Electrical outlets and cable lengths ..Cleaning and maintenance ... ix Register your computer with Lenovo ..Chapter 1. Product overview ..1 Moving your computer to another country or region .
Page 4
Safety and Warranty... Selecting a temporary startup device ..Lenovo Web site ... . Selecting or changing the startup device Lenovo Support Web site.
® Document Format (PDF) version from the Lenovo Support Web site at http://www.lenovo.com/support. The Lenovo Support Web site also provides the ThinkCentre Safety, Warranty, and Setup Guide and this ThinkCentre User Guide in additional languages. Service and upgrades Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center or your documentation.
or CRU, do not open the static-protective package containing the part until the instructions direct you to install it. When you handle options or CRUs, or perform any work inside the computer, take the following precautions to avoid static-electricity damage: •...
For your safety and to maintain optimum computer performance, always follow these basic precautions with your desktop computer: • Keep the cover closed whenever the computer is plugged in. • Regularly inspect the outside of the computer for dust accumulation. •...
Chapter 1. Product overview This chapter provides information about the computer features, specifications, software programs provided by Lenovo, and locations of connectors, components, parts on the system board, and internal drives. Features This section introduces the computer features. The information covers a variety of models.
Page 14
Connectivity • 10/100/1000 Mbps Ethernet controller System management features • Ability to store power-on self-test (POST) hardware test results • Desktop Management Interface (DMI) Desktop Management Interface provides a common path for users to access information about all aspects of a computer, including processor type, installation date, attached printers and other peripherals, power sources, and maintenance history.
Page 15
The operating system(s) listed here are being certified or tested for compatibility at the time this publication goes to press. Additional operating systems might be identified by Lenovo as compatible with your computer following the publication of this manual. This list is subject to change. To determine if an operating system has been certified or tested for compatibility, check the Web site of the operating system vendor.
Input frequency range: 50 to 60 Hz Lenovo programs Your computer comes with Lenovo programs to help you work more easily and securely. Depending on the Windows operating system preinstalled, the programs might vary. Accessing Lenovo programs on the Windows 7 operating system On the Windows 7 operating system, you can access Lenovo programs from either the Lenovo ®...
Page 17
Note: If you do not find the program you need in Control Panel, open the Lenovo ThinkVantage Tools program navigation window and double-click the dimmed icon to install the program you need. Then, follow the instructions on the screen.
Lenovo program to launch it. If a desired program is not in the list, click the plus icon +. • Press the Windows key to go to the Start screen. Click a Lenovo program to launch it. If you cannot find the program you need, move the pointer to the bottom-right corner of the screen to display the charms.
Page 19
The Lenovo Cloud Storage program is a cloud storage solution that enables you to store your files, such as documents and pictures, on a server. You can access the stored files through the Internet from different devices such as personal computers, smart phones, or tablets. For more information about the Lenovo Cloud Storage program, go to http://www.lenovo.com/cloud.
Web page, opening a file, and so on. You also can use the SimpleTap program to access the Lenovo App Shop, from which you can download various applications and computer software. To start the SimpleTap program in a quick way, do any of the following: –...
Locating connectors, controls, and indicators on the front of your computer Figure 1 “Front connector, control, and indicator locations” on page 9 shows the locations of the connectors, controls, and indicators on the front of your computer. Figure 1. Front connector, control, and indicator locations Integrated Microphone Hard disk drive activity indictor Integrated camera indicator...
Locating connectors on the rear of your computer Figure 2 “Rear connector locations” on page 10 shows the locations of the connectors on the rear of your computer. Some connectors on the rear of your computer are color-coded to help you determine where to connect the cables on your computer.
Connector Description DisplayPort out connector Used to attach a high-performance monitor, a direct-drive monitor, or other devices that use a DisplayPort connector. Ethernet connector Used to attach an Ethernet cable for a local area network (LAN). Note: To operate the computer within FCC Class B limits, use a Category 5 Ethernet cable.
Figure 3. Adjusting the computer stand Machine type and model label The machine type and model label identifies your computer. When you contact Lenovo for help, the machine type and model information helps support technicians to identify your computer and provide faster service.
