Summary of Contents for HP Compaq 8200 Elite

  • Page 1 Hardware Reference Guide HP Compaq 8200 Elite All-in-One Business PC...
  • Page 2 Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3: About This Book

    About This Book This guide provides basic information for upgrading this computer model. WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily harm or loss of life. CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information.
  • Page 4 About This Book ENWW...

  • Page 5: Table Of Contents

    Table of contents 1 Product Features ............................1 Overview .............................. 1 Front Components ..........................2 Side Components ..........................3 Rear Components ..........................4 Keyboard Features ..........................4 Adjusting Tilt ............................5 2 Hardware Repair and Upgrade ........................6 Warnings and Cautions ........................6 Additional Information ...........................
  • Page 6 ENWW...

  • Page 7: Product Features

    Product Features Overview Figure 1-1 HP Compaq 8200 Elite All-in-One Business PC The HP Compaq 8200 Elite All-In One Business PC offers the following features: ● Integrated All-in-One form factor ● 23-inch diagonal widescreen Full HD WLED anti-glare display (1080p) ●...

  • Page 8: Front Components

    Removable panels on the back of the chassis allow users or technicians to easily and efficiently service the PC ● Face Recognition for HP ProtectTools software with auto-login capabilities ● ENERGY STAR® qualified, EPEAT® Silver registered, and offers 89-percent energy-efficient power ●...

  • Page 9: Side Components

    Side Components Figure 1-3 Side Components Table 1-2 Side Components Component Component HP 6-in-1 Media Card Reader Tray-load optical drive (2) USB 2.0 ports Optical drive eject button Microphone/line in jack Brightness increase button Headphone jack Brightness decrease button Optical drive activity LED...

  • Page 10: Rear Components

    Rear Components Figure 1-4 Rear Components Table 1-3 Rear Components Component Component Drive access panel Security lock slot Center access panel Power connector with LED indicator Memory access panel RJ-45 Gigabit Ethernet port Optical drive location Stereo audio line out Hard drive location (4) USB 2.0 ports Memory location...

  • Page 11: Adjusting Tilt

    Table 1-4 Keyboard Features Component Component Sleep Fast Forward Fast Reverse Mute Volume Play/Pause Decrease Volume Stop Increase Volume Adjusting Tilt Tilt the computer forward up to 5 degrees or backward up to 20 degrees to set it to a comfortable eye level.

  • Page 12: Hardware Repair And Upgrade

    . It describes proper workstation, setup, posture, and health and work habits for computer users, and provides important electrical and mechanical safety information. This guide is located on the Web at http://www.hp.com/ergo. WARNING! Computers that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause personal injury.

  • Page 13: Connecting Power

    Connecting Power Plug the power cord into the power connection on the rear of the computer (1). Plug the three-pronged power plug into the power brick (2) and a power outlet (3). Figure 2-1 Connecting Power Plug all peripheral cables into the appropriate ports as needed. Press the power button on the front of the computer to turn it on.
  • Page 14 Place the computer face down on a soft flat surface. HP recommends that you set down a blanket, towel, or other soft cloth to protect the screen surface from scratches or other damage.
  • Page 15 To remove the memory access panel, pull upward on the two tabs on the inside edge of the panel (1) and slide the panel off the computer (2). Figure 2-3 Removing the Memory Access Panel Pull upward on the two raised tabs on the memory cover and lift the cover off the rear panel. Figure 2-4 Removing the Memory Cover ENWW...
  • Page 16 To remove a memory module, press outward on the two latches on each side of the SODIMM (1) then pull the SODIMM out of the socket (2). Figure 2-5 Removing a Memory Module To install a memory module, slide the SODIMM into the socket at approximately a 30° angle (1) then press the SODIMM down (2) so that the latches lock it in place.
  • Page 17 Press the memory cover back in place. Insert the bottom edge of memory cover into the sheet metal shielding first then press the top edge of memory cover down. Ensure that all the tabs on the memory cover are pressed firmly against the sheet metal shielding. Figure 2-7 Replacing the Memory Cover Place the memory access panel on the rear of the computer so that the edge of the panel is...

