EXPRELIA
6.1.

Repair schedule

Action
1 Visual inspection (transport damage)
2
Machine data check (rating plate)
3
Operational check / problem analysis
4 Opening machine
5
Visual inspection
6
Operational tests
7 Repairing the faults encountered
8
Checking any modifications (view info, new sw, etc.)
9
Service activities in accordance with the operating schedule
10 Internal cleaning
11 Operational test while the appliance is open
12 Assembly
13 Final inspection test
14 Draining the circuit (in winter)
15 External cleaning
16 Lubricating the brewing unit with suitable grease
17 Insulation test HG 701 (dielectric)
18 Documentation
6.2.

Service schedule

S
Replacement
ES Visual inspection
D
Descaling
CF Operative check
Component
Water filter:
Water tank lip seal
Boiler pin O-ring
Brewing unit
Hoses, attachments and Oetiker clamps
Coffee circuit pump
Hot water/steam circuit pump
Gearmotor:
Coffee grinder
Water circuit
Frothing valve assembly
Multi-way valve (solenoid pilot)
Saeco International Group
P
Cleaning
TR Noise test
R
Adjustment
Action
P/S/CF
S/CF
S/CF
ES/P/CF
ES/CF
ES/TR/CF
ES/TR/CF
ES/TR/CF
P/R/CF
D/CF
ES/S/CF
ES/S/CF
Rev. 00 / June 2010
06 STANDARD CHECKS
Support/tool
Grease solvent / Grease
Vacuum cleaner / brush
Saeco descaler
01
Page / 02
