INSTALLATION
& OPERATION
MANUAL
SuperVisor
®
SuperVisor
TriCore
Technology
® with
®
U.S. Patent Nos. 7,153,015 and 7,300,175, Other Patents Pending
Interior Lighting System
Dodge Charger
CONTENTS:
Introduction ...........................................................................2
Unpacking & Pre-Installation ................................................2
Installation & Mounting ......................................................3-4
Warranty ...............................................................................8
For future reference record your product's serial no. here __________________________________________
IMPORTANT:
Read all instructions and warnings before installing and using.
This manual must be delivered to the end user of this equipment.
INSTALLER:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperVisor and is the answer not in the manual?

Questions and answers

Related Manuals for Code 3 SuperVisor

Summary of Contents for Code 3 SuperVisor

  • Page 1 INSTALLATION & OPERATION MANUAL SuperVisor ® SuperVisor TriCore Technology ® with ® U.S. Patent Nos. 7,153,015 and 7,300,175, Other Patents Pending Interior Lighting System Dodge Charger CONTENTS: Introduction ................2 Unpacking & Pre-Installation ..........2 Installation & Mounting ............3-4 Wiring Instructions - Flash Pattern Selection ....4-6 Troubleshooting - Exploded View - Parts List .......7...

  • Page 2: Product Features

    Unpacking & Pre-installation Carefully remove the SuperVisor and place it on a flat surface, taking care not to scratch the lenses or damage the cable coming out of the top. Examine the unit for transit damage, broken lamps, etc. Report any damage to the carrier and keep the shipping carton.
  • Page 3 SuperVisor®. Pull all of the slack out of the cable as a helper positions the SuperVisor as close to the final position as possible. Once all of the slack is out of the cable and starting at the center of the SuperVisor at the rear view mir- ror attachment point, tuck the cable up behind and above the headliner.

  • Page 4: Wiring Instructions

    ® Once the two outer brackets are attached and the cable is routed, the SuperVisor is ready to be installed. With the SuperVisor held in po- sition behind the outer mounting brackets (see Figure 6) line up the mounting holes in the outer mounting brackets with the threaded holes in the SuperVisor and thread the supplied 1/4"-20 bolts and internal tooth lock washers into the SuperVisor's Outer Panel (see Figure 7).
  • Page 5 Larger wires and tight connections will provide longer service life for components. For high current wires it is highly recommended that terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation displacement connectors (e.g. 3M Scotchlock type connectors).
  • Page 6 Steady Burn Option The SuperVisor® can operate Light Head #2 (second Light Head from the driver side) in steady burn mode. To change the #2 Light Head from flashing to steady burn, remove the mounting screws that attach the SuperVisor's Cover to the Outer Panel to gain access to the printed circuit board inside (see the exploded view on page 7).

  • Page 7: Troubleshooting

    Outer Mtg. Brkt. Dodge Charger Pass Side T14747 Cover T15088 Inner Mtg. Brkt. Dodge Charger T14748 Blank Brkt. Crown Vic T15056 Outer Mtg. Brkt. Dodge Charger Drivr Side T14746 Outer Panel T15087 TriCore® Module Contact Code 3, Inc for P/N...
  • Page 8 *Code 3, Inc. reserves the right to repair or replace at its discretion. Code 3, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products returned to sender after the service has been rendered.