Lenovo provides a program that enables you to create recovery discs. For details about creating recovery discs, see “Creating recovery media” on page 36. Additionally, in case of a hard disk failure, you can order Product Recovery discs from the Lenovo Customer Support Center. For information about contacting the Customer Support Center, see Chapter 11 “Getting information, help, and service”...
Some keyboards have a blue ThinkVantage button that you can use to open a comprehensive on-board help and information center from Lenovo. Pressing the blue ThinkVantage button opens the SimpleTap program on the Windows 7 operating system or the Lenovo PC Device Experience program on the Windows 8 operating system.
Using the wheel mouse Primary mouse button Use this button to select or start a program or menu item. Wheel Use the wheel to control the scrolling action of the mouse. The direction in which you rotate the wheel controls the direction of the scrolling action. Secondary mouse button Use this button to display a menu for the active program, icon, or object.
1. From the Windows desktop, click Start ➙ Control Panel ➙ Appearance and Personalization. 2. In the Taskbar and Start Menu section, click Customize icons on the taskbar. 3. Click Turn system icons on or off and change the volume behaviors from Off to On. 4.
CD or DVD, do the following: To record a CD or DVD, do one of the following: • On the Windows 7 operating system, you have either the Corel DVD MovieFactory Lenovo Edition program or the Power2Go program installed on your computer.
Using the single-touch and multi-touch feature Note: The single-touch feature or multi-touch feature is only available on some computer models. Your computer might come with the single-touch feature or multi-touch feature depending on your model. If the single-touch feature or the multi-touch feature is available on your computer, you can tap the touch screen once with your finger to make a single click.
Selecting a pre-defined color temperature To select a pre-defined color temperature, do the following: 1. Press the brightness-up button. The following six options are displayed: • Auto adjustment • Pre-defined color temperature • Switch to RGB adjustment • Brightness adjustment •...
Page 32
1. Press the brightness-up button. The following six options are displayed: • Auto adjustment • Pre-defined color temperature • Switch to RGB adjustment • Brightness adjustment • Default setting • Exit 2. Press the brightness-down button to move to Brightness adjustment, and then press the brightness-up button.
The following topics provide information about arranging your work area, setting up your computer equipment, and establishing healthy work habits: Lenovo is committed to providing people with disabilities greater access to information and technology. As a result, the following information provides ways to help users that have hearing, vision, and mobility limitations get the most out of their computer experience.
Adjust the monitor so the top of the screen is at, or slightly below, eye level. Place the monitor at a comfortable viewing distance, usually 51 to 61 cm (20 to 24 inches), and position it so you can view it without having to twist your body.
When you register your computer, information is entered into a database, which enables Lenovo to contact you in case of a recall or other severe problem. After you register your computer with Lenovo, you will receive quicker service when you call Lenovo for help. In addition, some locations offer extended privileges and services to registered users.
If you relocate your computer to a country or region that uses an electrical outlet style different from the type you are currently using, you will have to purchase either electrical plug adapters or new power cords. You can order power cords directly from Lenovo. For power cord information and part numbers, go to: http://www.lenovo.com/powercordnotice...
The cable lock also locks the buttons used to open the computer cover. This is the same type of lock used with many notebook computers. You can order an integrated cable lock directly from Lenovo by searching for Kensington at: http://www.lenovo.com/support Figure 5.
Your computer is preinstalled with an antivirus program to help you guard against, detect, and eliminate viruses. Lenovo provides a full version of antivirus software on your computer with a free 30-day subscription. After 30 days, you must renew the license to continue receiving the antivirus software updates.
Page 40
For more information about how to use your antivirus software, refer to the help system of your antivirus software. ThinkCentre User Guide...
Do not open your computer or attempt any repair before reading and understanding the “Important safety information” on page v. Notes: 1. Use only computer parts provided by Lenovo. 2. When installing or replacing an option, use the appropriate instructions in this section along with the instructions that come with the option.
Installing a computer wall mount Note: When installing a computer wall mount, make sure that you leave at least a 60 mm (2.36 inches) space between the wall and your computer for easy access to the connectors on the computer rear panel. Removing and reinstalling the monitor stand Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety information”...
6. To reinstall the monitor stand, align the four screw holes with the corresponding holes in the chassis, and then install the four screws to secure the monitor stand to the computer. Figure 7. Reinstalling the monitor stand Replacing the USB keyboard or mouse Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety information”...
