FRS FM TRANSCEIVER

SPECIFICATIONS
• Number of channels
• Mode
• Frequency stability
• Frequency resolution
• Battery requirements
• External power supply
• Current drain
(at 4.5V DC)
• Operating temperature range
• Number of CTCSS frequencies
• Weight
• Output power
• External microphone connector
• Sensitivity (at 12dB SINAD)
• Audio output power
• External SP connector
• Battery life (Tx:Rx:Standby=1:1:8)
• Communication range*
* Communication range may differ depending on weather conditions, etc.
All stated specifications are subject to change without notice or obligation.
OPTIONS
BP-202 Ni-Cd BATTERY
CELL ASSEMBLY
Install into the battery cell space
in the transceiver.
3.6V/700mAh
SPEAKER-MICROPHONES and EARPHONE-MICROPHONE
HM-46 HM-75A
HM-46 : Compact and lightweight. Equipped with an earphone jack.
HM-75A : Allows you to remotely select operating channels, etc.
HM-131 : Durable body. Equipped with an earphone jack and revolving clip.
HM-128 : Light weight and compact earphone-microphone with PTT switch
that clips to your lapel.
1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan
Icom America Inc.
< >
Corporate Headquarters
2380 116th Avenue N.E., Bellevue, WA 98004, U.S.A.
Phone : (425) 454-8155 Fax : (425) 454-1509
URL : http://www.icomamerica.com
< >
Customer Service Phone : ( 425 ) 454-7619
Icom Canada
Glenwood Centre #150-6165 Highway 17,
Delta, B.C., V4K 5B8, Canada
Phone : ( 604 ) 952-4266 Fax : ( 604 ) 952-0090
URL : http://www.icomcanada.com
Icom (Australia) Pty. Ltd.
A.B.N. 88 006 092 575
290-294 Albert Street, Brunswick, Victoria, 3056, Australia
Phone : 03 9387 0666 Fax : 03 9387 0022
URL : http://www.icom.net.au
Icom New Zealand
146A Harris Road, East Tamaki, Auckland, New Zealand
Phone : 09 274 4062 Fax : 09 274 4708
URL : http://www.icom.co.nz
: 14
(simplex; 462.5625–467.7125MHz)
: FM (F3E)
: ±1.7kHz, ±4.0ppm
: 12.5kHz
(channel spacing 25kHz)
: 3 × AA(R6) alkaline cells ;
or optional BP-202
: 6.0V DC
±5% (with BC-149A or CP-18A)
: Less than 500mA
: –10˚C to +50˚C; +14˚F to +122˚F
: 38
(67.0–250.3Hz)
: 200g; 7oz (includes 3 alkaline cells)
: Less than 500mW ERP
: 3-conductor 2.5 (d) mm/2.2kΩ
: 0.158µV typical
: More than 100mW
at 10% distortion with an 8Ω load
: 3-conductor 3.5 (d) mm/8Ω
:
Battery type Battery life
3 alkaline cells approx. 28 hrs.
Optional BP-202 approx. 10 hrs.
: 2 miles (approx.; Wide, open space)
BC-149A WALL CHARGER CP-18A CIGARETTE
6V DC, 1A output AC adapter. 6V DC, 2A output from 12V cig-
Charges the BP-202, while op- arette lighter socket with internal
erating the radio. DC-DC converter.
HM-131 HM-128
Phone: 06 6793 5302
Icom (Europe) GmbH
Communication Equipment
Himmelgeister Str. 100, D-40225 Düsseldorf, Germany
Phone : 0211 346047 Fax : 0211 333639
URL : http://www.icomeurope.com
Icom Spain S.L.
Crta. de Gracia a Manresa Km. 14,750
08190 Sant Cugat del Valles Barcelona, SPAIN
Phone : ( 93 ) 590 26 70 Fax : ( 93 ) 589 04 46
URL : http://www.icomspain.com
Icom (UK) Ltd.
Unit 9, Sea St., Herne Bay, Kent, CT6 8LD, U.K.
Phone : 01227 741741 Fax : 01227 741742
URL : http://www.icomuk.co.uk
Icom France S.a
Zac de la Plaine, 1, Rue Brindejonc des Moulinais
BP 5804, 31505 Toulouse Cedex, France
Phone : (33) 5 61 36 03 03 Fax : (33) 5 61 36 03 00
URL : http://www.icom-france.com
DIMENSIONS
BC-119N DESKTOP CHARGER + BC-145A AC ADAPTER
+ AD-105 CHARGER ADAPTER
LIGHTER CABLE
BC-145A
Rapidly charges installed Ni-Cd battery cell assembly, BP-202. The
charger adapter and the AC adapter supplied with the BC-119N de-
pending on version. Charging time: 75 to 85 min.
HEADSETS
VS-1
HS-85
HS-85 : For hands-free operation. Includes VOX, PTT and "one-touch" PTT with a time-out timer.
VS-1 : PTT/VOX unit. Required when using the HS-94, HS-95 and HS-97 with the transceiver.
HS-94 : Earhook headset with flexible boom microphone.
HS-95 : Behind-the-head headset with flexible boom microphone.
HS-97 : Throat microphone fits around your neck comfortably.
Fax: 06 6793 0013 URL: http://www.icom.co.jp/world/index.html
Asia Icom Inc.
6F No. 68, Sec. 1 Cheng-Teh Road,
Taipei, Taiwan, R.O.C.
Phone : (02) 2559 1899 Fax : (02) 2559 1874
URL : http://www.asia-icom.com
Beijing Icom Ltd.
1305, Wanshang Plaza, Shijingshan Road,
Beijing, China
Phone : (010) 6866 6337 Fax : (010) 6866 3553
URL : http://www.bjicom.com
Certificate Number Q14190
Icom Inc. (Japan), is an ISO9001
certification acquired company.
AD-105
BC-119N
HS-95
HS-94
Count on us!
Your local distributor/dealer:
Printed in Japan
03WS0060 © 2003 Icom Inc.
HS-97
