KNOW YOUR PRESSURE WASHER

Read this owner's manual and safety rules before operating your high pressure washer.
Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various controls and
adjustments. Model may vary slightly in appearance from unit shown. Save this manual for future reference.
Recoil Starter
Nozzle Extension
Adjustable Nozzle
High Pressure Outlet
Adjustable Nozzle — Always attached to nozzle
extension.Adjustable nozzle allows you to adjust pressure
of spray and spray pattern.
Air Cleaner — Dry type filter element limits the amount
of dirt and dust that gets in the engine.
Automatic Cool Down System — Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto ground.This
system prevents internal pump damage.
Gas Tank — Fill tank with regular unleaded gasoline.
High Pressure Hose — Connect one end to water pump
and the other end to spray gun.
Generac Portable Products 1,700 PSI Pressure Washer
Spray Gun
Pump equipped with
Automatic Cool Down
System
Water Inlet
High Pressure Outlet — Connection for high pressure
hose.
Nozzle Extension — Attach to spray gun to use
adjustable nozzle.
Primer Bulb — Prepares a cold engine for starting.
Pump — Develops high water pressure.
Recoil Starter — Used for starting the engine manually.
Safety Goggles — Always use the enclosed goggles or
other eye protection when running your pressure washer.
Spray Gun — Controls the application of water onto
cleaning surface with trigger device. Includes safety latch.
Water Inlet — Connection for garden hose.
4
Safety Goggles
High Pressure Hose
Air Cleaner
Primer Bulb
Gas Tank