2. Remove the new wireless keyboard from the package. 3. Install the keyboard by opening the battery compartment cover and installing two AAA batteries according to the polarity indicators. Figure 9. Installing the keyboard batteries 4. Remove the USB dongle from the keyboard compartment or from the wireless mouse compartment and connect it to an available USB connectors on the computer.
Page 45
Press the battery compartment release button. Take out the USB dongle Figure 11. Taking out the USB dongle Figure 10. Opening the battery compartment Connect the USB dongle to an available USB connector Insert two AA batteries into the mouse compartment on the computer.
5. Reconnect the external cables and power cords to the computer. Obtaining device drivers You can obtain device drivers for operating systems that are not preinstalled at http://www.lenovo.com/support. Installation instructions are provided in readme files with the device-driver files. ThinkCentre User Guide...
Recovery program or the Product Recovery program installed. If the Enhanced Backup and Restore icon in the Lenovo ThinkVantage Tools program is dimmed, it indicates that you need to install the Rescue and Recovery program manually before enabling its features. To install the Rescue and Recovery program, do the following: a.
Note: On the Windows 7 operating system, you can create recovery media using discs or external USB storage devices. To create recovery media on the Windows 7 operating system, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Factory Recovery Disks. Then, follow the instructions on the screen.
1. From the Windows desktop, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Enhanced Backup and Restore. The Rescue and Recovery program opens. 2. In the Rescue and Recovery main window, click the Launch advanced Rescue and Recovery arrow.
This section provides instructions on how to create a rescue medium. To create a rescue medium on the Windows 7 operating system, do the following: 1. From the Windows desktop, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Enhanced Backup and Restore. The Rescue and Recovery program opens.
Reinstalling preinstalled applications This section provides instructions on how to reinstall preinstalled applications. To reinstall the selected applications preinstalled on your Lenovo computer, do the following: 1. Turn on the computer. 2. Go to the C:\SWTOOLS directory. 3. Open the apps folder. Within the apps folder, there are several subfolders named for various applications installed in your computer.
• To reinstall most commercially available programs in your system, see Microsoft Windows help system for more information. • To reinstall selected application programs that came preinstalled from Lenovo, do the following: 1. Turn on the computer. 2. Go to the C:\SWTOOLS directory.
device sequence in the Setup Utility program. See “Selecting a startup device” on page 45 for detailed information about temporarily or permanently changing the startup device sequence. For more information about the Setup Utility program, see Chapter 7 “Using the Setup Utility program” on page 43. It is important to create a rescue medium and a set of recovery media as early as possible and store them in a safe place for future use.
• Administrator Password • Hard Disk Password You do not have to set any passwords to use your computer. However, using passwords improves computing security. If you decide to set any passwords, read the following sections. Password considerations A password can be any combination of up to 64 alphabetic and numeric characters. For security reasons, it is recommended to use a strong password that cannot be easily compromised.
2. From the Setup Utility program main menu, select Security. 3. Depending on the password type, select Set Power-On Password, Set Administrator Password, or Hard Disk Password. 4. Follow the instructions on the right side of the screen to set, change, or delete a password. Note: A password can be any combination of up to 64 alphabetic and numeric characters.
3. Select the devices for the Primary Boot Sequence, the Automatic Boot Sequence, and the Error Boot Sequence. Read the information displayed on the right side of the screen. 4. Press F10 to save and exit the Setup Utility program. See “Exiting from the Setup Utility program” on page 46.
Utility program by starting your computer with a system-program-update disc or running a special update program from your operating system. Lenovo might make changes and enhancements to the POST and BIOS. When updates are released, they are available as downloadable files on the Lenovo Web site at http://www.lenovo.com. Instructions for using the POST and BIOS updates are available in a TXT file that is included with the update files.
Updating (flashing) the BIOS from your operating system Note: Because Lenovo makes constant improvements to its Web sites, the Web page contents are subject to change without notice, including the contents referenced in the following procedure. To update (flash) the BIOS from your operating system, do the following: 1.
