DC TO AC POWER INVERTER
L-Series User Manual
Cooler housing design!!
Anytime, Anywhere
Power it up wherever you go!!
Before install and use your Inverter,
read the User Manual and safety instructions.
12V / 24V / 48Vdc Input
115V / 230Vac Output
150W ~ 6000W Output cont.
VER.C/980720

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 0150LN and is the answer not in the manual?

Questions and answers

Related Manuals for Power Master 0150LN

Summary of Contents for Power Master 0150LN

  • Page 1 DC TO AC POWER INVERTER 12V / 24V / 48Vdc Input 115V / 230Vac Output 150W ~ 6000W Output cont. L-Series User Manual Before install and use your Inverter, read the User Manual and safety instructions. Cooler housing design!! Anytime, Anywhere Power it up wherever you go!! VER.C/980720...

  • Page 2: Table Of Contents

    CONTENTS A. General Introduction ................... 3 B. Application......................3 C. Features ....................... 3 D. Safety Instructions ....................3 E. Front View & Main Functions ................5 F. Rear View & Main Functions ................7 G. Pre-Installation Information ................8 H. Electrical Requirements ..................8 I.

  • Page 3: General Introduction

    A. General Introduction We are experts in DC to AC Power Inverter and Solar Inverter. Our engineers are making use of advanced technological design that results in an inverter that is more excellent, smarter and easier to use than any other inverter with similar power ratings. We have been developed to provide you with years of trouble free operation.
  • Page 4 Explosive Gas Precautions This equipment contains components that can produce arcs or sparks. To prevent fire or explosion do not install in compartments containing batteries or flammable materials, or in locations that require ignition-protected equipment. This includes any space containing gasoline-powered machinery, fuel tanks, or joints, fittings, or other connections between components of the fuel system.

  • Page 5: Front View & Main Functions

    E. Front View & Main Functions 0150LN 0350LN 0650L 1200L 1800L 3000L 6000L...
  • Page 6 ON / OFF switch Power ON/OFF switch, leave in the OFF position during installation. LED INDICATION • Over Volt: Over Voltage Protection. • Over Temp.: Over Temperature Protection. • Under Volt: Under Voltage Protection. • Over Load: Over Load Protection. •...

  • Page 7: Rear View & Main Functions

    F. Rear View & Main Functions 0150LN 0350LN 0650L 1200L 1800L 3000L 6000L...

  • Page 8: Pre-Installation Information

    Ventilation window Do not obstruct; allow at least 1 inch for airflow. Battery terminals Connect to 12V / 24V / 48V battery or other 12V / 24V / 48V power source. (+) is positive, (-) is WARNING! negative. Reverse polarity connection will blow internal fuse and may damage inverter permanently.
  • Page 9 AC safety Grounding—The AC input ground wire must connect to the incoming ground from your AC utility source. The AC output ground wire should go to the grounding point for your loads. (for example, a distribution panel ground bus) Neutral Grounding 115V models: The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation.

  • Page 10: Connection And Testing

    WARNING! Do not operate the power inverter without connecting it to ground. Electrical shock hazard may result. Making DC Wiring Connections Follow this procedure to connect the battery cables to the DC input terminals on the inverter. Your cables should be as short as possible (ideally, less than 10 feet / 3 meters) and large enough to handle the required current, in accordance with the electrical codes or regulations applicable to your installation.

  • Page 11: Operation

    Set the power switch to the ON position. Check the power and RUN / GREEN POWER LED indicators on the front panel of the inverter source. If the LED is not lit, check your power source and the connections to inverter. The other indicators should be off. Set power inverter switch to the OFF position.

  • Page 12: Trouble Shooting

    Adjust load sensitivity for green power mode as follows: • Turn OFF all AC loads, keeping the AC wiring connected. Some loads such as TVs must be turned OFF at the power point as they can still represent a small load to the inverter. •...

  • Page 13: Maintenance

    • Do not operate high power loads with the power inverter while watching television. • Make sure that the antenna feeding your television provides an adequate (“Snow free”) signal and that you are using good quality cable between the antenna and the television. •...

  • Page 14: Specifications

    O. Specifications 150W (L-N) 350W (L-N) 650W (L) 1200W (L) 1800W (L) 3000W (L) 6000W (L) Model No. Continuous Output 150W 350W 650W 1200W 1800W 3000W 6000W Power Output Power 300W 700W 1300W 2400W 3600W 6000W 12000W Surge AC Output 100 ~ 120v ±1~2% Voltage 200 ~ 240v ±1~2% adjustable...
