Fujitsu SPARC Enterprise T5120 Getting Started Manual

(for models that run on dc input power)
Hide thumbs

Advertisement

SPARC
Enterprise T5120 Server Getting Started Guide
®
(For Models That Run on DC Input Power)
This guide describes the minimum steps you must perform to power on and boot your server for the first time
using the preinstalled Solaris™ Operating System (Solaris OS).
Servers that use DC input power require you to build and connect the power cords to specific safety
specifications. The specifications are described in the SPARC Enterprise T5120 and T5220 Servers Installation Guide
that is available from http://www.fujitsu.com/sparcenterprise/manual/.
SPARC Enterprise T5120 Server
FIGURE 1

Before You Begin

For quick installation and configuration, follow these steps. For more detailed information, refer to the complete
online product documentation set at: http://www.fujitsu.com/sparcenterprise/manual/
Understand the following information before you set up the server for the first time:
Do not apply power until instructed to do so – This system includes a service processor (SP) that is used to
configure and boot the host server. To properly configure the host server and view SP messages, do not apply
power to the server until the SP and host networking connections are made, as described in this guide.
Shipping Contents
Quant
ity
Item
1
Server
2
RJ-45 Ethernet cable
1
RJ-45 to DB-25 adapter (crossover)
1
RJ-45 to DB-9 adapter (crossover)
1
Wrist strap
2
DC power connectors
1
Rackmounting kit with cable
management assembly

Advertisement

loading

  Summary of Contents for Fujitsu SPARC Enterprise T5120

  • Page 1: Before You Begin

    Solaris™ Operating System (Solaris OS). Servers that use DC input power require you to build and connect the power cords to specific safety specifications. The specifications are described in the SPARC Enterprise T5120 and T5220 Servers Installation Guide that is available from http://www.fujitsu.com/sparcenterprise/manual/.
  • Page 2 To take advantage of the DHCP setup method, refer to the online installation guide in the online product documentation set at: http://www.fujitsu.com/sparcenterprise/manual/ Set aside sufficient time – Installation times vary, but if you are performing these setup instructions for the ■...
  • Page 3: Quick Setup Instructions

    For rackmounting instructions, refer to the instructions included with the rail kit, the service label on the server, and to the online SPARC Enterprise T5120 and T5220 Servers Installation Guide. 3. Connect a serial cable between the server’s SER MGT port ( ) and a terminal device.
  • Page 4 6. Build and connect your DC power cables into the server power supplies and into separate power sources. Instructions for building the DC power cables are in the SPARC Enterprise T5120 and T5220 Servers Installation Guide. To provide redundancy, plug both power supplies into separate power sources. Note that the system can operate with only one power connection, but there is no redundancy in this case.
  • Page 5: Accessing Documentation

    Review the Solaris OS man pages and documentation for more details. Accessing Important Information for SPARC Enterprise Series Servers Before you deploy your server, check for the Product Notes for your server and other important information on the following websites. Global Site http://www.fujitsu.com/sparcenterprise/manual/notes/ North American Site https://download.computers.us.fujitsu.com/ Japanese Site http://primeserver.fujitsu.com/sparcenterprise/manual/notes/...
  • Page 6: Fujitsu Welcomes Your Comments

    For Users in Other Countries: http://www.fujitsu.com/global/contact/computing/sparce_index.html Copyright 2008-2009 Sun Microsystems, Inc. All rights reserved. FUJITSU LIMITED provided technical input and review on portions of this material. Copyright 2008-2009 Sun Microsystems, Inc. Tous droits réservés. Revue technique fournie par FUJITSU LIMITED sur des parties de ce matériel.
  • Page 8 s e t h e N F S v 4 d o m a i n d e r i v e d b y t h e s y s t e m...
  • Page 9 o o t...
  • Page 10 S U N S P 0 0 1 4 4 F A C 7 3 2 F l o g i n : r o o t P a s s w o r d : c h a n g e m e .
  • Page 11 h o w r e v p r i n f o...
