PARTS LIST – PUMP
Item Part # Qty Description
1 98300 1
2 97962 3
3 96795 3
4 21429 6
5 97835 1
6 21783 1
7 93680 3
8 97831 3
9 B2702 1
10 98227 1
11 B2310 0
1 . . . . . . 1
2 . . . . . . 3
5 . . . . . . 1
12 . . . . . . 1
13 . . . . . . 1
14 . . . . . . 1
15 . . . . . . 1
16 . . . . . . 1
17 185287 0
18 . . . . . . 1
19 . . . . . . 1
20 . . . . . . 1
21 . . . . . . 1
22 . . . . . . 1
28 . . . . . . 1
23 187879 0
21 . . . . . . 1
24 . . . . . . 1
25 . . . . . . 1
26 . . . . . . 1
27 . . . . . . 1
29 . . . . . . 1
30 B3513 0
31 . . . . . . 6
32 . . . . . . 6
37 . . . . . . 4
Generac Portable Products 1,700 PSI Pressure Washer
SEAL, Engine Donut
SHCS, M6 - 1 x 25
SLEEVE, Grommet Spacer
BUSHING, Rubber Mount
O-RING, Housing Seal
THERMAL RELIEF, GPW-
EG
SEAL, Oil Piston 15 TC4
SPACER, Pilot
HOUSING, Piston
ADAPTER, Engine
KIT, AXIAL CAM SERV
SEAL, Engine Donut
SHCS, M6 - 1 x 25
O-RING, Housing Seal
WASHER, Brg. 36 x 65 x 6Thk
ASSY., Brg. Cage 45 x 65
WASHER, Brg. 45 x 65 x 1
CAM, Axial 5.6 VS
BALL BEARING, 35 x 72 x 17
KIT, CHEM INJECT
FITTING, Chem Inject
BALL, Chem Inject
SPRING, Chem Inject
O-RING,Venturi & Seat, Black
VENTURI, Chem Inject
O-RING,Venturi,Yellow
KIT, UNLOADER
O-RING,Venturi & Seat, Black
CAP, Unloader
O-RING, Unloader Cap
SPRING, Unloader
PISTON ASSY., Unloader
SEAT, Unloader
KIT, CHECK VALVES
O-RING, Check Valve
ASSY., Check Valve
SHCS, M6-1.0 x 35
Item Part # Qty Description
33 B5433 3
34 97837 1
35 97841 3
36 97840 3
37 40946 4
38 B4186 0
37 . . . . . . 4
39 . . . . . . 1
40 . . . . . . 1
41 B2312 0
1 . . . . . . 1
2 . . . . . . 3
7 . . . . . . 3
5 . . . . . . 1
33 . . . . . . 3
34 . . . . . . 1
37 . . . . . . 4
42 . . . . . . 3
43 . . . . . . 3
44 . . . . . . 3
45 B1933 0
1 . . . . . . 1
2 . . . . . . 3
5 . . . . . . 1
7 . . . . . . 3
21 . . . . . . 2
25 . . . . . . 1
28 . . . . . . 1
31 . . . . . . 6
33 . . . . . . 3
34 . . . . . . 1
36 . . . . . . 3
37 . . . . . . 4
Item numbers 11, 17, 23, 30, 38, 41, and 45 are service kits
and include all parts shown within the box. Items
previously described are not listed under the service kit
number. Certain items are only available as a part of a kit.
19
SEAL, Double-Lip
O-RING, Hi-Pressure
Transfer
CAP, Outlet Check Valve
O-RING, Outlet CV Cap
SHCS, M6-1.0 x 35
KIT, HEAD CASTING SFG
SHCS, M6-1.0 x 35
HEAD, Pump
PLUG, 1/8-28 W/VIRB
KIT, PISTON & SPRING
SEAL, Engine Donut
SHCS, M6 - 1 x 25
SEAL, Oil Piston 15 TC4
O-RING, Housing Seal
SEAL, Double-Lip
O-RING, High Pressure Transfer
SHCS, M6-1.0 x 35
RETAINER, Piston Spring
PISTON, Dia. 15 x 65
SPRING, Piston Return
KIT, O-RING/SEAL SERV
SEAL, Engine Donut
SHCS, M6 - 1 x 25
O-RING, Housing Seal
SEAL, Oil Piston 15 TC4
O-RING,Venturi & Seat, Black
O-RING, Unloader Cap
O-RING,Venturi,Yellow
O-RING, Check Valve
SEAL, Double-Lip
O-RING, High Pressure Transfer
O-RING, Outlet CV Cap
SHCS, M6-1.0 x 35
