DeltaLab Stereo Chorus SC1 Owner's Manual

Effects pedal
Hide thumbs

Advertisement

Quick Links

Stereo Chorus
SC1
Owner's Manual

Advertisement

loading

Related Manuals for DeltaLab Stereo Chorus SC1

Summary of Contents for DeltaLab Stereo Chorus SC1

  • Page 1 Stereo Chorus Owner’s Manual...
  • Page 2 IMPORTANT SAFEGUARDS For your protection, please read these safety To prevent fire or hazard, do not warning expose the unit to rain or moisture. Instructions completely before operating the This symbol is intended to alert the user to appliance, and keep this manual for future the presence of non-insulated “dangerous reference Carefully observe all warnings, voltage”...

  • Page 3: Table Of Contents

    CONTENTS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 speciFications .

  • Page 4: Features

    • Sturdy metal case design • True bypass switching • Easy to use Rate, Depth and Level controls • Dual outputs • Powered by either a 9 Volt battery or a DeltaLab PS9 DC adapter (not included) • 5 Year Warranty • Sounds great!

  • Page 5: Specifications

    SPECIFICATIONS input impedance 500K ohms output load impedance >10K ohms equivalent input noise -90dBm power supply One 9 Volt Battery or external 9VDC adapter power consumption 20ma size 4.75 X 2.50 X 1.38 Weight 1.2lbs www .deltalabeffects .com...

  • Page 6: Controls And Connections

    CONTROLS AND CONNECTIONS...

  • Page 7: Operation

    OPERATION 1. Input – Connect your instrument to input jack. The circuit is turned on when a cable is inserted. 2. Rate – adjusts the speed of modulation. 3. Depth – adjusts depth (or amplitude) of modulation. 4. Level – adjusts the amount of effect mixed with your “dry” signal. 5.

  • Page 8: Notes

    NOTES 1. To avoid damage to electronics and speakers, always turn down the amplifier when connecting or disconnecting effects or an instrument. 2. Disconnect the battery when storing the unit for long periods of time. 3. a loss of chorus will occur when the battery is running low. if so, replace the 9 Volt battery.

  • Page 9: Battery Replacement

    BATTERY REPLACEMENT 1. Push the tab on the battery cover and lift. 2. Carefully unplug battery. 3. replace battery with a standard 9 Volt battery. 4. Close cover. Unplugging cables from input of SC1 when not in use will turn the unit off and prolong battery life.

  • Page 10: Application

    APPLICATION we recommend placing the DeltaLab Stereo Chorus before your amplifier and after distortion effects such as DeltaLab rD1 rock Distortion. Feel free to experiment with placement in the effects chain. Different placements will result in different tones.

  • Page 11: Warranty

    This product may contain a chemical(s) known to the state of California to cause cancer or birth defects or other reproductive harm. DeltaLab, P.O. Box 5111, Thousand Oaks, CA 91359-5111 all trademarks and registered trademarks mentioned herein are recognized as the property of their respective holders.
  • Page 12 P.O. Box 5111 Thousand Oaks, CA 91359-5111 U.S.A. www .deltalabeffects .com...
