Xerox Phaser 6200 Options Manual

Xerox Phaser 6200 Options Manual

Color laser printer trays
Hide thumbs Also See for Phaser 6200:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

See also: Troubleshooting Manual , Feature Manual
Trays
This section covers:
I
Loading paper in Trays 1-3 — see page 2.
I
Loading paper in the Multi-Purpose Tray — see page 6.
I
Using custom size paper — see page 8.
For a list of the acceptable papers, transparencies, envelopes, and labels that can be used in each tray,
refer to the Supported Papers section of the Trays and Paper Guide on the Interactive Documentation
CD-ROM.
Instructional videos for loading trays are available on the Interactive Documentation
CD-ROM or the Xerox web site at:
You can also refer to the labels inside the printer for paper loading instructions.
Note
Do not load a tray that is currently being used for printing.
You MUST set the paper type in the printer's front panel any time you add paper to the printer. If you
change paper types, take a moment to ensure that the front panel values agree with the paper you have
loaded. If you fail to do this, you can damage the printer's fuser.

Loading paper in Trays 1-3

Note
If you change the type of paper, you MUST
specify the type on the front panel of the printer.
Caution
Phaser® 6200 Transparency film is designed specifically to work with this printer's oil-less
fuser. Using non-Phaser 6200 Transparencies might result in poor image quality and might
damage the fuser. Damage caused by using non-Phaser 6200 Transparencies is not covered
under the warranty, service agreement, or Total Satisfaction Guarantee. To order
Phaser® 6200 Transparencies, visit the
DO NOT load Phaser® 6200 Transparency Film in Trays 2 or 3; use Tray 1 or the
Multi-Purpose Tray instead.
Caution
DO NOT load card stock, glossy coated paper, photo paper, envelopes, labels, business
cards, greeting cards, CD/DVD labels, and CD/DVD inserts in Trays 1-3; use the
Multi-Purpose Tray instead.
To load paper in Trays 1-3:
Copyright © 2002 Xerox Corporation. All Rights Reserved.
Phaser® 6200 Color Laser Printer
www.xerox.com/officeprinting/6200support/
Phaser® 6200 Supplies and Accessories web
OK
6200-46
site.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phaser 6200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xerox Phaser 6200

Summary of Contents for Xerox Phaser 6200

  • Page 1: Loading Paper In Trays

    Caution Phaser® 6200 Transparency film is designed specifically to work with this printer's oil-less fuser. Using non-Phaser 6200 Transparencies might result in poor image quality and might damage the fuser. Damage caused by using non-Phaser 6200 Transparencies is not covered under the warranty, service agreement, or Total Satisfaction Guarantee.
  • Page 2 Trays Pull out the tray. 6200-35 If loading paper having a different width, push the width guides outward. If loading paper having a different length, tilt the back guide forward, slide the guide, and insert the pins on the bottom of the guide into the holes in the tray corresponding to the paper size you are loading.
  • Page 3 Trays Insert a stack of paper into the tray. Place the paper under the front corner tabs and under the tabs on the back guide. For one-sided prints, place the side to be printed faceup with the top of the page at the front of the tray.
  • Page 4 Trays Insert the tray and push it completely into the printer. 6200-36 When the front panel prompts you: If you haven’t changed the type of paper, press the OK key to accept the current setting for paper type. If you have changed the type of paper, scroll to the correct paper type and press the OK key to save your selection.
  • Page 5 Caution Phaser® 6200 Transparency film is designed specifically to work with this printer's oil-less fuser. Using non-Phaser 6200 Transparencies might result in poor image quality and might damage the fuser. Damage caused by using non-Phaser 6200 Transparencies is not covered under the warranty, service agreement, or Total Satisfaction Guarantee.
  • Page 6 Trays Adjust the width guides to match the size of the paper. 6200-07 Insert the paper, transparencies, or envelopes in the Multi-Purpose Tray. Load the side to be printed facedown with the top of the page entering the printer first. Do not load paper above the fill line.

  • Page 7: Using Custom Size Paper

    Trays If you have changed the type or size of paper: On the printer’s front panel, scroll to by pressing the Down Arrow key, then press Change the OK key. Scroll to the correct paper type and press the OK key to save your selection. Scroll to the correct paper size and press the OK key to save your selection.
  • Page 8 Trays When the front panel prompts you to confirm the type and size of paper: Scroll to (by pressing the Down Arrow key) and press the OK key. Change Scroll to the correct paper type and press the OK key to save your selection. For the paper size, scroll to and press the OK key.
