RECIRCULATION
PRESSURE
SWITCH
RECIRCULATION
SPRAY
TUB INLET
RECIRCULATION
RECIRCULATION
HOSE
PRESSURE DOME
FROM PUMP
DIVERTER VALVE
Fig. 17
NOTE: The Diverter Valve is equipped with a plastic protective cover. If the diverter
valve is serviced or replaced the protective cover MUST be reinstalled.
