Bagless upright
Vax model number:
VZL-6013
VZL-6013A
VZL-6013AL
VZL-6013AA
VZL-6014
VZL-6014A
VZL-6014AA
WARNING: This cleaner has a constantly
!
rotating brush bar which, when left in
contact with lino, parquet and other hard flooring
could potentially cause some damage to the floor
surface.
NOTE: Vax recommends that you raise the height
of the brush bar when using this cleaner on lino and
hard flooring. Vax cannot be held responsible for
damage to these surfaces if the customer fails to
take notice of this recommendation.
www.vax.co.uk
0870 6061248
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
Vax careline
Advertisement
Table of Contents
Related Manuals for Vax VZL-6013
Summary of Contents for Vax VZL-6013
- Page 1 NOTE: Vax recommends that you raise the height of the brush bar when using this cleaner on lino and hard flooring. Vax cannot be held responsible for damage to these surfaces if the customer fails to take notice of this recommendation.
- Page 2 21 Handle release pedal when using this cleaner on lino 9 Stair cleaning handle 22 Hard Floor Brush and hard flooring. Vax cannot be (located below edge of dirt container) (Models: VZL-6014, VZL-6014A , held responsible for damage to VZL-6014AA only)
-
Page 3: Safety Information
IMPORTANT: If the inlet, hose or extension tube is damaged cord or plug. If the supply cord or plug is blocked, switch off the vacuum cleaner and damaged, return the vacuum cleaner to a Vax remove the blockage(s) before re-starting the vacuum Authorised Service Agent or suitably qualified cleaner. -
Page 4: How To Assemble
3. How to assemble Press button at handle base and push handle all the way down (Fig.3/4). Attach Handle Grasp orange tie wrap and pull until the black plug comes out of the handle cavity (Fig.3/1). Fig.3/4 Adjusting Handle For convenience in storing or carrying your cleaner, the Fig.3/1... -
Page 5: How To Operate
Stair Cleaning NOTE: Vax recommends that you raise the height of A stair cleaning handle has been designed for ease in the brush bar when using this cleaner on lino and hard using your cleaner on stairs. - Page 6 Fig.4/5 Fig.4/6 As an alternative, you may use the hose and power hand Select Proper Tool tool for stair cleaning. Clean from bottom to top. Combination tool: use with brush for carved furniture, NOTE: When using cleaning tools, the brush bar will table tops, books, lamps, lighting fixtures, venetian blinds, continue to rotate.
- Page 7 Vax Careline 0870 606 1248 5. Dirt container & filters: removal & replacement NOTE: Familiarize yourself with these home maintenance tasks as proper use and care of your cleaner will ensure continued cleaning effectiveness. Emptying the Dirt Container Empty the dirt cup before the dirt reaches the fill line (A) (Fig.5/1).
- Page 8 Remove dirt container as described above. Twist filter assembly counterclockwise. Remove assembly from dirt container (Fig.5/6). Fig.5/8 Cleaning the Final Filter Fig.5/6 IMPORTANT: Disconnect cleaner from electrical outlet. Do not operate cleaner without dirt cup Dirt and debris can be cleaned from the filter assembly by or filters in place.
-
Page 9: Maintenance
Vax Careline 0870 606 1248 6. Maintenance To remove the hood, press handle release pedal and place handle in low position. Using a coin, turn the two slots (A) on either side of the hood as shown (Fig.6/3). Replacing the Headlight Removing lens Disconnect cleaner from electrical outlet. - Page 10 IMPORTANT: To check condition of brushes, disconnect cleaner from electrical outlet. Move edge of a card across bottom plate while turning brush bar (Fig.6/9). Fig.6/6 Grasp brush bar firmly and fit it into position by first sliding end opposite the belt into the rectangular slot (A) on side of cleaner.
- Page 11 Vax Careline 0870 606 1248 Remove brush bar including end plates (A) and discard. To replace bottom plate, insert the four tabs on edge of bottom plate into slots on front of tool. Inspect belt to ensure that it is in good condition. If belt is cracked, gouged or broken, replace it (see following Pivot bottom plate down and snap closed (Fig.6/15).
-
Page 12: Clearing Blockages
With flat sides of turbine retainers (A) pointing down, slide 7. Clearing blockages retainers into grooves (B) in tool housing and snap into place (Fig.6/18). IMPORTANT: Disconnect cleaner from electrical outlet before attempting to clear blockages. Low suction or pick up may be due to a blockage in the system. -
Page 13: Troubleshooting
Vax Careline 0870 606 1248 8. Troubleshooting WARNING: To reduce the risk of personal injury, unplug vacuum cleaner before servicing. PROBLEM: Cleaner won’t run Cause: Not properly plugged into wall outlet. Solution: Plug in firmly. Cause: No electricity in wall outlet. -
Page 14: Technical Specification
Wattage: 1300W Saturday-Sunday 9.00am to 5.00pm. Capacity: 2.5l Any queries or concerns about using the Vax, call the Vax Filters: Washable pre-motor filter assembly Careline. Calls are charged at the UK national rate. Washable HEPA post-motor filter assembly Please make a note of the serial number and model Washable anti-bacterial post-motor filter number of the carpet cleaner before calling. - Page 15 Vax Careline 0870 606 1248 This page has been left intentionally blank.
- Page 16 EEC STATEMENT OF COMPLIANCE Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the VZL-6013 Mach 3 Range and VZL-6014 Mach 4 Range upright vacuum cleaners are manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive EMC: 2004/108/EC Electromagnetic Compatibility Directive Waste electrical products should not be disposed of with household waste.
