- Page 1 P OWER ED STU DIO SU BW OO FER OW N ER ' S M ANUAL M ANUEL DE L 'UTILISATEUR MODEL TYPE: YS2009...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Read these instructions – All the safety and operating instructions should be read before this product is operated. Keep these instructions – The safety and operating instructions should be retained for future reference. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. Follow all instructions –...
- Page 4 Use the input jacks to feed the YSS10 with a mono or stereo signal from your source. It is preferred that your source go directly to the YSS10 and then be looped up to your full-range loudspeakers via the High Pass Output jacks.
- Page 5 The YSS10 has circuitry to prevent clipping, over-current and over-excursion. At high levels, the internal limiter will limit the gain of the YSS10; if the user attempts to set the subwoofer level control at a high level, the resulting setting will be incorrect. The level control should be set while operating at low levels (under 10 watts).
- Page 6 P OWER ED STUDI O S U BW O OF E R Specifications Model YSS10 System Type Subwoofer Active or Passive Active Program Power (Watts) 250 Watts Max SPL (dB) 120 dB (continuous) Frequency Response (Hz +/- 3db) 50-150Hz Crossover Frequency (Hz) 80Hz...
- Page 7 Le réglage à 0 dB de la commande de niveau du YSS10 est le bon point de départ lors de l’ajustement initial d’un système de sonorisation. Les ajustements peuvent ensuite être effectués pour obtenir le meilleur son.
- Page 8 Lors de l’opération à des niveaux élevés, le limi- teur interne limitera le gain du YSS10 donc si l’utilisateur tente de régler la commande de niveau du subwoofer à un niveau élevé, le réglage qui en résultera sera incorrect.
- Page 9 PO WER ED ST U DI O S U BW O O FE R Spécifications Modèle YSS10 Type de Système Subwoofer Actif ou Passif Actif Puissance Nominale (Watts) 250 Watts Niveau de Pression Sonore Max (dB) 120 dB (continue) Réponse en Fréquence (Hz +/- 3db) 50-150Hz Fréquence de Filtre Séparateur (Hz): 80Hz...
- Page 11 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 12 Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689 Printed in China Manual-Owners-yss10-00-1v1 • March 13, 2012...
