INSTEON 2484D Quick Start Manual

Quick-Start Guide
TM
KeypadLinc - INSTEON 8 Button Countdown Timer
Model: #2484D
A Countdown Timer that Turns Itself Plus other INSTEON Devices off Automatically
KeypadLinc INSTEON Countdown Timer is a general purpose, countdown timer with 7 or 8 timer
durations. Like other countdown timers, it will turn the connected lights / circuit off when its timer
expires. However, that's where the similarity ends. Countdown Timer can also turn other
INSTEON devices off when its timer expires. Still further, when you Link other INSTEON devices
(as a Controller) to Countdown Timer, it will automatically start its countdown timer for the amount
of time you choose.
Important: Installation should be performed only by a qualified electrician or by a homeowner who is familiar and comfortable with electrical circuitry. If there are any questions, consult an electrician. For
setup questions contact Tech Support at SmartLabs for guidance. Tools required: Phillips screwdriver, slotted screwdriver and a wire cutter/stripper. Two or more properly installed INSTEON Access
Points are strongly recommended for every home to ensure reliable communication. You will need to ID all your wires before beginning. For a wiring diagrams (including 3-way circuits), see the
KeypadLinc Dimmer Owner's Manual at http://www.smarthome.com/2486D.pdf.
1) Disconnect power at the service panel
2) Remove trim plate and existing switch/dimmer
3) Connect Countdown Timer's copper wire to ground with a wire nut (or screw as appropriate)
4) Connect Countdown Timer's white wire to neutral with a wire nut
5) Connect Countdown Timer's black wire to hot wire with a wire nut
6) Connect Countdown Timer's red wire to the switch-leg with a wire nut (control of a local load is optional)
7) Carefully screw Countdown Timer into electrical box and replace trim plate
8) Restore power at the service panel
Countdown Timer will return to its last on / off state
9) Test Countdown Timer by pressing the "2 min" button
Your lights will turn on, flash after 1 minute and turn off after 2 minutes
1) Tap the "5 min" button (this will turn your lights on for 5 minutes)
Your lights will turn on and any INSTEON devices controlled by your Countdown Timer will also turn on
5 min. LED will turn on
After 3 minutes the 2 min. LED will turn on and the 5 min. LED will turn off
After 1 minute the "1 minute warning" will turn your lights off then back on, indicating 1 minute left
After 1 more minute your lights will turn off and any INSTEON devices linked to Countdown Timer will also be turned off
2) To turn lights off at any time, tap the OFF button or the button whose LED is on
Your lights will turn off and any INSTEON devices linked to Countdown Timer will also be turned off
Creating Links to Control other INSTEON Devices from Countdown Timer
1) Press & hold any button on Countdown Timer until its LED begins blinking
2) Press & hold the SET button on the INSTEON-compatible Responder you wish to control until its LED flashes
Note: for multi-button devices, press & hold the button of choice until LED / load flashes
Note: All the devices you link in this manner will be turned on when you turn Countdown Timer on and will turn Off when the timer
expires.

Removing Links to other INSTEON Devices from Countdown Timer

1) Press & hold the corresponding button on Countdown Timer until its LED begins blinking
2) Press & hold the same button again – hold it for 15 seconds
3) Press & hold the SET button on the INSTEON-compatible Responder you wish to remove from Countdown Timer until its LED flashes
Note: for multi-button devices, press & hold the button of choice until LED / load flashes
Page 1 of 2
Rev. 121307
