Episode ESS-6-BLK Owner's Manual

INSTALLATION TIP
The volume control on your receiver or amplifier serves as the "master" volume for all of the connected
speakers. The volume level of the speakers will likely vary from area to area. This can happen even when
identical speakers are used and can be due to room size differences, placement differences, even changes
in decoration, such as hard floors versus plush carpeting. The best way to correct this and balance the volume
between these areas is to install an Episode Volume Control (sold separately) on each pair of speakers in your
system. This allows you to adjust the volume of each pair of speakers independently. If all of the speakers in
your system are equipped with Episode volume controls, you can leave the "master" volume on your receiver
or amplifier set at one position and use the Episode volume controls for each pair.
Receiver
TUNER 94.9
Amplifier Zone 6 Zone 5
L+ L- R- R+ L+ L- R- R+ L+ L- R- R+
L+ L- R- R+ L+ L- R- R+ L+ L- R- R+
SPECIFICATIONS
Overall Dimensions 11-1/2" wide x 2" high 6-3/4" deep
Audio Power Handling 100 Watts/channel continuous. 200 Watts music power
Connection Type Removable connectors for use with 14-22 gauge stranded copper wire
(16 gauge recommended)
Frequency Response +0 dB, -0 dB (flat) from 20 Hz to 20 kHz
Weight 2-1/4 lbs
AMP Protection The AMP protection switch requires an amplifier that is 4 ohm capable.
Lifetime Limited Warranty
All Episode Speakers Selectors have a Lifetime Limited Warranty. This warranty includes parts and labor
Lifetime
repairs on all components found to be defective in material or workmanship under normal conditions of
use. This warranty shall not apply to products which have been abused, modified or disassembled.
Products to be repaired under this warranty must be returned to the SnapAV or a designated service
center with prior notification and an assigned return authorization number (RA).
Zone 4 Zone 3 Zone 2 Zone 1
L+ L- R- R+ L+ L- R- R+ L+ L- R- R+ L+ L- R- R+
L+ L- R- R+ L+ L- R- R+ L+ L- R- R+ L+ L- R- R+
100312
OWNER'S MANUAL
ESS-6-BLK
Six Speaker Selector
>>
with Amplifier Protection
