Page 1: Service Manual
Service manual Room air conditioner Split Wall-Mounted Type GC/GU-S05CR GC/GU-S07CR GC/GU-S09CR GC/GU-S12CR GC/GU-S18CR Climatic Control Corporation Wall-Mounted Split Type... -
Page 2: Table Of Contents
Content Precaution ........................1 Safety Precaution ........................1 Warning ............................. 1 Function ........................3 Dimension ........................5 Indoor unit..........................5 Outdoor unit ..........................6 Specification ........................ 7 Refrigerant cycle diagram................... 9 Operation limits ......................10 Cooling operation........................10 Heating operation ........................10 Schematic diagram and Wiring diagram .............. - Page 3 10.10 Auto mode ..........................30 10.11 Force cooling function......................31 10.12 Sleep mode..........................31 10.13 Auto restart function......................... 32 10.14 Anion (optional)........................32 Model and Parameters ....................33 Troubleshooting......................34 12.1 Display board........................... 34 12.2 Troubleshooting ........................35 12.3 Diagnostic chart ........................36 12.4 Resetting phenomenon often occurs during operation.............
-
Page 4: Precaution
1. Precaution Safety Precaution To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instruction will cause harm or damage. Before service unit, be sure to read this service manual at first. Warning Installation Do not use a defective or underrated circuit breaker. - Page 5 There is risk of physical injury, electric shock, or product failure. Operational When the product is soaked (flooded or submerged), Do not expose the skin directly to cool air for long contact an Authorized service center. periods of time. (Do not sit in the draft). There is risk of fire or electric shock.
-
Page 6: Function
2. Function Indoor unit Operation ON/OFF by remote controller Sensing by room temperature Room temperature sensor. Pipe temperature sensor. Room temperature control Maintain the room temperature in accordance with the setting temperature. Starting temperature control Indoor fan is delayed for 5 sec at the starting. Time Delay Safety control Restarting is for approx. - Page 7 Outdoor unit Power relay control The unit has 3 mins delay between continuously ON/OFF operations. Low ambient kit The unit can operate in cooling mode at low ambient temperature conditions. Low noise air flow system Bird tail propeller fan makes the outdoor unit run more quietly. Hydrophilic aluminum fin The hydrophilic fin can improve the heating efficiency at operation mode.
-
Page 8: Dimension
3. Dimension 3.1 Indoor unit Dimension Mode www.generalclimate.com Wall-Mounted Split Type... -
Page 9: Outdoor Unit
3.2 Outdoor unit Dimension Mode www.generalclimate.com Wall-Mounted Split Type... -
Page 10: Specification
4. Specification Model GC/GU-S05CR GC/GU-S07HR 1, 220-240V~,50Hz 1, 220-240V~,50Hz Power supply Ph-V-Hz 5000 7000 Capacity Btu/h Input Cooling Rated current Btu/w.h Capacity Btu/h ----- 7600 Input ----- Heating Rated current ----- ----- Max. current Starting current KH104VFHC Model 2P14C235ANA Rotary Type Rotary SHANGHAI SENLIN... - Page 11 Model GC/GU-S09HR GC/GU-S12HR GC/GU-S18HR Ph-V-Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz Power supply Capacity Btu/h 9000 12000 18000 Input 1230 1920 Cooling Rated current Btu/w.h Capacity Btu/h 10000 13000 20000 Input 1290 1980 Heating Rated current 10,2 10,1 Max. current Starting current Model 2P18S225ANK...
-
Page 12: Refrigerant Cycle Diagram
5. Refrigerant cycle diagram Cooling only Heat pump mode www.generalclimate.com Wall-Mounted Split Type... -
Page 13: Operation Limits
6. Operation limits 6.1 Cooling operation Outdoor unit air temp. Indoor air temp. Note: The chart is the result from the continuous operation under constant air temperature conditions. However, excludes the initial pull-down stage. 6.2 Heating operation Indoor air temp. Outdoor unit air temp. -
Page 14: Schematic Diagram And Wiring Diagram
7. Schematic diagram and Wiring diagram Schematic diagram www.generalclimate.com Wall-Mounted Split Type... -
Page 15: Wiring Diagram
Wiring diagram 7.2.1 Cooling mode GC/GU-S05CR INDOOR UNIT YЈ ¦ G YЈ ¦ G YЈ ¦ G COMPRESSOR CAPACITOR CAPACITOR www.generalclimate.com Wall-Mounted Split Type... - Page 16 7.2.2 GC/GU-S07HR, GC/GU-S09HR, GC/GU-S12HR www.generalclimate.com Wall-Mounted Split Type...
- Page 17 MSG-18HR www.generalclimate.com Wall-Mounted Split Type...