Attention: Do not download updated device drivers from the Windows Update Web site. The device drivers provided on the Windows Web site have not been tested by Lenovo and using them might cause unexpected problems. Obtain updated device drivers from Lenovo.
The System Update program is preinstalled on most Lenovo computers and is ready to run. The only prerequisite is an active Internet connection. You can start the program manually, or you can use the schedule feature to enable the program to search for updates automatically at specified intervals.
CAUTION: Be sure to turn off the computer and monitor power switches before cleaning the computer and monitor screen. Computer Use only mild cleaning solutions and a damp cloth to clean the painted surfaces of the computer. Keyboard To clean your computer keyboard, do the following: 1.
A log book can help you or a Lenovo technician determine if a problem is related to change in hardware, change in software, or some other action that might have taken place.
Page 65
1. Back up all files and data from the hard disk drive. There are a variety of backup programs available commercially. Your operating system also might have a backup program that you can use. Lenovo provides the Rescue and Recovery program to help you back up and restore data. See “Performing backup and recovery operations”...
Note: If you cannot correct the problem, have the computer serviced. For a list of service and support telephone numbers, refer to the ThinkCentre Safety, Warranty, and Setup Guide that comes with your computer or go to the Lenovo Support Web site at http://www.lenovo.com/support/phone. Symptom...
See Chapter 11 “Getting information, help, and service” on page 73 for more information. • If you are unable to run the diagnostic program, contact the Lenovo Customer Support Center. See Chapter 11 “Getting information, help, and service” on page 73 for more information.
1. Remove the new hardware option or software. If you must remove the computer cover to remove a hardware option, make sure you review and follow the electrical safety information provided with your computer. For your safety, do not operate the computer with the cover removed. 2.
Refer to the documentation that comes with the application or game for instructions on setting sound-card settings. • If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
Note that on some models the startup sequence is permanently set and cannot be changed. If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
Page 72
• Try a lower screen resolution or color depth. If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
DVD disc is in the drive labeled “DVD”. If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
Page 74
See “Enabling or disabling a device” on page 45. If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
Networking problems The following are the most common networking problems. Select your networking problem from the following list: • “Ethernet problems” on page 65 • “A wireless LAN problem” on page 66 • “A wireless WAN problem” on page 67 •...
4. If an exclamation mark is displayed next to an adapter name under Network adapters, you might not be using the correct driver or the driver is not enabled. To update the driver, right-click the highlighted adapter. 5. Click Update Driver Software, and then follow the instructions on the screen. •...
• Ensure that the wireless radio is enabled by double-clicking the Access Connections icon in the Windows notification area. • Check Network Name (SSID), and your encryption information. Use Access Connections to verify this case-sensitive information. A wireless WAN problem Message: Unauthorized WAN card is plugged in - Power off and remove the WAN card.
Option problems Use this information to diagnose problems with Lenovo hardware options that do not have their own troubleshooting information. Select your symptom from the following list: • “An option that was just installed does not work” on page 68 •...
Page 81
Insufficient free hard disk drive space Symptom: Insufficient free hard disk drive space The Windows operating system will slow down and might produce errors if the hard disk drive gets too full. To check the amount of free space on the Windows 7 operating system, do the following: 1.
Note: Depending on the size of the hard disk drive and amount of data currently stored on the hard disk drive, the disk-defragmentation process might take up to several hours to complete. On the Windows 7 operating system, do the following: 1.
• Make sure that the serial-port adapter, if you added one, is properly installed and firmly seated. If these actions do not correct the problem, run the diagnostic programs (see “Lenovo Solution Center” on page 72 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service”...
Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files. You will need the log files when you speak to a Lenovo technical support representative. ThinkCentre User Guide...
You can use the information in this section to access useful resources relating to your computing needs. Lenovo ThinkVantage Tools The Lenovo ThinkVantage Tools program guides you to a host of information sources and provides easy access to various tools to help you work more easily and securely.
Most computers come with a set of diagnostic programs that help you identify hardware problems. For instructions on using the diagnostic programs, see “Lenovo Solution Center” on page 72. You can also get the latest technical information and download device drivers and updates from Lenovo Support Web site at: http://www.lenovo.com/support...
• Engineering Change management - There might be changes that are required after a product has been sold. Lenovo or your reseller will make selected Engineering Changes (ECs) that apply to your hardware available. These items are not covered by the warranty: •...
