choose from: 1. Normal position (Mounting Bracket not required) For normal position, as shown in Figure 1, place the base unit on any desired but suitable location.

  • Page 13: Wall Mounting

    Wall Mounting Wall Mounting You may choose to put the BASE UNIT of your cordless telephone on a wall. 1. With the back of the BASE UNIT facing up, connect the SHORT TELEPHONE LINE CORD to the telephone line jack. 2.

  • Page 14: Receiving Calls

    Cordless Telephone Operation Receiving Calls when the handset is in the base unit When the phone rings, lift the handset. The base unit’s IN USE LED indicator will light up. [NOTE: The handset’s RINGER SWITCH must be in the “ON” position for the Ringer to operate.
  • Page 15 Cordless Telephone Operation Caution: Repeated incremental exposure to amplification levels greater than 18 dB may be harmful to individuals without hearing disabilities. Therefore, do not remove the warning label attached to the back of the handset. If it is likely that a visually impaired person will use the telephone, securely attach the provided warning printed in Braille to the back of the handset (See, Diagram A).

  • Page 16: Placing Calls

    Cordless Telephone Operation Placing Calls 1. Press the TALK button. The IN USE LED indicator will light up. 2. Listen for a dial tone. 3. Dial the phone number. 4. When you have finished with your call, press the TALK button again. The IN USE LED indicator will turn off.
  • Page 17 Cordless Telephone Operation Direct Audio Connection The AUDIO output jack allows you to connect your CL-40 to other assistive listening device such as a cochlear implant. To connect an assistive listening device: Plug a compatible auxiliary cable (available from Ameriphone dealers) into the AUDIO Jack.

  • Page 18: Recalling Stored Numbers From Memory

    Cordless Telephone Operation Storing Numbers Do not press the TALK button after taking the handset off of the cradle. 2. Press the MEMO button. 3. Dial the number you want to store. 4. Press the MEMO button again. 5. Dial the index number (0-9) where you want to store that number. You will hear one confirmation beep.

  • Page 19: Security System

    Security Security Your cordless telephone uses a digital coding security system to prevent unauthorized use of your telephone line by another nearby cordless telephone. The system has its own identifying signal created by microcomputers in both the base unit and handset. Security Code This telephone has an internal security code with 65,536 possible combinations.

  • Page 20: Recharging The Battery Pack

    Recharging the Battery Pack Battery Type Use the following type and size of battery pack: Cordless Telephone Battery Pack 3.6V, 600mAh Ni-Cd Battery Pack Recharging the Battery Pack The nickel cadmium (Ni-Cd) battery pack in the handset can be recharged many times using the built-in charger in the base unit.

  • Page 21: Changing The Battery Pack

    Changing the Battery Pack Changing the Battery Pack The battery pack provides power for the handset of your cordless telephone. To Replace the Battery Pack: 1. Remove the HANDSET BATTERY COMPARTMENT COVER by pressing the circular rib on top of the cover and sliding it down. 2.

  • Page 22: Problem Solving

    Problem Solving Problem Solving Section For your assistance, we have listed below a few common problems. Phone does not work, check the following: 1. Base unit is plugged into power source. 2. Handset is charged. 3. TONE/PULSE switch is in the right position. 4.

  • Page 23: Technical Information

    Technical Information Technical Information This cordless telephone uses radio frequencies to allow mobility. There are certain difficulties in using radio frequencies with a cordless telephone. While these are normal, the following could affect the operation of your system. Noise Electrical pulse noise is present in most homes at one time or another. This noise is most intense during electrical storms.

  • Page 24: Fcc Requirements

    FCC Requirements Federal Communications Commission Requirements This equipment complies with Part 68 of FCC Rules. A label on the BASE UNIT of this equipment contains, among other information, the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment. You must, upon request, provide this information to your telephone company.
  • Page 25 FCC Requirements Federal Communications Commission Requirements (continued) Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