-
Page 18: Installation Details
8. Installation details Wrench torque sheet for installation Outside diameter Torque inch Kg.m φ6.35 φ9.52 φ12.7 φ15.88 φ19.05 Connecting the cables The power cord of connect should be selected according to the following specifications sheet. Grade Unit Pipe length and the elevation Standard Max. -
Page 19: Air Purging Of The Piping And Indoor Unit
Air purging of the piping and indoor unit Required tools: Hexagonal wrench; adjustable wrench; torque wrenches, wrench to hold the joints and gas leak detector. Note: The air in the indoor unit and in the piping must be purged. If air remains in the refrigeration piping, it will affect the compressor, reduce the cooling capacity, and could lead to a malfunction of unit. -
Page 20: Pumping Down (Re-Installation)
Pumping down (Re-installation) Procedure 1. Confirm that both the 2-way and 3-way valves are set to the opened position. Remove the valve stem caps and confirm that the valve stems are in the opened position. Be sure to use a hexagonal wrench to operate the valve stems. 2. -
Page 21: Re-Air Purging (Re-Installation)
Re-air purging (Re-installation) Procedure: 1. Confirm that both the 2-way and 3-way valves are set to the closed position. 2. Connect the charge set and a charging cylinder to the service port of the 3-way valve. Leave the valve on the charging cylinder closed. 3. -
Page 22: Balance Refrigerant Of The 2-Way, 3-Way Valves
Balance refrigerant of the 2-way, 3-way valves Procedure: 1. Confirm that both the 2-way and 3-way valves are set to the open position. 2. Connect the charge set to the 3-way valve’s service port. Leave the valve on the charge set closed. Connect the charge hose with the push pin to the service port. -
Page 23: Evacuation
Evacuation Procedure: 1. Connect the vacuum pump to the charge set’s centre hose. 2. Evacuation for approximately one hour. Confirm that the gauge needle has moved toward -0.1 Mpa (-76 cmHg) [vacuum of 4 mmHg or less]. 3. Close the valve (Low side) on the charge set, turn off the vacuum pump, and confirm that the gauge needle does not move (approximately 5 minutes after turning off the vacuum pump). -
Page 24: Gas Charging
Gas charging Procedure: 1. Connect the charge hose to the charging cylinder. Connect the charge hose which you disconnected from the vacuum pump to the valve at the bottom of the cylinder. 2. Purge the air from the charge hose. Open the valve at the bottom of the cylinder and press the check valve on the charge set to purge the air (be careful of the liquid refrigerant). -
Page 25: Capacity Table
9. Capacity table GC/GU-S05CR OUTDOOR TEMPERATURE DRY SUMMER Cooling mode Indoor 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC Conditions 21ºC D Total capacity kW 1.41 1.33 1.23 1.13 1.06 0.98 15ºC W Sensitive capacity kW 1.03 0.99 0.93 0.86 0.81 0.76 Input kW. -
Page 26: Gc/Gu-S09Hr
GC/GU-S09HR OUTDOOR TEMPERATURE DRY SUMMER Cooling mode Indoor 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC Conditions 21ºC D Total capacity kW 2.50 2.35 2.17 2.00 1.87 1.73 15ºC W Sensitive capacity kW 1.82 1.75 1.64 1.52 1.43 1.34 Input kW. 0.86 0.90 0.94 1.02... -
Page 27: Gc/Gu-S18Hr
OUTDOOR CONDITIONS WINTER Indoor 12ºC D 7ºC D 4ºC D 0ºC D -4ºC D -7ºC D Conditions 11ºC W 6ºC W 3ºC W -1ºC W -6ºC W -8ºC W 4.50 3.94 3.61 3.17 2.73 2.40 Capacity kW 15ºC Input kW. 1.38 1.26 1.17... -
Page 28: Electronic Function
10. Electronic function (Just for the 5K, 7K, 9K, 12K, 16K, 18K cooling and heating mode) 10.1 Electronic control working environment Input voltage: 175~253V Input power frequency:50HZ Ambient temperature: -7°C+43°C Indoor fan normal working amp is less than 1A Outdoor fan normal working amp is less than 1.5A Four-way valve normal working amp is less than 1A Swing motor: DC12V Compressor: single-phase power supply. -
Page 29: Protection
Anti frozen at cooling mode 10.4 Protection 10.4.1 3 minutes delay at restart for compressor. 10.4.2 Sensor protection at open circuit and breaking disconnection 10.4.3 Fan Speed is out of control. When Indoor Fan Speed is too high(higher than High Fan+300RPM)or too low(lower than 400RPM), the unit stops and LED displays failure information and can’t returns to normal operation automatically. -
Page 30: Dehumidifying Mode