  • Page 18: Replacing The Hard Drive

    Place the computer face down on a soft flat surface. HP recommends that you set down a blanket, towel, or other soft cloth to protect the screen surface from scratches or other damage.
  • Page 19 Remove the center access panel by pulling outward on the panel at the slot on the top edge of the panel. Figure 2-10 Removing the Center Access Panel To remove the drive access panel, push downward on the two tabs on the inside edge of the panel (1) and slide the panel off the computer (2).
  • Page 20 Loosen the captive screw next to the front of the drive that secures the drive to the computer. You can use either a Torx or slotted screwdriver to loosen the screw. Figure 2-12 Loosening the Hard Drive Security Screw Grasp the handle on top of the hard drive cage (1) and slide the cage toward the outer edge of the computer, then lift the cage out of the computer (2).
  • Page 21 Remove the four mounting screws that secure the drive to the cage. Do not remove the blue rubber grommets behind each screw. They must stay attached to the cage when installing a new hard drive. Figure 2-14 Removing the Hard Drive Mounting Screws Slide the hard drive out of the cage.
  • Page 22 Slide the new hard drive into the cage making sure that the connectors on the hard drive are at the opening of the cage. Figure 2-16 Sliding the Hard Drive into the Cage Install the four mounting screws that secure the hard drive to the cage. Make sure that the blue rubber grommets remain attached to the cage behind each screw.
  • Page 23 Set the hard drive cage down into the bay so that the tabs on the bottom of the cage align with the slots on the chassis and slide the cage toward the center of the computer (1) so that the connector on the rear of the drive is securely seated.

  • Page 24: Installing A Security Lock

    Place the drive access panel on the rear of the computer so that the edge of the panel is slightly hanging off the edge of the computer and slide the panel toward the center of the computer until it snaps in place. Figure 2-20 Replacing the Drive Access Panel To replace the center access panel, insert the bottom edge of the panel then press down firmly...

  • Page 25: Synchronizing The Optional Wireless Keyboard Or Mouse

    the cable to your desk (or other stationary object) and the other to this security slot on the computer. Secure the security lock with the key. Figure 2-22 Installing a Security Lock Synchronizing the Optional Wireless Keyboard or Mouse The optional wireless keyboard and mouse are easy to set up. Just remove the battery tabs on both the keyboard and the mouse.
  • Page 26 Insert the wireless receiver into a USB port on the computer. Figure 2-23 Installing the Wireless Receiver Make sure the Power switch on the bottom of the mouse is in the On position (1). Press the Connect button on the bottom of the mouse (2) for fives seconds. The blue activity LED from the wireless receiver illuminates when the synchronization command has been received and turns off when synchronization is complete.

  • Page 27: Removing Batteries From The Wireless Keyboard Or Mouse

    Removing Batteries from the Wireless Keyboard or Mouse NOTE: The wireless keyboard and mouse are optional components. To remove batteries from the wireless keyboard, remove the battery door on the underside of the keyboard (1) and lift the batteries out of the battery compartment (2). Figure 2-25 Removing Batteries from the Wireless Keyboard To remove batteries from the wireless mouse, remove the battery door on the underside of the mouse...

  • Page 28: Appendix A Electrostatic Discharge

    Use conductive field service tools. ● Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, contact an HP authorized dealer, reseller, or service provider. NOTE: For more information on static electricity, contact an HP authorized dealer, reseller, or service provider.

  • Page 29: Appendix B Computer Operating Guidelines, Routine Care And Shipping Preparation

    Computer Operating Guidelines, Routine Care and Shipping Preparation Computer Operating Guidelines and Routine Care Follow these guidelines to properly set up and care for the computer: ● Keep the computer away from excessive moisture, direct sunlight, and extremes of heat and cold.

  • Page 30: Optical Drive Precautions

    CAUTION: If any object or liquid falls into the drive, immediately unplug the computer and have it checked by an authorized HP service provider. Shipping Preparation Follow these suggestions when preparing to ship the computer: Back up the hard drive files on PD discs, tape cartridges, CDs, or USB flash drives.

  • Page 31: Index

    Index additional information 6 optical drive precautions 24 components front 2 power rear 4 connecting 7 side 3 computer operating guidelines 23 rear components 4 electrostatic discharge, preventing security lock location 18 damage 22 shipping preparation 24 side components 3 features specifications keyboard 4...
