Dino-Lite Handheld Digital Microscope

Thank you for choosing Dino-Lite Handheld Digital Microscope!

Dino-Lite Handheld Digital Microscope has a wide scope of applications, such as,

1. Skin Check

2. Scalp Check

3. Industrial Inspection e.g. Printing Circuit Board(PCB)inspection, electronics

device inspection

4. Visual Assistance

5. Printing Inspection

6. Textile Inspection

7. Jewelry Inspection

8. Science Learning

9. ..... etc.

Please read this manual carefully before using Dino-Lite Handheld Digital

Microscope.

Dino-Lite Handheld Digital Microscope User's Manual

www.agelectronica.com

AM-311S/AM311-ST

User's Manual

www.agelectronica.com

Table of Contents

Need help?

Do you have a question about the AM-311S and is the answer not in the manual?

Questions and answers

Summary of Contents for Dino-Lite AM-311S

Page 1 Dino-Lite Handheld Digital Microscope AM-311S/AM311-ST User’s Manual Thank you for choosing Dino-Lite Handheld Digital Microscope! Dino-Lite Handheld Digital Microscope has a wide scope of applications, such as, 1. Skin Check 2. Scalp Check 3. Industrial Inspection e.g. Printing Circuit Board(PCB)inspection, electronics device inspection 4.
Page 2: Table Of Contents
Windows XP ....................6 Windows 2000 ................... 10 Windows 98se .................... 13 Connecting Procedure..................19 Operate Dino-Lite Handheld Digital Microscope ..........19 DinoCapture Application Software..............20 Picture / Video Folder .................. 21 Menu Function List..................25 Open The Picture ..................28 The opened picture can be displayed in full screen by clicking ....
Page 3: Product Specifications
When hands are wet, do not plug in or remove the adaptor or other connectors. Using or storing Dino-Lite Handheld Digital Microscope, do not plug in any other cables, not belong to Dino Digital Microscope. Do not use any detergent or volatile solution, which will damage the camera case, painted surfaces &...
Page 4: Contents And Name Of Parts
USB Cable《USB2.0 / 1.1》 (1.8m) Dock Connecting to PC System Requirements ● PC’s system requirements: OS: Windows 98se, 2 000, XP CPU: Pentium IV 1.5G, Celeron, AMD Athlon or above Memory: 128MB Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 5: Driver Installation Procedure
Driver Installation Procedure Power on PC and place installation CD into CD-ROM driver, do not connect ■ USB Cable from Dino-Lite Handheld Digital Microscope to PC before driver installation. Select driver installation, and follow the instructions to complete installation. ■...
Page 6 Click “Next” to continue, as shown. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 7 When the “Software Installation” warning message appears, click “Continue Anyway”. Click “Finish” to complete the installation. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 8 6. Plug USB Cable to Dino-Lite Handheld Digital Microscope to connect with PC, a “Found New Hardware Wizard” will then appear. Click “Next” to continue. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 9 Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 10: Windows 2000
Place the installation CD into CD-ROM driver, the installation program should be started automatically. Otherwise, please execute the AUTORUN.EXE directly from the CD. Select “Driver Installation” from Dino-Lite Handheld digital Microscope Installation menu screen as shown. Click “Next” to continue, as shown.
Page 11 Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 12 4. When the “Digital Signature Not Found” warning message appears, click “Yes” to continue the installation. 5. Click “Finish” to complete the installation. 6. Plug USB Cable to Dino-Lite Handheld Digital Microscope to connect with PC Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com...
Page 13: Windows 98Se
Place the installation CD into CD-ROM driver, the installation program should be started automatically. Otherwise, please execute the AUTORUN.EXE directly from the CD. Select “Driver Installation” from Dino-Lite Handheld digital Microscope Installation menu screen as shown. Click “Next” to continue, as shown.
Page 14 Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 15 4. Click “Finish” to complete the installation. 5. Plug USB Cable to Dino-Lite Handheld Digital Microscope to connect with PC Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 16 Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 17 6. When the following message appears, please insert the Windows 98 Second Edition CD-ROM. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 18 Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 19: Connecting Procedure
Connecting Procedure The following procedure will show you how to properly connect Dino-Lite Handheld Digital Microscope with your PC. Connect USB Cable on Microscope Device to PC USB port. Operate Dino-Lite Handheld Digital Microscope The following procedure will show you how to operate Dino Digital Microscope.
Page 20: Dinocapture Application Software
Microscope has been connected to PC via USB. Click DinoCapture, the DinoCapture main screen will be shown as below. The right hand side display the real-time image under the microscope. If Dino-Lite Handheld Digital Microscope has not been found while opening the DinoCapture, the message will be prompted as below.
Page 21: Picture / Video Folder
But it is still suggested to save the picture or video and keep the folder clean for file security and program’s performance concern. Thumbnail Notation Grey shadow -- The picture or video has not yet been saved. Orange shadow -- The picture or video has been saved. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 22: Take Picture
Tool Bar or by selecting “Picture” under Capture Menu. Take Video The Video can be taken either by clicking the icon on Tool Bar or by selecting “Video” under Capture Menu. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 23 The file can be saved as “jpg” or “bmp”, by either clicking in the Tool Bar or by selecting “Save as” under the File Menu . The selected file in the folder will then be saved as prompted below. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 24 Click “Mail” : The file name is same as system’s. The selected file can be mailed by clicking in the Tool Bar, or by selecting “Mail” under the File Menu. Share Click “share” in the File Menu. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 25: Menu Function List
Delete All – To delete all the files in selected folder, picture or video. On display thumbnail picture, click mouse right key, the functions showed are same as file’s. 2. Setting Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 26 The user can select the quality of audio file to be recorded. Video Setting The user can set the parameter of video. Note: The resolution setting is not useful. Video Compression Setting Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 27 The picture, video and frame functions in Capture have the same functions as the buttons of in the Tool Bar. 4. Help User can use “Program Updates” in Help to download the most updated Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 28: Open The Picture
Open The Picture The opened picture can be displayed in full screen by clicking To return from full screen mode, just click the mouse left key. Function Description Save as Copy Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 29: Open The Video Or Time Lapsed Video
Previous Picture Next Picture Share the Picture by sending the file to DinoShare under the Shared Document Enlarge Shrinkage Open The Video Or Time Lapsed Video Function Description Play Stop Pause Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com www.agelectronica.com...
Page 30: Q&A
Please check all the connection of all necessary cable and adapter. Q2. Why cannot work, when connect to PC? a. Check driver installation is completed. b. The USB cable is connected to Dino-Lite Handheld Microscope and PC USB port. Q3. How to install driver? a.
Page 31: Copyright
Information in the user manual is written for the current specification of the product. The manufacturer of Dino Digital Microscope continues to provide additional functions and apply new technology to it. All specifications may be changed without notice to individual users. Dino-Lite Handheld Digital Microscope User’s Manual www.agelectronica.com www.agelectronica.com www.agelectronica.com...