Auto fan at cooling mode: Anti-freezing control to indoor evaporator at cooling mode ( T: evaporator temp. ) Compressor and outdoor fan on EVAP. temp. down EVAP. temp. up Compressor and outdoor fan off (after 5 mins) 10.7 Dehumidifying mode 10.7.1 The 4-way valve is off in dehumidifying mode 10.7.2 Compressor and Indoor Fan actions in dehumidifying mode TA-TS... -
Page 31: Heating Mode
Indoor Block Compressor and Outdoor Fan ON 6minutes BREEZE OFF 4minutes ON 5minutes BREEZE OFF 5minutes ON 4minutes BREEZE OFF 6minutes Repeat on and off cycle. 10.7.3 Low room temperature protection: When room temperature decreases to below 10 , compressor and outdoor fan will stop(indoor fan is Breeze). -
Page 32: Defrosting Mode(Available For Heating Mode)
10.8.5 Auto wind at heating mode (T=indoor temp.) 10.8.6 Indoor evaporator high-temperature protection at heating mode (T=indoor exchanger temp.) 10.8.7 The louver opens to Standard Angle ANGLHEAT when power is on for the first time 10.9 Defrosting mode(available for heating mode) Defrosting condition: Defrosting starts when either of the following &... -
Page 33: Auto Mode
Calculate from the end of latest defrost, evaporator high temp. Protection only closes outdoor fan with the compressor still running. Add up to 90 minutes. Defrosting time At condition , If item B is satisfied before item A, it would be regarded as severe frosting and the defrosting time is 10 minutes. -
Page 34: Force Cooling Function
10.10.2 The indoor fan blows automatically in corresponding selected mode 10.10.3 The motion of indoor fan’s blade should accord with the selected operation mode 10.10.4 One mode should be carried out for at least 15 minutes once selected. If the compressor cannot start for 15 minutes, reselect the operation mode according to the room temp. -
Page 35: Auto Restart Function
10.12.4 Auto: After an hour running under economic mode, the set temp will rise 1 ,if it is under cooling mode; the set temp will decrease 1 ,if it is under heating mode; the set temp will be changeless, if it is under fan-only mode;... -
Page 36: Model And Parameters
11. Model and Parameters Model GC/GU-S05CR GC/GU-S07HR GC/GU-S09HR GC/GU-S12HR GC/GU-S18HR I3SEC [A] I5MIN [A] IFAN [A] IRESTORE [A] 4.5A IDEFROST [A] TE1 ['C] TE2 ['C] TE3 ['C] TE4 ['C] TE5 ['C] TE6 ['C] TE7 ['C] TE8 ['C] TE9 ['C] ANGLCOOL ['] 200°... -
Page 37: Troubleshooting
12. Troubleshooting 12.1 Display board Operation The indicator flashes once every second after power is on and illuminates when the air conditioner is in operation. Timer indicator: The indicator illuminates then TIMER is set ON. PRE-DEF. indicator (For cooling & heating mode only) The air conditioner starts defrosting automatically if outdoor unit frosts in heating operating. -
Page 38: Troubleshooting
12.2 Troubleshooting For cooling mode: Operation Timer Failure phenomenon lamp lamp Indoor fan speed has been out of control for over 1 minute Indoor room temp. or evaporator sensor is open circuit or short circuit Over current protection of the compressor occurs 4 times EEROM error No over-zero signal r Extinguish... -
Page 39: Diagnostic Chart
12.3 Diagnostic chart After energizing, no indicator is lighted and the air conditioner can’t be operated. www.generalclimate.com Wall-Mounted Split Type... -
Page 40: Resetting Phenomenon Often Occurs During Operation
12.4 Resetting phenomenon often occurs during operation. (That is automatically entering to the status when power is on.) The reason is that the instantaneous voltage of main chip is less than 4.5V. Check according to the following procedure: 12.5 Operation lamp flashes and Timer lamp off. 12.6 Operation lamp flashes and Timer lamp on. -
Page 41: Operation Lamp Off And Timer Lamp Flashes
12.7 Operation lamp off and Timer lamp flashes 12.8 Operation lamp on and Timer lamp flashes EEROM error, indoor PCB is defective. 12.9 Operation lamp flashes, Timer lamp flashes . This is alarm signal when the main chip can’t detect over-zero signal. When such failure occurs, the main control board must have fault. -
Page 42: Characteristic Of Temperature Sensor
13. Characteristic of temperature sensor Temp. Resistance KΩ Temp. Resistance KΩ Temp. Resistance KΩ 62.2756 14.6181 4.3874 58.7079 13.918 4.2126 56.3694 13.2631 4.0459 52.2438 12.6431 3.8867 49.3161 12.0561 3.7348 46.5725 11.5 3.5896 10.9731 3.451 41.5878 10.4736 3.3185 39.8239 3.1918 37.1988 9.5507 3.0707 35.2024...