Page 88
For more information about these services, go to the Lenovo Web site at: http://www.lenovo.com ThinkCentre User Guide...
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo Rescue and Recovery ThinkVantage Microsoft, Windows, and Windows Media are trademarks of the Microsoft group of companies. Celeron, Intel, Intel Core and Pentium are trademarks of Intel Corporation in the United States, other countries, or both.
• Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by using other than specified or recommended cables and connectors or by unauthorized changes or modifications to this equipment.
Page 92
Geräte der Klasse B. Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach Paragraf 5 des EMVG ist die Lenovo (Deutschland) GmbH, Gropiusplatz 10, D-70563 Stuttgart. ThinkCentre User Guide...
Depending on the configuration of your computer and the country or region where the computer was purchased, you might have received additional printed regulatory notices. All regulatory notices are available on the Lenovo Support Web site in electronic format. To access electronic copies of the documentation, go to http://www.lenovo.com/support and click User Guides and Manuals.
Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. For information on recycling Lenovo products, go to: http://www.lenovo.com/recycling...
If you want to replace it with a new one, contact your place of purchase or ask for a repair service provided by Lenovo. If you have replaced it by yourself and want to dispose of the disused lithium battery, insulate it with vinyl tape, contact your place of purchase, and follow their instructions.
Customer participation is important to minimize any potential effects of batteries and accumulators on the environment and human health due to the potential presence of hazardous substances. For proper collection and treatment, go to: http://www.lenovo.com/recycling Appendix C. WEEE and recycling information...
ENERGY STAR program requirement for computers at the time of manufacture: 3512, 3528, 3533, 3535, 3536, 3537, 3538, 3539, 3543, 3548, 3549, 3553, 3554, 3556, 3558, and 3559. For more information about ENERGY STAR ratings for Lenovo computers, go to http://www.lenovo.com.
Appendix F. İthalatçı – İmalatçı / Üretici Firma Bilgileri ve Diğer Bilgiler 1. İmalatçı ya da ithalatçı firmaya ilişkin bilgiler: Ürünün ithalatçı firması, Lenovo Technology B.V. Merkezi Hollanda Türkiye İstanbul Şubesi’dir. Adresi ve telefonu şöyledir: Üner Plaza. Eski Üsküdar Yolu.
Page 104
13. İthal edilmiş mallarda, yurt dışındaki üretici firmanın unvanı ve açık adresi ile diğer erişim bilgileri (telefon, telefaks ve e-posta vb.): Lenovo (Singapore) Pte. Ltd. 151 Lorong Chuan No: 02-0 1 New Tech Park Singapore, 556741...
Garanti Hizmetinin Alınabileceği Merkezler Arızalı Ideapad / IdeaCentre /Lenovo B serisi/Lenovo G serisi /Lenovo H serisi /Lenovo V serisi ürünlerini ücretsiz servise gönderebilmeniz için aşağıdaki numaralardan servis kaydı açtırabilirsiniz. Telefon: 0 212 336 03 66 Ücretsiz aramalar için: 00800 448 825 165 (Sadece sabit hatlardan aranabilir)
Page 106
DİYARBAKIR Metro Bilgisayar Eğitim Tic. ve San.Ltd. Şti. Adresi: Ali Emiri 5. Sokak, Kaçmaz Apartmanı, No:4/1 Diyarbakır Posta kodu: 21100 Web Adresi: http://www.metrobilgisayar.com.tr/ Telefon: 412 223 94 36 Faks no: 422 224 55 07 İSTANBUL Bdh Bilişim Destek Hizmetleri San.Ve Tic.Aş. Gülbahar Mah.
Page 107
Peritus Bilgisayar Sist. Dış Tic.San.Ltd.Şti. Adresi: Ziverbey Eğitim Mahallesi, Poyraz Sokak, Sadıkoğlu İş Merkezi 1, D: 15 Ziverbey Kadıköy İstanbul Posta kodu: 81040 Web Adresi: http://www.pbs.biz.tr/ Telefon: 216 345 08 00 Faks no: 216 349 09 92 Seri Bilgi Teknolojileri LTD ŞTI. Alemdağ...
