DeltaLab Digital Delay DD1 Owner's Manual

Deltalab dd1 digital delay pedal
Hide thumbs

Advertisement

Quick Links

Digital Delay
DD1
Owner's Manual

Advertisement

loading

Related Manuals for DeltaLab Digital Delay DD1

Summary of Contents for DeltaLab Digital Delay DD1

  • Page 1 Digital Delay Owner’s Manual...
  • Page 2 IMPORTANT SAFEGUARDS For your protection, please read these safety To prevent fire or hazard, do not warning expose the unit to rain or moisture. Instructions completely before operating the This symbol is intended to alert the user to appliance, and keep this manual for future the presence of non-insulated “dangerous reference Carefully observe all warnings, voltage”...

  • Page 3: Table Of Contents

    CONTENTS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 speciFications .

  • Page 4: Features

    The DD1 Digital Delay creates echo effects from short slap-back to longer repeating echo. The DD1 adds echo effects to the sound of electric guitar and electronic keyboards. Features: • Sturdy metal case design •...

  • Page 5: Specifications

    SPECIFICATIONS input impedance 500K ohms output load impedance >10K ohms equivalent input noise -100dBm power supply One 9 Volt Battery or external 9VDC adapter power consumption 20ma size 4.75 X 2.50 X 1.38 Weight 1.2lbs www .deltalabeffects .com...

  • Page 6: Controls And Connections

    CONTROLS AND CONNECTIONS TIME REPEATS LEVEL D D 1 Digital Delay...

  • Page 7: Operation

    OPERATION 1. Input - Connect your instrument to input jack. The circuit is turned on when a cable is inserted. 2. Time - adjusts speed of echo repeats. 3. Repeats - adjusts how many times the echoes are heard. 4. Level - adjusts the amount of effect heard. 5.

  • Page 8: Notes

    NOTES 1. To avoid damage to electronics and speakers, always turn down the amplifier when connecting or disconnecting effects or an instrument. 2. Disconnect the battery when storing the unit for long periods of time. 3. a loss of delay signal will occur when the battery is running low. if so, replace the 9 Volt battery.

  • Page 9: Battery Replacement

    1. Push the tab on the battery cover and lift. 2. Carefully unplug battery. 3. replace battery with standard 9 Volt battery. 4. Close cover. Unplugging cables from input of DD1 when not in use will turn the unit off and prolong battery life. www .deltalabeffects .com...

  • Page 10: Application

    APPLICATION we recommend placing the DeltaLab Digital Delay before your amplifier and after other effects such as DeltaLab SC1 Stereo Chorus or rD1 rock Distor- tion. Feel free to experiment with placement in the effects chain. Different placements will result in different tones.

  • Page 11: Warranty

    This product may contain a chemical(s) known to the state of California to cause cancer or birth defects or other reproductive harm. DeltaLab, P.O. Box 5111, Thousand Oaks, CA 91359-5111 all trademarks and registered trademarks mentioned herein are recognized as the property of their respective holders.
  • Page 12 P.O. Box 5111 Thousand Oaks, CA 91359-5111 U.S.A. www .deltalabeffects .com...
