- Page 1 150 LITRE COMPRESSORS MODEL No. DA160/400B. STOCK No. 33059. MODEL No. DA150/400BLA. STOCK No. 52585. • INSTRUCTIONS • IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL. 05/97...
-
Page 2: Table Of Contents
STOCK No.52585. Whilst every effort has been made to ensure accuracy of information given in this manual is correct at the time of going to print, the Draper Tools policy of continuous improvement determines the right to change specification without notice. -
Page 3: Specification/Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorized. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the 12 month period. -
Page 4: Safety Warning
Please read the following instructions carefully. Failure to do so could lead to serious personal injury. IMPORTANT: Draper Tools recommends that this compressor should not be modified or used for any application other than that for which it was designed. If you are unsure of it’s relative applications do not hesitate to contact us in writing and we will advise you. -
Page 5: Power Supply
POWER SUPPLY CONNECTING YOUR COMPRESSOR TO THE POWER SUPPLY: A separate electrical socket should be used for your machine. The circuit should not be less that a 13 amp ring main which should be protected by a 30 amp fuse or miniature circuit breaker rated at 30 amps. If an extension cable is used, use only 3-core extension leads with 3-pin sockets which will accept the machine’s plug. -
Page 6: Know Your Air Compressor
KNOW YOUR AIR COMPRESSOR (A) PRESSURE GAUGE (G) AIR OUTLET VALVE indicates air pressure in receiver releases air from the reservoir (B) ON/OFF SWITCH (PRESSURE SWITCH) (H) THERMAL OVERLOAD PROTECTION RESET SWITCH (C) MOTOR (I) OVERLOAD SAFETY RELIEF VALVE (D) RESERVOIR INSPECTION PLUG (J) RESERVOIR DRAIN VALVE (E) PULLEY GUARD covers, protects moving parts... -
Page 7: Operation
OPERATION 1. Connect the compressor to the power supply. Always turn the machine on and off by means of the appropriate switch (B) Fig.4 located on top of the pressure switch box. Fig.4. 2. Check that the reservoir drain valve is closed (C) Fig.5. -
Page 8: Maintenance
MAINTENANCE IMPORTANT: Fig.9. Before performing any maintenance operations, disconnect the compressor from the power supply and release all the air from the receiver until the pressure gauge reads zero. EVERY DAY: A. Check the oil level and top up if required. B. -
Page 9: Optional Accessories
" Straight Air Line Hose Hose (50ft) (50ft) Part No.4307. Part No.4309. 3 pce Air Line Coupling Set Stock No.36940. Stock No.36942. Part No.ACK1. Stock No.27740. See Draper Catalogue for full range of PCL couplings and fittings - 9 -... -
Page 10: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE SYMPTOMS POSSIBLE CAUSES Thermal overload protection trips. Oil level low. Wrong direction of rotation. Pressure switch failure/motor overload. High oil consumption. Air filter clogged. Wrong type of oil. Broken piston rings. Oil pumping. Air filter clogged. Wrong type of oil Oil level too high. - Page 11 NOTES - 11 -...
- Page 12 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
