Central Pneumatic 69473 Part List Manual

Specifications, Parts List & Diagram

Save This Manual

inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and
the receipt in a safe and dry place for future reference.
3" high speed air cutter

Specifications

Maximum Wheel Size 3" Dia.
Arbor Size 3/8"
Maximum Pressure 90 PSI
Air Inlet Fitting Size 1/4" - 18 NPT Female
Maximum Speed* 18,000 RPM
Air Consumption 5 CFM @ 90 PSI
Accessories Hex Key, Wrench
* Maximum speed at stated maximum air pressure.
Excess air pressure is hazardous and may cause
the tool to exceed stated maximum speed.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright 2012 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly, operating,
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
®
. All rights reserved.
Read the separate High Speed Air Cutter Safety Warnings,
Installation and Operation Instructions before using this
product. Failure to do so can result in serious injury.
SAVE tHIS SpECIFICAtIOn SHEEt And tHE HIgH SpEEd
AIR CuttER SAFEty WARnIngS, InStAllAtIOn And
OpERAtIOn InStRuCtIOnS FOR FutuRE REFEREnCE.
ITEM 69473
