- Page 1 YSS2 ACTIVE STUDIO S U B W O O F E R OWNER'S MANUAL MANUEL DE L'UTILISATEUR MODEL TYPE: YS1052 Manual-Owners-yss2-00-1v1.pdf...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO A INSTRUCTIONS RELATIVES AU RISQUE RISK OF FIRE, ELECTRIC SHOCK, DE FEU, CHOC ÉLECTRIQUE, OU OR INJURY TO PERSONS BLESSURES AUX PERSONNES CAUTION: AVIS: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE, N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE) NOT REMOVE COVER (OR BACK). -
Page 3: Getting Connected
YSS 2 YSS2 Active Studio Subwoofer Connection There are a couple of ways to connect the YSS2 to your audio system. One method uses speaker cables, the other method uses shielded cables with RCA type connectors. Looking at the rear panel of the YSS2, you will see two sets of spring terminals (one labeled Input / From Amplifier, the other labeled Output / To Speaker) and two sets of RCA jacks labeled Input and... - Page 4 YSS 2 PHASE SUBWOOFER CROSSOVER INPUT OUTPUT ° ° (Norm) LEVEL FREQUENCY POWER AUTO YSS2 ACTIVE STUDIO S U B W O O F E R OUTPUT INPUT TO SPEAKER FROM AMPLIFIER NOTE: Phase can be used to describe the relationship of superimposed audio waves. By super- posing audio waves using different phase shifts the audio waves can reinforce each other (0°...
- Page 5 YSS 2 YSM2p YSM2p YSM1i YSM1i RCA Input RCA Input Series 2 Series 2 Amplifier Input PHASE PHASE SUBWOOFER CROSSOVER INPUT OUTPUT SUBWOOFER CROSSOVER INPUT OUTPUT ° (Norm) ° ° (Norm) ° LEVEL FREQUENCY LEVEL FREQUENCY POWER AUTO POWER AUTO YSS2 YSS2 YSS2...
- Page 6 YSS 2 Subwoofer Actif YSS2 pour Studio Connection Il y a plus qu’une façon de raccorder votre YSS2 à votre système audio. Une méthode utilise les câbles de haut-parleurs, l’autre méthode utilise des câbles blindés avec connecteurs de type RCA. Vous retrou- verez sur le panneau arrière de la YSS2 deux en- sembles de terminaux à...
- Page 7 YSS 2 Éteignez l’appareil lorsqu’il n’est pas utilisé. Si l’appareil n’est pas utilisé pour une longue période de temps, débranchez la du réceptacle CA. Opérez avec source d’alimentation telle que spécifiée sur l’appareil ou dans le manuel d’opération. 2. Sélecteur de Phase Ce sélecteur alterne la phase du subwoofer en relation avec les haut-parleurs principaux.
- Page 8 YSS 2 YSM2P YSM2P YSM1i YSM1i Entrée Entrée Series 2 Series 2 Amplificateur Entrée RCA PHASE PHASE SUBWOOFER CROSSOVER INPUT OUTPUT SUBWOOFER CROSSOVER INPUT OUTPUT ° (Norm) ° ° (Norm) ° LEVEL FREQUENCY LEVEL FREQUENCY POWER AUTO POWER AUTO YSS2 YSS2 YSS2 YSS2...
- Page 9 YSS 2 YSS2 A CTIVE ST UDIO S U B W O O F E R Specifications Compact Active Studio Subwoofer Type 150 Watts Power 10-inch ceramic magnet driver Speaker 10Hz to 300Hz Frequency Response 105dB +/- 3 dB 2 x RCA (L&R) / 2 x Speaker push terminal (L&R) Inputs 2 x RCA (L&R) / 2 x Speaker push terminal (L&R) Thru-Puts...
- Page 10 YSS 2...
- Page 11 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 12 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689 Printed in China...
