ASSEMBLY & OPERATING INSTRUCTIONS
This safety alert symbol identifies important safety messages in this manual.
Failure to follow this important safety information may result in serious injury
or death.
LS144-829-0512
Rev. 3
22 TON VERTICAL/HORIZONTAL
MODEL NO.
S401622BL
Owner's Manual
LOG SPLITTER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpeeCo SPLITMASTER S401622BL
Summary of Contents for SpeeCo SPLITMASTER S401622BL
- Page 1 Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. 22 TON VERTICAL/HORIZONTAL LOG SPLITTER MODEL NO. S401622BL Owner’s Manual ASSEMBLY & OPERATING INSTRUCTIONS This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death.
-
Page 2: Table Of Contents
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. Table of Contents Page(s) Important Safety Information......................... Intended Use ......................... Personal Protective Equipment ....................Safety Decals ........................General Safety ........................Preparation of the Log ......................Work Area ........................... -
Page 3: Important Safety Information
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. WARNING: Read and thoroughly understand all instructions in this manual and on safety decals before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. - Page 4 Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. PART NUMBER: S52062200 LOCATION: TOP OF CYLINDER PART NUMBER: S52062300 LOCATION: STRIPPER PLATE, OPERATOR SIDE PART NUMBER: S52062600 LOCATION: STRIPPER PLATE, NON OPERATOR SIDE PART NUMBER: S52062400 LOCATION: HYDRAULIC TANK LOWER TANK, RIGHT CORNER PART NUMBER: S52062100 LOCATION: TOP OF HYDRAULIC CYLINDER Page 2...
-
Page 5: General Safety
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. GENERAL SAFETY ALWAYS keep the operator’s manual nearby for reference. Reread the manual periodically. ALWAYS keep all bystanders and pets a minimum of 10 feet away from your work area when operating this log splitter. -
Page 6: Repair And Maintenance Safety
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. ALWAYS block the wheels to prevent movement of the log splitter while in operation. KNOW how to stop the log splitter and disengage the controls before operating it. -
Page 7: Hydraulic Safety
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. MAINTENANCE & SAFETY The hydraulic system of your log splitter requires careful inspection along with the mechanical parts. Be sure to replace frayed, kinked, cracked or otherwise damaged hydraulic hoses or hydraulic components. NEVER check for leaks of hydraulic fluid with your hand. Fluid escaping from a small hole can be almost invisible. Escaping fluid under pressure can have sufficient force to penetrate skin causing SERIOUS INJURY or even DEATH. Leaks can be safely detected by passing a piece of cardboard over the suspected leak and looking for discoloration. -
Page 8: Towing Safety
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. IMPORTANT NOTE – (spark arrester): As a precautionary measure against possible flying sparks, always take a Class B fire extinguisher with you when operating this log splitter in dry areas. This log splitter is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). -
Page 9: Assembly Instructions
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. ASSEMBLY INSTRUCTIONS NOTE: This log splitter was partially assembled at the factory. Refer to the drawings and parts list should it become necessary to disassemble the unit for repair or replacement of parts ITEM NO. DESCRIPTION QTY. Beam Assembly Beam Lock Assembly Tank Assembly... - Page 10 Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. STEP 3: Attach the tongue assembly (5) to the tank assembly (1) using two 1/2” NC x 4-1/2” hex cap bolts (2), two 1/2” lock washers (3) and two 1/2” hex nuts (4). Tighten.
- Page 11 Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. STEP 5: Connect the end of the 1/2” ID x 38” hydraulic pressure hose (1) coming from the fitting on the pump to the fitting on the valve. See illustrations below. STEP 6: Slide one hose clamp on the end of the 3/4” x 56” hydraulic return hose (2) that comes from the fitting on the filter. Then connect the hose to the fitting on the valve. Tighten hose clamp. See illustrations below. Area of DETAIL A Detail SCALE 1:3 ITEM NO. DESCRIPTION QTY. 1/2” X 38” Pressure Hose 3/4” x 56” Return Hose...
-
Page 12: Replacement Parts
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. REPLACEMENT PARTS TANK/ENGINE ASSEMBLY BREAKDOWN ITEM NO. PART NO. DESCRIPTION QTY. 5/16” Flat Washer 5/16”-18 UNC Nylock Nut 5/16” x 1-1/2” GR 5 Bolt S40118800 Tank S390604B0... - Page 13 Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. BEAM ASSEMBLY BREAKDOWN ITEM NO. PART NO. DESCRIPTION QTY. 1/2” Hex Nut 1/2” Regular Lock Washer 1/2” x 3-1/4” Hex Bolt S390118BC 4” x 24” Hydraulic Cylinder S39032000 3/4”...
-
Page 14: Operating Instructions
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. -
Page 15: Operation
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. CAUTION: TURN FUEL SHUT OFF VALVE TO THE “OFF” POSITION PRIOR TO TOWING. FAILURE TO DO SO MAY RESULT IN FLOODING THE ENGINE. NOTE: The engine maximum governed speed is preset at the factory at 3600 RPM no load speed. When splitting wood the throttle should be set at the maximum speed to develop the horsepower required for the pump. -
Page 16: Warranty/Service Information
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. IMPORTANT NOTICE We, the manufacturer, reserve the right to change the product and/or specifications in this manual without notification. The manual is for information usage only and the pictures and drawings depicted herein are for reference only. NOTES Warranty Repair and Service Do not return this product to the store for warranty issues or repair. Call 1-800-525-8322 for the location of the nearest service center. -
Page 17: Specifications
Free Shipping on 22 Ton Speeco Log Splitters at Northern Hydraulics. Call 1-800-823-4937. SPECIFICATIONS Engine SpeeCo 212cc Pump Two-Stage, 11 gpm Cylinder 4 in. Diameter x 24 in. Stroke Valve Auto-Return Maximum Splitting Force 22 Tons Maximum Log Length 26 in.
