- Page 1 Internal Use Only Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL MODEL : VK8710HFN, V-K9001HTM, VKC902HTW VKC902HTM, V-KC902HTM CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. July, 2007 P/NO : MFL37414503 Printed in Korea...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS..........................3 CAUTIONS..............................3 DESCRIPTION..............................4 SPECIFICATIONS ............................4 DISASSEMBLY ............................5~6 TROUBLE SHOOTING GUIDE ........................7~9 SCHEMATIC DIAGRAM ..........................10 CIRCUIT DIAGRAM ...........................11 EXPLODED VIEW ..........................12~15 REPLACEMENT PARTS LIST ......................16~63... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Motor filter(Air Cleaner) 3. Avoid suction such materials as : 1) This filter is reusable. 1) Liquid or wet dust : 2) Never use the vacuum cleaner without filter. Clogs the ventilation holes, reduces the suction It may damage the motor. -
Page 4: Description
DESCRIPTION Hose Assembly, Flexible Pipe Assembly, Cord Reel Power Cord Telescopic Button Dust Tank Nozzle Assembly, Nozzle Assembly,Turbine Turbine(Mini) CANISTER ATTACHMENTS BRUSH ASSEMBLY, DUST NOZZLE, CREVICE SPECIFICATIONS • MODEL : REFER TO THE COVER PAGE • PACKING DIMENSION : 605 330 380 (D W H) •... -
Page 5: Disassembly
DISASSEMBLY NOTE : Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power supply cord from the wall outlet. • Almost all of the parts of this vacuum cleaner can be 3) Disassemble the body cover, raising the body cover. disassembled with a screw driver and each Pull out the two lead wire housing. -
Page 6: Disassembly
3. Cord Reel Assembly Replacement 4. Disassembly of Motor Housing. 1) Lift the cord reel assembly from body base. 1) Remove the two screws fastening the body base. 2) Remove the one screw fastening the body base. Cord Real Assembly... -
Page 7: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE 1. SWITCH ON BUT MOTOR DOSE NOT TURN. CHECKING CAUSE SOLUTION CHECK THE POWER The fuse is melt down Exchange the fuse SOURCE in the coverknife switch Poor plug insertion Insert again Power cord cut Repair or exchange Interior lead wire cut Exchange the lead wire Motor(stator armature) coil cut... - Page 8 4. SWITCH OFF BUT MOTOR TURNS Poor connection Repair. 5. WEAK SUCTION POWER Motor armature cut Exchange the motor Foreign matters attached to Low rotation speed Remove the foreign matters the impeller Inquire to the power utility Low voltage company Hose and extension wands Remove the foreign matters are clogged with foreign...
- Page 9 6. VIBRATION NOISES Loose parts Secure firmly Unbalanced motor assembly Exchange or repair the motor Foreign matters are attached Remove the foreign matters to the impeller Armature is cut or foreign Exchange the motor matters attached Remove foreign matters 7. RADIO, TV RECEPTION DISTURBANCE Poor cord, lead wire Exchange cord, lead wire Poor electric connector or...
-
Page 10: Schematic Diagram
SCHEMATIC DIAGRAM MICRO S/W SLIDE VOLUME MAIN COMPRESS MOTOR C-2 TYPE -10-... -
Page 11: Circuit Diagram
CIRCUIT DIAGRAM -11-... -
Page 12: Exploded View
#EV# EXPLODED VIEW BASE ASSEMBLY, BODY VK8710HFN(V-KC902HTM.AXRQBWT) V-KC902HTM(V-KC902HTM.ALSQSAF) V-KC902HTM(V-KC902HTM.AXRQBNL) VKC902HTW(V-KC902HTM.AMWQLGU) V-KC902HTM(V-KC902HTM.AMWQLGH) V-KC902HTM(V-KC902HTM.AMWPECC) VKC902HTM(V-KC902HTM.AXRQLGU) V-KC902HTM(V-KC902HTM.AMWRLAP) V-KC902HTM(V-KC902HTM.AMWPBRL) V-KC902HTM(V-KC902HTM.AMWQLGE) V-KC902HTM(V-KC902HTM.AXRPLAR) V-KC902HTM(V-KC902HTM.AMWPMEC) V-K9001HTM(V-KC902HTM.ADTQRUA) V-KC902HTM(V-KC902HTM.AXRQDAG) V-KC902HTM(V-KC902HTM.AMWQLTK) V-KC902HTM(V-KC902HTM.ADTQLGD) V-KC902HTM(V-KC902HTM.AXRQSBI) V-KC902HTM(V-KC902HTM.AMWPLMC) V-KC902HTM(V-KC902HTM.AXRQEAK) ACQBZ1 MFGBF1 MHYBC1 MCKBZ1 MCQBZ1 EAUBA1 MCKBF1 MCQBA1 ACQBM1 ADVBF1 MHABA1 MDSBA2 MDSBA4 MHJBR1 MDSBA3... - Page 13 #EV# COVER ASSEMBLY, BODY MCKCT1 MDSCA3 MFCCR1 ABNCA1 MHYCC1 MCZCD1 MCKCH1 MDSCA1 MEBCC1 MCKCA1 MDSCA2 MBGCR1 MHYCC2 MCKCB1 MDSCA4 AEMCC1 MGECS1 MJHCM1 MDTCA1 EAUCA1 EADCS1 EADCS2 MCKCZ1 MGECC1 MEJCC1 -13-...
- Page 14 #EV# TANK ASSEMBLY, DUST AJLTD1 MCKTS1 MBLTT1 MJMTC1 MJCTA1 MGJTB1 MGJTR1 MCKTH1 MJMTD1 MDTTA1 -14-...
- Page 15 #EV# ACCESSORIES AEMAF1 AGBN57 AGRPT1 MASNB1 AHRNA1 AHRNS1 AGBN51 ABCAD1 MFVAC1 -15-...
