Predator Engines 173cc Owner's Manual & Safety Instructions page 20

68122 Parts List
Part Description
1 Cover, Cylinder Head
2 Gasket, Cylinder Head Cover
3 Head Asm., Cylinder
4 Gasket, Cylinder Head
5 Bolt
6 Plug, Spark
7 Bolt, Cylinder Head
8 Bracket, Muffler Shield
9 Bolt
10 Stud
11 Pin
12 Crankcase Asm.
13 Shield, Crankcase Side
14 Dipstick Asm., Oil
15 Bolt
16 Bolt
17 Bracket, Fuel Tank Right
18 Seal, Oil
19 Bolt
20 Bolt
21 Plate, Breath Groove Cover
22 Gasket, Breath Groove
23 Piece, Breath
24 Strainer, Breath Groove
25 Shield, Crankcase Rear
26 Bearing
27 Bracket, Fuel Tank Left
28 Bolt
29 Arm, Governor
30 Washer
31 Seal, Oil
32 Pin
33 Bracket, Fuel Tank Lower
34 Bolt
35 Gasket, Crankcase
36 Pin
37 Washer
38 Block, Returning Oil
39 Bolt
40 Plate, Governor Spindle Compression
41 Seal, Oil
42 Bolt
43 Gear Asm., Governor
44 Cover, Crankcase
45 Ring, The First
46 Ring, The Second
47 Ring Set, Oil
48 Piston
49 Clip, Piston Pin
50 Pin, Piston
51 Rod, Connecting
52 Crankshaft Asm.
53 Nut, Valve Lock
54 Nut_ Valve Adjusting
55 Seat, Valve Spring
56 Rocker, Valve
57 Spring, Valve
58 Guide, Seal
59 Bolt, Valve Adjusting
60 Valve, Intake
Page 20
Qty.
1
1
1
1
4
1
4
1
1
2
2
1
1
1
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
6
1
1
1
1
1
1
2
1
1
1
2
2
2
2
2
1
2
1
For technical questions, please call 1-800-520-0882.
Part Description
61 Plate Asm., Lifter Stopper
62 Lifter, Valve
63 Tappet, Valve
64 Camshaft Asm.
65 Valve, Exhaust
66 Starter Asm., Recoil
67 Housing, Engine
68 Shroud
69 Nut
70 Stud
71 Stud
72 Gasket, Insulator Plate
73 Plate, Carburetor Insulator
74 Gasket, Carburetor
75 Gasket, Carburetor Insulator
76 Carburetor Asm.
77 Gasket, Air Cleaner
78 Priming Bulb
79 Gasket, Air Cleaner
80 Tube, Breather
81 Nut
82 Case, Air Cleaner
83 Element Asm., Air Cleaner
84 Cover, Air Cleaner Case
85 Cover, Muffler Outer
86 Gasket, Exhaust Outlet
87 Bolt
88 Bolt
89 Muffler Asm.
90 Bolt
91 Tank Asm., Fuel
92 Strainer, fuel
93 Clamp
94 Tube, Fuel
95 Clamp
96 Collar
97 Hose, Vapor Rubber
98 Valve, One Way
99 Jacket, Rubber
100 Hose, Vapor Rubber
101 Clamp
102 Hose, Air Cleaner Rubber
103 Collector, Vapor
104 Bracket Asm., Vapor Collector
105 Nut, Flywheel
106 Flywheel Asm.
107 Bolt
108 Coil, Ignition
109 Brake Asm.
110 Bolt
111 Bolt
112 Rod, Governor
113 Spring, Throttle Valve Returning
114 Control Asm., Throttle
115 Bolt
116 Support Asm., Governor
117 Bolt, Governor Support
118 Nut
119 Spring, Governor
120 Clip
Qty.
1
2
2
1
1
1
1
1
3
2
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
3
2
1
2
1
1
1
1
1
4
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Vertical Engine
