MODEL NO. 40151000 & 401510CA
ASSEMBLY & OPERATING INSTRUCTIONS
This safety alert symbol identifies important safety messages in this manual.
Failure to follow this important safety information may result in serious injury
or death.
LS112-794-0810
Rev. 2
10 TON HORIZONTAL LOG SPLITTER
Owner's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpeeCo SplitMaster 40151000
Summary of Contents for SpeeCo SplitMaster 40151000
- Page 1 10 TON HORIZONTAL LOG SPLITTER MODEL NO. 40151000 & 401510CA Owner’s Manual ASSEMBLY & OPERATING INSTRUCTIONS This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death.
-
Page 2: Table Of Contents
Table of Contents Page(s) Important Safety Information......................... Intended Use ......................... Personal Protective Equipment ....................Safety Decals ........................General Safety ........................Preparation of the Log ......................Work Area ........................... Operation of the Log Splitter ....................Repair and Maintenance Safety ..................... Hydraulic Safety ........................Fire Prevention ........................ -
Page 3: Important Safety Information
WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly. - Page 4 PART NUMBER: 52060700 LOCATION: FRONT OF TONGUE PART NUMBER: 52055200 LOCATION: BOTH SIDES OF RAM Page 2...
-
Page 5: General Safety
GENERAL SAFETY Failure to follow these instructions may result in serious injury or death. EVER NEVER allow children to operate this log splitter. NEVER allow adults lacking proper instructions and understanding to operate this log splitter. KEEP all people and pets a minimum of 10 feet away from your work area when operating this log splitter. Only the operator is to be near the log splitter during use. -
Page 6: Repair And Maintenance Safety
KNOW how to stop the log splitter and disengage the controls before operating it. NEVER place hands or feet between the log and splitting wedge during forward or reverse stroke. Serious injury or death could result. NEVER straddle or step over the log splitter during operation. NEVER reach or bend over the log splitter to pick up a log. -
Page 7: Hydraulic Safety
HYDRAULIC SAFETY The hydraulic system of your log splitter requires careful inspection along with the mechanical parts. Be sure to replace frayed, kinked, cracked or otherwise damaged hydraulic hoses or hydraulic components. NEVER check for leaks of hydraulic fluid with your hand. Fluid escaping from a small hole can be almost invisible. Escaping fluid under pressure can have sufficient force to penetrate skin causing serious personal injury or even death. -
Page 8: Towing Safety
IMPORTANT NOTE: This log splitter is equipped with an internal combustion engine and should not be used on or near any unimproved forest- covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in efffective working order by the operator. -
Page 9: Assembly Instructions
IMPORTANT NOTICE We, the manufacturer, reserve the right to change the product and/or specifications in this manual without notification. The manual is for information usage only and the pictures and drawings depicted herein are for reference only. ASSEMBLY INSTRUCTIONS NOTE: This log splitter was partially assembled at the factory. Refer to the drawing and parts list should it become necessary to disassemble the unit for repair or replacement of parts. -
Page 10: Engine Oil Recommendations
CAUTION: DO NOT START OR RUN THE ENGINE BEFORE ADDING OIL IN THE HYDRAULIC RESERVOIR AND OIL IN THE ENGINE. ENGINE OIL RECOMMENDATIONS Use 4-stroke automotive detergent oil. SAE 10W-30 is recommended for general use. Refer to the SAE Viscosity Grades chart on page 17 of your engine owner’s manual for average temperature ranges. -
Page 11: Towing
OPERATION WARNING: See safety information related to operation of the log splitter on page 3 and 4 of this manual. Make sure that you have the recommended personal protective equipment described on page 1. 1) Set up the log splitter in a clear, level area and block the wheels. Make sure that the suction port on the tank is always on the lower side of the log splitter. -
Page 12: Parts List
MODEL NO. 40151000 LOG SPLITTER Illustration 1 Reference Part No. Description Quantity 40127800 Frame/Axle 40035500 Tire 1/8” x 1” Cotter Pin 3/4” Washer 07096700 Lock Pin 5/16” x 1-1/2” Hex Cap Bolt 40128000 Ground Stand 7/16” x 1-1/2” Hex Cap Bolt 5/16”... - Page 13 MODEL NO. 40151000 LOG SPLITTER 13 14 Illustration 2 Reference Part No. Description Quantity 40128100 Tank/beam 3/8” Nylock Nut 40128300 Push Plate 3/8” x 2-1/2” Hex Cap Bolt 39039100 Swivel Elbow, 3/4”, 1/2” 390410C0 Auto-Return Valve 39034300 1/2”-1/2” Hex Nipple 39013300 2-3/4”...
- Page 14 Illustration 3 Engine/Pump Assembly Reference Part Number Description Qty. 5/16”-18 UNC Nylock Nut 5/16” x 1-1/4 Grade 5 Bolt M8 x 1.25 x 20mm Bolt 39026100 Pressure Hose 39053900 196 cc Engine 39071800 2.5 GPM Pump 40034800 3/16” x 1” Square Key 40081200 Pump Mount 400833L0...
- Page 15 NOTE: Some of the 40151000 log splitters are equipped with the pump shown below. Please make a visual identification of your pump before ordering replacement parts or calling for service. Illustration 3 Engine/Pump Assembly Reference Part No. Description Quantity 39053900 6.5 HP Speeco Engine...
-
Page 16: Notes
IMPORTANT NOTICE We, the manufacturer, reserve the right to change the product and/or specifications in this manual without notification. The manual is for information usage only and the pictures and drawings depicted herein are for reference only. NOTES Model No. ____________________ Serial No. -
Page 17: Specifications
SPECIFICATIONS " " " " " " " " l l i i f f...
Need help?
Do you have a question about the SplitMaster 40151000 and is the answer not in the manual?
Questions and answers
Filling hydraulic fluid
To fill hydraulic fluid in the SpeeCo SplitMaster 40151000:
1. Insert a funnel into the return line (15) as shown in Illustration 2.
2. Fill approximately 2 gallons of AW46 hydraulic oil until the fluid is visible in the clear line at tank level.
- Use automatic transmission fluid instead if temperatures are below 32°F.
- Use only clean oil and prevent dirt from entering the reservoir.
3. Attach return line (12) to valve (6) and secure with hose clamp (16).
4. Start the engine and cycle the cylinder using the valve handle to remove air.
5. Turn off the engine, cycle the valve handle to relieve pressure, and disconnect the return line at the valve.
6. Add approximately 1/2 gallon of fluid to top off.
