7.20. Fitting and removing Oetiker clamps
1
1
2
2
Use a suitable pair of pliers to remove the
clamp (as illustrated)
Saeco International Group
Extract the display and the
keypad
1) Boiler connection
2) Other connections
Tighten the clamp as illustrated
Rev. 00 / June 2010
07 DISASSEMBLY
CPU and display card assembly
09
